Hanwha ARD-810-2TB Video Surveillance Station - 10-Channel DVR with 2TB HDD - 4K/5MP Recording - HDMI - Ethernet
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This surveillance station records video in H.265, H.264, and Motion JPEG formats, balancing quality with efficient file sizes to maximize storage utilization. It handles PAL and NTSC video signal formats, making it compatible with a broad range of camera inputs globally. The system includes two USB 2.0 ports for peripheral connectivity and data transfer, alongside Ethernet for network integration.
The ARD-810-2TB is compatible with Windows 10, macOS Big Sur 11 or later, and Linux operating systems, offering flexibility in management software deployment. Its physical design measures 11.81 inches wide, 8.22 inches deep, and 1.85 inches high, with a weight of 2.43 pounds, fitting discreetly in rack or desktop installations. Environmental resilience is assured with an operating temperature range from 32°F to 104°F (0°C to 40°C), suitable for various indoor settings.
Relevant factors for this section include Total Number of Channels, Connectivity Technology, Recording Formats, Hard Drive Capacity. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Hanwha ARD-810-2TB delivers practical advantages for security deployments by combining high-capacity storage with advanced recording features. Its 10-channel capacity addresses the needs of small businesses, retail environments, or residential complexes requiring multi-camera coverage without overwhelming complexity.
Efficient Video Management
Utilizes H.265 and H.264 compression to record high-quality video with reduced file sizes, extending storage duration and minimizing bandwidth usage during remote viewing.
- Smaller file sizes for longer retention
- Reduced network load
Enhanced Detection Accuracy
Incorporates face detection, PTZ control, and motion detection to focus recording on relevant events, reducing storage waste and improving incident review efficiency.
- Automated event tracking
- Fewer false alarms
Deployment / Use Cases
This surveillance station is ideal for environments where reliable, centralized recording is needed without extensive IT infrastructure. Its 10-channel limit makes it a fit for small office buildings, retail stores, or warehouses where monitoring entry points, aisles, and storage areas is critical.
Use cases include retail loss prevention, where high-resolution recording helps identify shoplifting incidents; small business security, providing oversight of premises after hours; and residential complexes, monitoring common areas like lobbies or parking lots. The remote management capability allows property managers or security personnel to check feeds from off-site, enhancing responsiveness to alerts.
Retail Surveillance
Monitors cash registers, entrances, and stock rooms with 5MP clarity, supporting investigations into theft or disputes.
Office Building Security
Provides 24/7 recording of hallways, server rooms, and reception areas, with motion detection to flag unauthorized access.
Physical Profile
The ARD-810-2TB features a compact, low-profile design that facilitates easy placement on desktops or integration into standard rack setups. Its dimensions of 11.81 inches wide by 8.22 inches deep by 1.85 inches high allow it to fit in tight spaces, while the 2.43-pound weight ensures stability without bulk. The unit's construction supports reliable operation in controlled indoor environments, with ventilation considerations for sustained performance.
- Width
- 11.81" (300 mm)
- Depth
- 8.22" (208.70 mm)
- Height
- 1.85" (47 mm)
- Weight
- 2.43 lb (1100 g)
Highlights
- 10-channel capacity for small-to-mid range surveillance needs
- Pre-installed 2TB hard drive for ample video storage
- 4K recording support with up to 5MP resolution at 120 fps
- Advanced features: face detection, PTZ control, motion detection
- Ethernet connectivity for reliable wired network integration
- Remote management capability for off-site monitoring
- HDMI output for local display connectivity
- Compatible with Windows, macOS, and Linux operating systems
- Low power consumption at 20.40W
- Compact design: 11.81" W x 8.22" D x 1.85" H
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | ARD-810-2TB |
| Brand Name | Hanwha |
| Product Series | A |
| Product Model | ARD-810 |
| Product Name | A ARD-810 Video Surveillance Station |
| Product Type | Video Surveillance Station |
| Technical Information | |
| Total Number of Channels | 10 |
| Connectivity Technology | Wired |
| Recording Formats | 4K |
| HD Recording | Yes |
| System Components | Digital Video Recorder |
| Features | Face Detection,PTZ Control,Motion Detection |
| Storage | |
| Hard Drive Capacity | 2 TB |
| Video | |
| Video Formats | H.265,H.264,Motion JPEG |
| Video Signal Format | PAL,NTSC |
| Maximum Resolution | 5MP |
| Maximum Frame Rate | 120 fps |
| Network & Communication | |
| Ethernet | Yes |
| Remote Management | Yes |
| Interfaces/Ports | |
| USB | Yes |
| USB Standard | USB 2.0 |
| Number of USB Ports | 2 |
| HDMI | Yes |
| Software | |
| Operating System Supported | Windows 10,macOS Big Sur 11 or Later,Linux |
| Power Description | |
| Power Consumption | 20.40 W |
| Physical Characteristics | |
| Height | 1.85" (47 mm) |
| Width | 11.81" (300 mm) |
| Depth | 8.22" (208.70 mm) |
| DVR Weight | 2.43 lb (1100 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Miscellaneous | |
| Country of Origin | Vietnam |
User Manual
FAQ
How many cameras can I connect to the Hanwha ARD-810-2TB?
The Hanwha ARD-810-2TB supports up to 10 channels, meaning you can connect up to 10 cameras directly to this digital video recorder. This capacity is suitable for small-to-mid range surveillance setups, such as covering multiple entrances, rooms, or outdoor areas in a business or residential property.
What is the maximum recording resolution of this surveillance station?
This station records at a maximum resolution of 5MP (megapixels), which provides high-definition video clarity for identifying details like faces or license plates. It also supports 4K recording formats, ensuring compatibility with modern high-resolution cameras and delivering sharp footage for security reviews.
Does the ARD-810-2TB include built-in storage?
Yes, the ARD-810-2TB comes with a pre-installed 2TB hard drive. This provides substantial onboard storage for video footage, reducing the need for immediate additional purchases. The capacity allows for extended recording periods, especially when using efficient compression formats like H.265 to minimize file sizes.
Can I manage this DVR remotely?
Yes, the ARD-810-2TB supports remote management. Once connected to the internet via its Ethernet port, you can access the system from any location using compatible software. This enables live viewing, playback of recorded footage, and configuration changes without being physically present at the recorder.
What video compression formats does it use?
This DVR records video in H.265, H.264, and Motion JPEG formats. H.265 and H.264 are advanced compression standards that reduce file sizes while maintaining quality, helping to maximize storage efficiency and bandwidth usage. Motion JPEG offers alternative compatibility for specific playback or editing needs.
What operating systems are supported for management?
The Hanwha ARD-810-2TB is compatible with Windows 10, macOS Big Sur 11 or later, and Linux operating systems. This broad support allows flexibility in choosing management software and devices, whether you're using a PC, Mac, or Linux-based system to configure and monitor the surveillance station.
