Lenovo 12SH002DUS ThinkCentre M90a Gen 5 All-in-One Computer - Intel Core i5-14500 vPro - 32GB RAM - 512GB SSD - 23. 8" FHD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At its core, the ThinkCentre M90a Gen 5 is powered by a 14th-generation Intel Core i5-14500 processor. This tetradeca-core (14-core) CPU operates at a base speed of 2.60 GHz with a maximum turbo frequency of 5.0 GHz, leveraging Intel vPro technology for advanced remote management and security capabilities. The system is built on an Intel Q670 chipset, ensuring stable performance and compatibility with modern peripherals.
Memory configuration includes 32 GB of DDR5 SDRAM running at 4800 MHz, arranged in a dual-channel setup (2 x 16 GB) for optimal bandwidth. Storage is handled by a 512 GB PCI Express NVMe 4.0 x4 SSD in the M.2 form factor, delivering rapid boot times, fast application loading, and efficient data access. An integrated DVD-Writer optical drive supports DVD±RW media for legacy data and media needs.
Key Product Advantages
This all-in-one desktop excels in environments where space efficiency, performance, and manageability are critical. Its integrated design reduces cable clutter and simplifies setup, while the powerful hardware ensures smooth operation across a wide range of business applications.
Enhanced Visuals and Productivity
The 23.8-inch Full HD display provides crisp, clear visuals with a brightness of 250 cd/m², ideal for extended work sessions. Features like Low Blue Light and flicker-free technology help reduce eye strain, while the NVIDIA GeForce MX570A discrete graphics card accelerates multimedia tasks, video editing, and light graphical work with 4 GB of dedicated GDDR6 memory.
Comprehensive Connectivity
Connectivity options include seven USB ports (three USB 3.2 Gen 1, three USB 3.2 Gen 2, and one USB-C with 15W charging), Gigabit Ethernet, Wi-Fi 6 (802.11ax), and Bluetooth. This extensive port selection supports peripherals, external storage, and networking needs without requiring additional adapters.
Business-Ready Security and Management
With Intel vPro technology and Windows 11 Pro, this system offers robust security features, remote management capabilities, and enhanced data protection. The built-in webcam includes a physical privacy shutter for added security, and the system is backed by a 3-year onsite warranty for reliable support.
Deployment / Use Cases
The ThinkCentre M90a Gen 5 is well-suited for corporate offices, educational institutions, healthcare settings, and retail environments where a compact, all-in-one form factor is advantageous. Its performance profile makes it ideal for general office productivity, customer service kiosks, digital signage, and light creative work.
In office deployments, this desktop handles multitasking across business applications, video conferencing, and data analysis with ease. For educational or training rooms, the integrated display and robust connectivity simplify setup and maintenance. The inclusion of a VESA mount and UltraFlex V stand allows for flexible placement on desks or wall mounting, adapting to various workspace configurations.
Corporate Workstations
Deploy as primary workstations for employees needing reliable performance, security features, and a clutter-free desk setup. The vPro technology enables IT departments to manage and secure devices remotely.
Front-Office and Customer-Facing Roles
Use in reception areas, retail points of sale, or healthcare check-in stations where space is limited and a professional appearance is important. The all-in-one design integrates seamlessly into countertops or kiosks.
Localization and Operating System
This system comes pre-installed with Windows 11 Pro, providing a modern, secure operating system optimized for business use. The OS language is set to English, offering a familiar interface for users in English-speaking regions or international offices.
Keyboard localization is English, ensuring compatibility with standard QWERTY layouts and reducing the need for additional configuration. Windows 11 Pro includes features like BitLocker encryption, remote desktop access, and enhanced update management, supporting compliance and IT governance in organizational environments.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkCentre M90a Gen 5 features a sleek, black all-in-one design with dimensions of 21.24 inches wide, 18.58 inches high, and 9.94 inches deep. It weighs approximately 17.26 pounds, making it stable yet manageable for placement on desks or mounting. The included UltraFlex V stand offers tilt adjustment for ergonomic viewing, and the VESA mount compatibility allows for wall or arm mounting to save desk space.
- Width
- 21.24" (539.60 mm)
- Depth
- 9.94" (252.60 mm)
- Height
- 18.58" (472 mm)
- Weight
- 17.26 lb (7830 g)
What's in the Box
The package includes all essential components for immediate setup and use.
