Hanwha XNP-C7310R 4MP AI IR PTZ Dome Camera - 31x Optical Zoom - 984 ft IR Night Vision - 2592 x 1520 Resolution - White
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the XNP-C7310R lies a 1/1.8" CMOS sensor that captures 4-megapixel imagery with enhanced low-light sensitivity. The varifocal lens system provides 31x optical zoom ranging from 6.9mm wide-angle to 214.7mm telephoto, complemented by a P-iris mechanism that maintains optimal exposure across lighting conditions. Video encoding utilizes H.265, H.264, and MJPEG compression with multiple profile options to balance quality and bandwidth requirements.
The camera's imaging pipeline includes advanced features such as wide dynamic range (WDR) for challenging lighting scenarios, digital image stabilization to reduce motion blur, and defog processing that enhances visibility in poor atmospheric conditions. Intelligent analytics capabilities support motion detection, privacy masking, and object tracking while maintaining compatibility with industry-standard video management systems.
Relevant factors for this section include HD Recording, Night Vision, Night Vision Distance, Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This surveillance camera delivers exceptional operational advantages through its combination of long-range capability, environmental resilience, and intelligent features. The 984-foot infrared night vision extends monitoring effectiveness around the clock, while the rugged construction ensures continuous operation across extreme temperature ranges from -58°F to 165°F.
Extended Monitoring Range
The 31x optical zoom provides precise identification capabilities at distance, while the 984-foot IR illumination ensures reliable nighttime coverage across large areas.
- 31x optical zoom for detailed identification
- 984 ft IR coverage for expansive areas
- Varifocal adjustment for optimal framing
Environmental Resilience
IP66/67 waterproof rating and IK10 impact resistance protect against harsh weather, dust, and physical damage for reliable outdoor deployment.
- IP66/67 waterproof and dustproof
- IK10 vandal resistance rating
- -58°F to 165°F operating range
Intelligent Analytics
Built-in AI capabilities support advanced video analytics including motion detection, privacy masking, and object tracking without requiring external processing.
- Motion detection with configurable zones
- Privacy masking for sensitive areas
- Defog and WDR for challenging conditions
Deployment / Use Cases
The XNP-C7310R excels in perimeter security applications where long-range identification and environmental durability are critical requirements. Its 31x zoom capability makes it ideal for monitoring large outdoor areas such as parking lots, industrial facilities, and transportation hubs where detailed facial or license plate recognition is necessary at distance.
Educational campuses and corporate facilities benefit from the camera's discreet dome design combined with robust vandal resistance, providing unobtrusive monitoring of entrances, courtyards, and high-traffic corridors. The HPoE support simplifies installation in retrofit scenarios where existing network infrastructure can deliver both power and data over standard Ethernet cabling.
Critical Infrastructure Protection
Monitor power plants, water treatment facilities, and communication towers with the camera's extended temperature range and environmental sealing.
- -58°F to 165°F operating range
- IP66/67 protection against elements
- Remote management via standard protocols
Large Perimeter Surveillance
Secure warehouses, logistics centers, and manufacturing campuses with the 984-foot IR coverage and 31x optical zoom for detailed identification.
