HPE P20249-291 ProLiant DL380 G10 2U Rack Server - 1x Xeon Gold 5218 2. 3GHz 16-Core - 32GB RAM - 8 x 2. 5" Hot-Swap Bays - RAID - Gigabit Ethernet
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This ProLiant DL380 G10 server is engineered for high-density compute and storage in a standard 2U rack footprint. The Intel Xeon Gold 5218 processor includes 22 MB of cache and supports a second processor for future scalability, doubling the core count and memory capacity in a dual-CPU configuration. The memory subsystem uses DDR4 SDRAM technology and is Intel Optane Memory Ready for future performance-tiered memory solutions.
Storage flexibility is central to the design, with eight hot-swap 2.5" bays allowing for rapid drive replacement and capacity upgrades without downtime. The Smart Array P408i-a SR controller provides hardware RAID support for data protection and performance. Expansion capabilities include three PCIe Gen 3 slots (two x8 and one x16), with a standard configuration that can be upgraded to eight slots in a two-processor setup.
Key Product Advantages
The DL380 G10 balances performance, expandability, and manageability for modern data center demands. Its scalable architecture allows organizations to start with a single processor and 32 GB of RAM, then grow to a dual-processor configuration with up to 1.54 TB of memory as needs evolve. The hot-swap drive bays and power supplies enable maintenance and upgrades without interrupting server operations, critical for 24/7 environments.
Enterprise Storage Flexibility
Eight 2.5" hot-swap bays support both SATA and SAS drives, allowing mixed use for performance and capacity. The integrated Smart Array controller delivers hardware RAID for data redundancy and improved I/O performance.
- Supports SATA and SAS drives
- Hardware RAID acceleration
- Hot-swap for zero downtime maintenance
Advanced Remote Management
HPE iLO Standard provides full remote management capabilities, including power control, virtual media, and system health monitoring. Intelligent Provisioning simplifies OS deployment and configuration.
- Out-of-band server management
- Integrated virtual KVM
- Automated OS deployment
Power Efficiency & Reliability
An 800W hot-swappable power supply delivers efficient power with N+1 redundancy support. The server meets ENERGY STAR 3.0 standards and includes comprehensive security features like UEFI Secure Boot and firmware rollback protection.
- 80 PLUS efficient PSU
- Hot-swap power supply support
- Enterprise security features
Deployment / Use Cases
The ProLiant DL380 G10 is versatile enough for a range of business-critical applications. Its balance of compute, memory, and storage makes it well-suited for virtualization hosts, where multiple virtual machines can leverage the 16-core processor and expandable memory. Database servers benefit from the fast storage options and RAID protection for transaction integrity.
Additional use cases include application servers for ERP or CRM systems, file and print servers in medium to large organizations, and private cloud infrastructure. The server's remote management capabilities through HPE iLO make it ideal for distributed environments or data centers with limited physical access.
Virtualization Host
Run multiple virtual machines with the 16-core Xeon Gold processor and scalable memory. Support for major hypervisors including VMware vSphere, Microsoft Hyper-V, and Linux KVM.
- High core density for VMs
- Support for all major hypervisors
- Memory scalability to 1.54 TB
Database Server
Handle transactional and analytical workloads with fast storage options and hardware RAID. The server supports Windows Server and multiple Linux distributions for database platforms.
- RAID-protected storage
- Support for SQL Server, Oracle, MySQL
- Gigabit Ethernet for network connectivity
Physical Profile
Designed for standard 19-inch racks, the server occupies 2U of vertical space with dimensions of 3.44" (87.30 mm) in height, 17.54" (445.40 mm) in width, and 26.75" (679.40 mm) in depth. The compact 2U form factor maximizes rack density while providing ample internal expansion. The server weighs approximately 42.99 lb (19.5 kg) and includes integrated cable management arms for clean rack installation.
- Width
- 17.54" (445.40 mm)
- Depth
- 26.75" (679.40 mm)
- Height
- 2U
- Weight
- 42.99 lb (19500 g)
What's in the Box
The server ships with all necessary components for immediate rack installation and operation.
