Hanwha XNP-C6403R 2MP 40x AI IR PTZ Network Camera - Full HD 1080p - 656 ft IR Night Vision - White - HPoE
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera features a 1/2.8-inch CMOS sensor that delivers 2-megapixel resolution with support for H.265, H.264, and MJPEG compression formats. The varifocal lens offers a focal length range from 4.3mm to 170mm, providing both wide-angle coverage and detailed telephoto observation.
The camera's imaging system includes a comprehensive suite of video enhancement features including Wide Dynamic Range (WDR), Digital Noise Reduction (DNR), Back Light Compensation (BLC), and Digital Image Stabilization. These technologies work together to maintain image quality in high-contrast scenes and challenging lighting environments.
This section brings together practical product details such as HD Recording, Recording Formats, Night Vision, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The XNP-C6403R stands out with its combination of long-range infrared illumination, high optical zoom capability, and industrial-grade construction. The camera's AI-powered analytics enable intelligent monitoring with features like motion detection, privacy masking, and audio detection for comprehensive security coverage.
Extended Night Vision Coverage
Infrared illuminators provide clear monochrome imaging up to 656 feet (200 meters), eliminating the need for additional lighting in complete darkness.
- 200-meter IR range
- Integrated IR LEDs
- Day/Night functionality
Advanced Video Analytics
Built-in AI capabilities enable intelligent scene analysis and automated response to security events.
- Motion detection zones
- Privacy masking
- Audio detection triggers
Industrial Durability
IP66 weatherproof rating and IK10 impact resistance ensure reliable operation in harsh outdoor environments.
- Water and dust resistant
- Vandal resistant
- Wide temperature range
Deployment / Use Cases
The Hanwha XNP-C6403R is ideally suited for perimeter security, large facility monitoring, and critical infrastructure protection where long-range observation and detailed identification are essential. Its PTZ capabilities and high zoom ratio make it particularly effective for monitoring expansive areas from a single installation point.
Common deployment scenarios include parking lots, industrial complexes, transportation hubs, educational campuses, and government facilities. The camera's HPoE support simplifies installation by delivering both power and data over a single Ethernet cable, reducing wiring complexity and installation costs.
This section brings together practical product details such as HD Recording, Recording Formats, Night Vision, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Perimeter Security
Monitor fence lines, gates, and property boundaries with the camera's long-range IR and high zoom capabilities.
Large Area Surveillance
Cover expansive spaces like parking lots, warehouses, or sports facilities with a single high-performance camera.
Physical Profile
The camera features a durable white housing with a 6.22-inch (158 mm) diameter design that withstands harsh environmental conditions. Weighing 7.05 pounds (3200 grams), the unit maintains stability in windy conditions while supporting smooth PTZ operation. The compact form factor facilitates installation on poles, walls, or ceilings using standard mounting hardware.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 7.05 lb (3200 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 7.05 lb (3200 g)
- Length
- 4.3 mm (0.17")
Highlights
- 2-megapixel CMOS sensor delivers Full HD 1080p resolution at 60 fps
- 40x optical zoom varifocal lens (4.3mm to 170mm focal length)
- 656-foot (200-meter) infrared night vision with integrated IR illuminators
- HPoE (High Power over Ethernet) support for simplified installation
- IP66 weatherproof and IK10 impact-resistant construction
- Advanced video analytics including motion detection and privacy masking
- Wide operating temperature range from -40°F to 122°F (-40°C to 50°C)
- Support for H.265, H.264, and MJPEG video compression formats
- Fast Ethernet connectivity with comprehensive protocol support
- 3-year limited warranty for peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | XNP-C6403R |
| Brand Name | Hanwha |
| Product Series | X |
| Product Model | XNP-C6403R |
| Product Name | 2MP, 40x, AI IR PTZ camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | Full HD |
| Night Vision | Yes |
| Night Vision Distance | 656.17 ft (200 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.8" |
| Color Supported | Color |
| Field of View | H: 65.66°(Wide)~1.88°(Tele) / V: 39.4°(Wide)~1.09°(Tele) |
| Effective Camera Resolution | 2 Megapixel |
| Video | |
| Video Formats | H.265,H.264,MJPEG,H.265M,H.265H,H.264M,H.264H,H.265B,H.264B |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 60 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 4.3 mm (0.17") |
| Maximum Focal Length | 170 mm (6.69") |
| Lens Included | Yes |
| Minimum Aperture | f/4.95 |
| Maximum Aperture | f/1.6 |
| Optical Zoom | 40x |
| Exposure | |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 2 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | IPv4,IPv6,TCP/IP,UDP/IP,RTP/UDP,RTP/TCP,RTCP,RTSP,NTP,HTTP,HTTPS,SSL/TLS,DHCP,FTP,SMTP,ICMP,IGMP,SNMPv1/v2c/v3 (MIB2),ARP,DNS,DDNS,QoS,UPnP,Bonjour,LLDP,SRTP,ONVIF,TCP,NTCIP,MQTT |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Power Source Type | HPoE |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Diameter | 6.22" (158 mm) |
| Weight (Approximate) | 7.05 lb (3200 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Wide Dynamic Range,Day/Night,Back Light Compensation (BLC),Digital Noise Reduction,Digital Image Stabilization,Motion Detection,Privacy Masking,Gain Control,White Balance,Audio Detection,PTZ |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum night vision distance of this camera?
The Hanwha XNP-C6403R provides infrared night vision coverage up to 656.17 feet (200 meters). This extended range is achieved through integrated IR illuminators that enable clear monochrome imaging in complete darkness, making the camera suitable for perimeter security and large area surveillance applications.
What type of power does this network camera require?
This camera supports HPoE (High Power over Ethernet), which delivers both power and data over a single Ethernet cable. This simplifies installation by eliminating the need for separate power wiring and reduces overall deployment costs while ensuring reliable operation in remote or difficult-to-wire locations.
What video resolutions and frame rates does this camera support?
The camera captures Full HD video at 1920 x 1080 resolution with a maximum frame rate of 60 frames per second. This high frame rate ensures smooth video playback and accurate capture of fast-moving objects, making it suitable for applications requiring detailed motion analysis and identification.
Is this camera suitable for outdoor installation?
Yes, the XNP-C6403R is designed for outdoor use with an IP66 rating for protection against dust and water ingress. It also features an IK10 impact resistance rating and operates in temperatures from -40°F to 122°F (-40°C to 50°C), making it durable enough for challenging environmental conditions.
What type of lens does this camera have?
This camera features a varifocal lens with 40x optical zoom capability. The focal length ranges from 4.3mm (wide angle) to 170mm (telephoto), providing both broad area coverage and detailed close-up observation. The lens includes automatic aperture control from f/1.6 to f/4.95 for optimal light management.
What video compression formats are supported?
The camera supports H.265, H.264, and MJPEG compression formats, including advanced variants like H.265M, H.265H, H.264M, and H.264B. This comprehensive format support ensures compatibility with various recording systems and network video recorders while optimizing bandwidth usage and storage efficiency.
What storage is included?
The system includes Memory Card of storage for applications, files, and everyday business data.