Highlights
- Intel Core i5-14500 processor with 14 cores, 20 threads, and vPro technology for powerful, manageable performance
- 32 GB of DDR5 RAM at 4800 MHz ensures smooth multitasking and responsiveness in demanding applications
- 512 GB NVMe SSD provides fast boot times, quick data access, and ample storage for essential files
- 23.8-inch Full HD display with 1920 x 1080 resolution delivers crisp visuals for productivity and multimedia
- NVIDIA GeForce MX570A discrete graphics with 4 GB GDDR6 memory accelerates graphical tasks and enhances visual quality
- Windows 11 Pro operating system offers advanced security, management features, and a modern user interface
- Comprehensive connectivity includes 7 USB ports, Wi-Fi 6, Bluetooth, and Gigabit Ethernet
- Built-in webcam with privacy shutter supports video conferencing while maintaining security
- Energy-efficient design with ENERGY STAR 8.0 certification and environmental compliance (EPEAT Gold, RoHS)
- 3-year onsite warranty provides reliable support and peace of mind for business deployments
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 12SH002DUS |
| Brand Name | Lenovo |
| Product Line | ThinkCentre |
| Product Series | M90a Gen 5 |
| Product Model | 12SH002DUS |
| Product Name | ThinkCentre M90a Gen 5 12SH002DUS All-in-One Computer |
| Product Type | All-in-One Computer |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core i5 |
| Processor Generation | 14th Gen |
| Processor Model | i5-14500 |
| Processor Core | Tetradeca-core (14 Core) |
| Processor Threads | 20 |
| Processor Speed | 2.60 GHz |
| Maximum Turbo Speed | 5 GHz |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | Q670 |
| Memory | |
| Standard Memory | 32 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Speed | 4800 MHz |
| Memory Configuration | 2 x 16GB |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| SSD Form Factor | M.2 |
| Optical Drive Type | DVD-Writer |
| Optical Media Supported | DVD±RW |
| Display & Graphics | |
| Screen Size | 23.8" |
| Screen Mode | Full HD |
| Screen Resolution | 1920 x 1080 |
| Touchscreen | No |
| Brightness | 250 cd/m² |
| Graphics Controller Manufacturer | NVIDIA |
| Graphics Controller Model | GeForce MX570A |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Technology | GDDR6 |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Built-in Devices | |
| Webcam | Yes |
| Camera Privacy Shutter | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports | 7 |
| Number of USB 3.2 Gen 1 Ports | 3 |
| Number of USB 3.2 Gen 2 Ports | 3 |
| USB Type-C (Rear) | Yes |
| USB Type-C Detail | 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 15W charging(rear) |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 230 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Desktop |
| Height | 18.58" (472 mm) |
| Width | 21.24" (539.60 mm) |
| Depth | 9.94" (252.60 mm) |
| Weight (Approximate) | 17.26 lb (7830 g) |
| Miscellaneous | |
| Package Contents | ThinkCentre M90a Gen 5 12SH002DUS All-in-One Computer USB Calliope Keyboard USB Calliope Mouse UltraFlex V Stand VESA mount |
| Features | Low Blue Light,Flicker-free,Security Slot |
| Energy Star | Yes |
| TCO Certified | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0,TCO Certified Edge |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 3 (ErP Lot 3) |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year, Onsite |
User Manual
FAQ
What processor does this Lenovo ThinkCentre M90a Gen 5 have?
This all-in-one computer is equipped with an Intel Core i5-14500 processor from the 14th generation. It features 14 cores and 20 threads, with a base speed of 2.60 GHz and a maximum turbo speed of 5.0 GHz. The processor includes Intel vPro technology, which enhances remote management and security capabilities for business environments.
How much memory and storage is included?
The system comes with 32 GB of DDR5 SDRAM running at 4800 MHz, configured as two 16 GB modules for dual-channel performance. For storage, it includes a 512 GB PCI Express NVMe 4.0 x4 SSD in the M.2 form factor, offering fast data transfer speeds and reliable storage for operating systems, applications, and files.
What are the display specifications?
The Lenovo ThinkCentre M90a Gen 5 features a 23.8-inch Full HD display with a resolution of 1920 x 1080 pixels. It has a brightness of 250 cd/m² and includes Low Blue Light and flicker-free technology to reduce eye strain. The display is non-touch and is paired with an NVIDIA GeForce MX570A discrete graphics card for enhanced visual performance.
What operating system is pre-installed?
This computer comes with Windows 11 Pro pre-installed in English. Windows 11 Pro provides advanced security features like BitLocker encryption, remote desktop access, and improved update management, making it suitable for business and professional use where data protection and IT management are priorities.
What connectivity options are available?
Connectivity includes seven USB ports: three USB 3.2 Gen 1 ports, three USB 3.2 Gen 2 ports, and one USB-C port on the rear that supports data transfer and 15W charging. The system also features Gigabit Ethernet, Wi-Fi 6 (802.11ax) for wireless networking, Bluetooth for peripheral connections, and an integrated DVD-Writer optical drive.
What is the warranty and environmental certification?
This Lenovo ThinkCentre M90a Gen 5 is backed by a 3-year onsite warranty, providing reliable support and service. It meets several environmental standards, including ENERGY STAR 8.0 for energy efficiency, EPEAT Gold, GREENGUARD, TCO Certified 9.0, and RoHS compliance, ensuring it is designed with sustainability and reduced environmental impact in mind.