Highlights
- Intel Xeon Gold 5218 16-core processor at 2.30 GHz for high-performance computing
- 32 GB DDR4 memory installed with expansion to 1.54 TB across 24 DIMM slots
- Eight 2.5" hot-swap drive bays for flexible storage configurations
- HPE Smart Array P408i-a SR RAID controller with SATA and SAS support
- 2U rack form factor with dimensions optimized for data center density
- HPE iLO Standard remote management with Intelligent Provisioning
- 800W hot-swappable power supply with efficiency certification
- Support for Windows Server, Linux, and virtualization platforms
- Comprehensive security features including UEFI Secure Boot and firmware protection
- Three-year warranty with onsite support and next business day response
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P20249291 |
| Brand Name | HPE |
| Product Line | ProLiant |
| Product Series | DL380 G10 |
| Product Name | ProLiant DL380 G10 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon Gold |
| Processor Generation | 2nd Gen |
| Processor Model | 5218 |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Speed | 2.30 GHz |
| Cache | 22 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 1.54 TB |
| Memory Technology | DDR4 SDRAM |
| Total Number of Memory Slots | 24 |
| Number of Occupied Memory Slots | 1 |
| Intel Optane Memory Ready | Yes |
| Controllers | |
| Controller Type | Serial ATA/600,12Gb/s SAS |
| Controller Model | Smart Array P408i-a SR |
| RAID Supported | Yes |
| I/O Expansions | |
| Number of External 5.25" Bays | 1 |
| Number of Internal 2.5" Bays | 8 |
| Number of SFF Bays | 8 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 3 |
| PCI Express x8 (Gen 3.x) Slots | 2 |
| PCI Express x16 (Gen 3.x) Slots | 1 |
| PCI Express Details | 3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2 processor configuration |
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 5 |
| Number of USB 3.0 Ports | 5 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Remote Management Controller | HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView Advanced (require licenses) |
| Operating System | |
| Operating System Supported | Windows Server 2019 Standard,Windows Server 2019 Essentials,Windows Server 2019 Datacenter,Windows Server 2016 Standard,Windows Server 2016 Essential,Windows Server 2016 Datacenter,Hyper-V,Red Hat Enterprise Linux 7.6,Red Hat Enterprise Linux 8,SUSE Linux Enterprise Server 12,SuSE Linux Enterprise Server 15,Windows Server 2012 R2 Standard,Windows Server 2012 R2 Essentials,Windows Server 2012 R2 Datacenter |
| Power Description | |
| Input Voltage | 230 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Plug/Connector Type | C13/C14 |
| Maximum Power Supply Wattage | 800 W |
| Hot Swappable Power Supply | Yes |
| Miscellaneous | |
| Package Contents | ProLiant DL380 G10 Server SFF Easy Install Rails with Cable Management Arm |
| Security Features | UEFI Secure Boot and Secure Start support Tamper-free updates - components digitally signed and verified Immutable Silicon Root of Trust Ability to rollback firmware FIPS 140-2 validation Secure erase of NAND/User data Common Criteria certification Configurable for PCI DSS compliance Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser Support for Commercial National Security Algorithms (CNSA) Secure Recovery - recover critical firmware to known good state on detection of compromised firmware |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 3.0 |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 3.44" (87.30 mm) |
| Width | 17.54" (445.40 mm) |
| Depth | 26.75" (679.40 mm) |
| Weight (Approximate) | 42.99 lb (19500 g) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
User Manual
FAQ
What processor is installed in this HPE DL380 G10 server?
This server comes with one Intel Xeon Gold 5218 processor installed. This is a 2nd generation Xeon Gold CPU with 16 cores (hexadeca-core) running at a base clock speed of 2.30 GHz and featuring 22 MB of cache. The server supports a second processor for future expansion, allowing you to double the core count and performance in a dual-CPU configuration.
How much memory does this server have and can it be expanded?
The server includes 32 GB of DDR4 SDRAM memory installed in one of 24 available memory slots. This provides substantial capacity for most workloads while leaving 23 slots open for expansion. The system supports up to 1.54 TB of total memory when fully populated with compatible DIMMs, making it highly scalable for memory-intensive applications like virtualization and large databases.
What type of storage bays does this server have?
This DL380 G10 configuration features eight internal 2.5" small form factor drive bays that are hot-swappable. These bays support both Serial ATA/600 and 12Gb/s SAS drives, giving you flexibility to choose between capacity-optimized SATA drives or performance-oriented SAS drives. The hot-swap capability allows you to replace or add drives without powering down the server.
Does this server include RAID support?
Yes, the server includes an HPE Smart Array P408i-a SR RAID controller that provides hardware RAID support. This controller manages both SATA and SAS drives and offers RAID levels for data protection and performance optimization. Hardware RAID offloads RAID processing from the main CPU, improving overall system performance for storage-intensive operations.
What remote management features are included?
The server comes with HPE iLO Standard remote management embedded in the system. This includes Intelligent Provisioning for simplified operating system deployment and configuration. iLO provides out-of-band management capabilities such as power control, virtual media mounting, hardware health monitoring, and remote console access, allowing administrators to manage the server even when the operating system is not running.
What is the power supply configuration and efficiency?
This server includes one 800W hot-swappable power supply installed, with support for a second power supply for redundancy (N+1 configuration). The power supply uses a standard C13/C14 connector and operates at 230V AC input. It meets ENERGY STAR 3.0 efficiency standards and features hot-swap capability, allowing replacement without system downtime if a redundant configuration is implemented.
What processor or CPU is listed for this server or storage platform?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 2.30 GHz processor for everyday performance and multitasking.
