HP B50TRUA#ABA Z2 Mini G9 Workstation - Intel Core i9-14900K 14th Gen - 64GB DDR5512GB NVMe SSD - 12GB Dedicated Graphics - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Built on Intel's W680 chipset, the Z2 Mini G9 Workstation features a 24-core Intel Core i9-14900K processor operating at 3.20 GHz with 32 threads for parallel processing efficiency. The system supports up to 64GB of DDR5 SDRAM across two memory slots, providing high-speed data access for memory-intensive applications.
Storage is handled by a 512GB PCI Express NVMe 4.0 solid-state drive with x4 interface bandwidth, delivering rapid file access and system responsiveness. The NVMe controller supports RAID 0 and 1 configurations for data protection or performance optimization. Connectivity includes six USB ports with two SuperSpeed USB Type-C 20Gbps ports, four Mini DisplayPort outputs, Gigabit Ethernet, wireless LAN, and Bluetooth for comprehensive peripheral support.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Compact Professional Workstation, High-Performance Computing.
Compact Professional Workstation
The mini PC form factor delivers full workstation capabilities in a space-efficient design measuring just 2.72" x 8.31" x 8.58", ideal for crowded desks, mobile setups, or multi-system deployments where physical footprint matters.
- Small form factor saves desk space
- Easy to transport between locations
- Simplifies cable management in tight spaces
High-Performance Computing
With 24 processing cores, 64GB of DDR5 memory, and dedicated graphics acceleration, this system maintains consistent performance under heavy computational loads typical in professional technical environments.
- 24-core processor handles parallel workloads
- DDR5 memory improves data transfer efficiency
- Dedicated graphics accelerates visualization tasks
Deployment / Use Cases
The HP Z2 Mini G9 Workstation excels in environments where computing power must coexist with physical space constraints. Engineering firms can deploy multiple units for CAD and simulation work without consuming excessive office real estate. Financial analysts benefit from the system's processing capabilities for complex modeling while maintaining clean, organized workspaces.
Creative studios appreciate the dedicated graphics performance for video editing and 3D rendering in compact editing bays. Educational institutions find the small form factor ideal for computer labs where multiple workstations must fit in limited classroom spaces. IT departments value the standardized configuration for easy deployment and maintenance across professional user bases.
Technical Design & Engineering
Supports CAD applications, finite element analysis, and computational fluid dynamics with the processing power and memory capacity needed for complex simulations and modeling.
Data Analysis & Scientific Computing
Handles large datasets, statistical analysis, and research computations with the multi-core processor and high-speed storage for efficient data processing workflows.
Localization and Operating System
This workstation ships with Windows 11 Pro pre-installed, providing professional-grade operating system features including BitLocker encryption, Remote Desktop, and enhanced security controls. The Windows 11 Pro environment offers a modern interface optimized for productivity with improved window management, virtual desktop support, and integration with Microsoft 365 services.
The system supports dual voltage input (120V AC and 230V AC) for international deployment flexibility. Environmental certifications include Energy Star compliance, China Energy Conservation Program (CECP), Energy-related Products Directive (ErP), RoHS, WEEE, and TCO Certified standards for global regulatory acceptance.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The compact mini PC design measures 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth, with a weight of approximately 5.29 pounds. The small footprint allows placement in various orientations—vertical with optional stand or horizontal on desk surfaces. The air cooling system maintains optimal thermal performance within the constrained enclosure while operating quietly in office environments.
The minimalist chassis design features clean lines and professional aesthetics suitable for corporate settings. The compact dimensions facilitate installation in space-constrained areas such as under desks, on wall mounts, or in equipment racks with appropriate mounting hardware.
- Width
- 288 GB/s
- Depth
- 8.58" (218 mm)
- Height
- 2.72" (69 mm)
- Weight
- 5.29 lb (2400 g)
What's in the Box
The workstation ships complete with all essential components for immediate deployment.