- 984 ft IR illumination for expansive areas
- 31x zoom for target identification
- Fast Ethernet for reliable connectivity
Physical Profile
The white dome housing measures 7.40 inches (188 mm) in diameter with a weight of 9.70 pounds (4400 g), providing a substantial presence that deters tampering while maintaining aesthetic discretion. The form factor supports standard mounting options for ceiling or wall installation, with the dome design helping to conceal the camera's viewing direction for enhanced security effectiveness.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 9.70 lb (4400 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 9.70 lb (4400 g)
- Length
- 6.9 mm (0.27")
Highlights
- 4-megapixel CMOS sensor delivers 2592 x 1520 resolution at 60 fps
- 31x optical zoom varifocal lens with 6.9mm to 214.7mm focal range
- 984-foot (299.92 m) infrared night vision with built-in IR LEDs
- IP66/67 waterproof rating and IK10 impact resistance for harsh environments
- HPoE support delivers power and data over single Ethernet cable
- H.265, H.264, and MJPEG video compression with multiple profiles
- Wide dynamic range, defog, and digital image stabilization features
- ONVIF compliant with support for 30+ network protocols
- Operating temperature range from -58°F to 165°F (-50°C to 74°C)
- 5-year limited warranty with manufacturing in Vietnam
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | XNP-C7310R |
| Brand Name | Hanwha |
| Product Model | XNP-C7310R |
| Product Name | XNP-C7310R 4MP 31x AI IR PTZ Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 984 ft (299.92 m) |
| Night Vision Type | Infrared |
| Camera Iris | P-iris |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/1.8" |
| Color Supported | Color |
| Field of View | H : 59.4°(Wide)~2.54°(Tele), V : 35.8°(Wide)~1.49°(Tele), D : 68.2°(Wide)~2.95°(Tele) |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Video Formats | H.264,H.265,MJPEG,H.264B,H.264H,H.264M,H.265M,H.265H,H.265B |
| Maximum Video Resolution | 2592 x 1520 |
| Maximum Frame Rate | 60 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 6.9 mm (0.27") |
| Maximum Focal Length | 214.7 mm (8.45") |
| Lens Included | Yes |
| Minimum Aperture | f/4.6 |
| Maximum Aperture | f/1.36 |
| Optical Zoom | 31x |
| Exposure | |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 2 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | Unicast,Multicast,ONVIF,IEEE 802.1X (EAP-TLS),Digest Authentication,IPv4,IPv6,UDP/IP,RTP/UDP,RTP/TCP,RTSP,RTCP,NTP,HTTP,HTTPS,SSL/TLS,DHCP,FTP,SMTP,ICMP,IGMP,SNMPv1/v2c/v3 (MIB2),ARP,DNS,DDNS,QoS,UPnP,Bonjour,LLDP,CDP,SRTP,TCP,UDP,MQTT,NTCIP |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 62 W |
| Power Source Type | HPoE |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Form Factor | Dome |
| Diameter | 7.40" (188 mm) |
| Weight (Approximate) | 9.70 lb (4400 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -58°F (-50°C) |
| Maximum Operating Temperature | 165.2°F (74°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Day/Night,Built-in IR LED,Password Protection,Privacy Masking,Wide Dynamic Range,Motion Detection,Defog,Digital Image Stabilization,Gain Control,White Balance |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66,IP67 |
| Country of Origin | Vietnam |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the effective surveillance range of this camera's night vision?
The Hanwha XNP-C7310R provides infrared night vision coverage up to 984 feet (299.92 meters) using built-in IR LEDs. This extended range ensures reliable monitoring of large outdoor areas during nighttime hours, with the infrared illumination automatically activating in low-light conditions to maintain surveillance effectiveness around the clock.
How does the 31x optical zoom benefit surveillance applications?
The 31x optical zoom allows the camera to capture detailed imagery at varying distances without sacrificing image quality. With a focal length range from 6.9mm wide-angle to 214.7mm telephoto, operators can zoom in on specific areas of interest for identification purposes while maintaining the flexibility to monitor broader scenes when needed, all through optical magnification rather than digital zoom.
What environmental protections does this dome camera offer?
This camera features IP66/67 ingress protection ratings making it waterproof and dustproof, along with an IK10 impact resistance rating that provides vandal resistance. It operates across an extreme temperature range from -58°F to 165°F (-50°C to 74°C) and handles up to 95% humidity, ensuring reliable performance in challenging outdoor and industrial environments.
What power method does this network camera use?
The XNP-C7310R supports HPoE (High Power over Ethernet) which delivers both data and up to 62 watts of power over a single Ethernet cable. This simplifies installation by eliminating the need for separate power wiring near the camera location, while providing sufficient power for the camera's zoom mechanism, infrared LEDs, and heating elements in cold environments.
What video management systems are compatible with this camera?
The camera is ONVIF compliant and supports over 30 network protocols including RTSP, SNMP, and standard IP networking. This ensures compatibility with most professional video management software and network video recorder systems. The camera also includes support for multicast streaming, IPv6, and various authentication methods for integration into diverse security infrastructures.
What intelligent features does this AI camera include?
Beyond basic surveillance, the camera incorporates AI-powered analytics including motion detection with configurable zones, privacy masking to obscure sensitive areas in the video stream, defog processing to enhance visibility in poor conditions, and digital image stabilization to reduce motion blur. These features operate within the camera itself without requiring external processing hardware.