Package contents include Z2 Mini G9 Workstation Wolf Pro Security Edition Keyboard Mouse Power Adapter, Z2 Mini G9 Workstation Wolf Pro Security Edition. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Core i9-14900K 14th Gen processor with 24 cores and 32 threads
- 64GB DDR5 SDRAM memory for handling memory-intensive applications
- 512GB PCIe NVMe 4.0 SSD provides fast storage access and system responsiveness
- 12GB dedicated graphics memory accelerates visualization and rendering tasks
- Windows 11 Pro operating system with professional features and security
- Compact mini PC form factor saves valuable desk space
- Six USB ports including two SuperSpeed USB Type-C 20Gbps ports
- Four Mini DisplayPort outputs support multiple monitor configurations
- Gigabit Ethernet, Wi-Fi, and Bluetooth for comprehensive connectivity
- 280W power supply with dual voltage input (120V/230V AC)
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | B50TRUA#ABA |
| Brand Name | HP |
| Product Series | Z2 Mini G9 |
| Product Name | Z2 Mini G9 Workstation Wolf Pro Security Edition |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i9 |
| Processor Generation | 14th Gen |
| Processor Model | i9-14900K |
| Processor Core | Tetracosa-core (24 Core) |
| Processor Threads | 32 |
| Processor Speed | 3.20 GHz |
| Processor Socket | Socket LGA-1700 |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 2 |
| Memory Configuration | 2 x 32GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe |
| RAID Supported | Yes |
| RAID Levels | 0, 1 |
| Display & Graphics | |
| Graphics Memory Capacity | 12 GB |
| Graphics Memory Accessibility | Dedicated |
| Maximum Memory Bandwidth | 288 GB/s |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x SuperSpeed USB Type-C 20Gbps signaling rate |
| DisplayPort | Yes |
| Mini DisplayPort | Yes |
| Number of Mini DisplayPort | 4 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 280 W |
| Physical Characteristics | |
| Cooler Type | Air Cooler |
| Form Factor | Mini PC |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Miscellaneous | |
| Package Contents | Z2 Mini G9 Workstation Wolf Pro Security Edition Keyboard Mouse Power Adapter |
| Energy Star | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
| Additional Warranty Information | Support Service Included: HP 3 Years Wolf Pro Security Edition Service. For terms and conditions, please visit & Manufacturer Warranty: 1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
User Manual
FAQ
What processor does the HP Z2 Mini G9 Workstation use?
This workstation features the Intel Core i9-14900K processor from the 14th Generation. It operates at 3.20 GHz with 24 physical cores and 32 threads, providing substantial processing power for demanding computational tasks. The processor uses the Socket LGA-1700 interface and is supported by Intel's W680 chipset for optimal performance in professional workstation applications.
How much memory is installed and what type is it?
The system comes with 64GB of DDR5 SDRAM installed across two memory slots in a 2 x 32GB configuration. DDR5 memory technology offers improved data transfer rates compared to previous generations, with this system supporting a maximum memory bandwidth of 288 GB/s. The memory operates in non-ECC mode and represents the maximum supported capacity for this configuration.
What storage configuration does this workstation have?
Storage is provided by a 512GB solid-state drive using the PCI Express NVMe 4.0 interface with x4 lanes. This NVMe SSD delivers high-speed storage access for rapid file loading and system responsiveness. The storage controller supports RAID 0 and RAID 1 configurations, allowing users to optimize for performance or data redundancy based on their specific workflow requirements.
What graphics capabilities does this workstation offer?
The workstation includes dedicated graphics with 12GB of dedicated memory. This graphics configuration provides hardware acceleration for visualization, rendering, and display-intensive applications. The system features four Mini DisplayPort outputs, enabling multi-monitor setups for expanded workspace in professional environments where multiple applications or data sources need simultaneous visibility.
What connectivity options are available on this system?
Connectivity includes six USB ports total, with two SuperSpeed USB Type-C ports supporting 20Gbps signaling rates. The system also features Gigabit Ethernet for wired networking, integrated wireless LAN for Wi-Fi connectivity, and Bluetooth for peripheral connections. Display outputs consist of four Mini DisplayPort connections for flexible monitor arrangements in professional workstation setups.
What is the form factor and physical dimensions of this workstation?
The HP Z2 Mini G9 uses a mini PC form factor with compact dimensions of 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth. Weighing approximately 5.29 pounds, this space-efficient design allows placement in various orientations while delivering full workstation capabilities. The small footprint is particularly valuable in environments where desk space is limited or multiple systems need deployment in constrained areas.
