Lenovo 12V4000XUS ThinkCentre M90s Gen 5 Desktop - Intel Core i9-14900 - 64GB DDR5512GB NVMe SSD - Windows 11 Pro - Small Form Factor
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of this desktop is the Intel Q670 chipset, supporting the Core i9-14900 processor with Intel vPro technology for enhanced manageability and security. The memory subsystem utilizes four 16 GB DDR5 modules for a total of 64 GB at 4000 MHz, providing ample bandwidth for memory-intensive applications.
Storage is handled by a high-speed M.2 SSD using the PCI Express NVMe 4.0 x4 interface, delivering rapid boot times and fast data access. The system includes a DVD±RW optical drive for legacy media support and features comprehensive connectivity with nine USB ports, including USB 3.2 Gen 2 Type-C with 15W charging capability on the front panel.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This ThinkCentre desktop combines enterprise-grade performance with space-efficient design, making it ideal for environments where desk real estate is limited but computing power cannot be compromised. The small form factor chassis houses powerful components while maintaining professional aesthetics and robust construction.
Professional-Grade Performance
The Intel Core i9-14900 processor with 24 cores and 32 threads delivers workstation-level performance for demanding applications, supported by 64 GB of fast DDR5 memory.
- 24-core Intel Core i9-14900 processor
- 64 GB DDR5 @ 4000 MHz
- 512 GB PCIe NVMe 4.0 SSD
Comprehensive Connectivity
With nine USB ports including high-speed USB 3.2 Gen 2 Type-C, Gigabit Ethernet, Wi-Fi 6, and Bluetooth, this system offers flexible connection options for peripherals and networks.
- 9 USB ports total
- Front USB-C with 15W charging
- Wi-Fi 6 and Bluetooth
Deployment / Use Cases
The ThinkCentre M90s Gen 5 is well-suited for professional environments requiring reliable, high-performance computing in compact form factors. Its combination of powerful processing, substantial memory, and dedicated graphics makes it effective for engineering workstations, financial analysis stations, and creative production systems.
The small form factor design allows deployment in space-constrained settings such as reception desks, medical offices, retail point-of-sale stations, and educational computer labs. With Windows 11 Pro and Intel vPro technology, the system integrates smoothly into managed IT environments while providing the performance needed for demanding business applications.
Engineering & Design Workstation
The 24-core processor and dedicated graphics accelerate CAD, simulation, and 3D modeling applications while the compact design fits in crowded engineering labs.
Financial Analysis Station
64 GB of DDR5 memory handles large datasets and complex financial models, with the small form factor ideal for trading desks and analyst offices.
Localization and Operating System
This system comes pre-installed with Windows 11 Pro in English, providing a professional operating environment with enhanced security features, management capabilities, and productivity tools. The keyboard is localized for English language input, ensuring compatibility with standard keyboard layouts and typing conventions.
Windows 11 Pro includes BitLocker device encryption, Windows Information Protection, and enterprise-grade management features that integrate with existing IT infrastructure. The English language installation simplifies deployment in English-speaking business environments across North America and other regions using English as the primary business language.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkCentre M90s Gen 5 utilizes a space-efficient small form factor design measuring 13.37" high, 3.64" wide, and 11.72" deep, with a weight of approximately 11.68 pounds. The black chassis maintains professional aesthetics while the compact dimensions allow placement in various workspace configurations.
Despite its small size, the system includes comprehensive connectivity with front-accessible USB ports including a USB-C port with 15W charging capability. The form factor supports vertical or horizontal orientation, providing flexibility for different desk setups while maintaining optimal thermal performance for the high-performance components.
- Width
- 3.64" (92.50 mm)
- Depth
- 11.72" (297.70 mm)
- Height
- 13.37" (339.50 mm)
- Weight
- 11.68 lb (5300 g)
What's in the Box
The package includes the complete desktop system with all necessary components for immediate deployment.
Highlights
- Intel Core i9-14900 processor with 24 cores and 32 threads for high-performance computing
- 64 GB of DDR5 memory running at 4000 MHz for smooth multitasking
- 512 GB PCIe NVMe 4.0 SSD for fast boot times and rapid data access
- Intel Arc A310 LP dedicated graphics with 4 GB GDDR6 memory
- Windows 11 Pro operating system with English language
- Small form factor design saves desk space while delivering full desktop performance
- Wi-Fi 6 and Bluetooth for wireless connectivity
- Nine USB ports including front USB-C with 15W charging
- Intel vPro technology for enhanced manageability and security
- DVD±RW optical drive for legacy media support
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 12V4000XUS |
| Brand Name | Lenovo |
| Product Line | ThinkCentre |
| Product Series | M90s Gen 5 |
| Product Model | 12V4000XUS |
| Product Name | ThinkCentre M90s Gen 5 12V4000XUS Desktop Computer |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core i9 |
| Processor Generation | 14th Gen |
| Processor Model | i9-14900 |
| Processor Core | Tetracosa-core (24 Core) |
| Processor Threads | 32 |
| Processor Speed | 2 GHz |
| Maximum Turbo Speed | 5.80 GHz |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | Q670 |
| Memory | |
| Standard Memory | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Speed | 4000 MHz |
| Memory Configuration | 4 x 16GB |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| SSD Form Factor | M.2 |
| Optical Drive Type | DVD-Writer |
| Optical Media Supported | DVD±RW |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | Arc A310 LP |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Technology | GDDR6 |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 9 |
| Number of USB 3.2 Gen 1 Ports | 6 |
| Number of USB 3.2 Gen 2 Ports | 2 |
| USB Type-C (Front) | Yes |
| USB Type-C Detail | 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with 15W charging(front) |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 310 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Small Form Factor |
| Height | 13.37" (339.50 mm) |
| Width | 3.64" (92.50 mm) |
| Depth | 11.72" (297.70 mm) |
| Weight (Approximate) | 11.68 lb (5300 g) |
| Miscellaneous | |
| Package Contents | ThinkCentre M90s Gen 5 12V4000XUS Desktop Computer USB Traditional Keyboard USB Calliope Mouse |
| Features | Security Slot |
| Energy Star | Yes |
| TCO Certified | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),TCO Certified 9.0,GREENGUARD |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 3 (ErP Lot 3) |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year, Onsite |
User Manual
FAQ
What processor does this Lenovo ThinkCentre desktop use?
This desktop features the Intel Core i9-14900 processor from the 14th Gen family. It has 24 cores and 32 threads with a base clock speed of 2 GHz and maximum turbo frequency of 5.80 GHz. The processor includes Intel vPro technology for enhanced security and manageability in business environments.
How much memory is installed and what type is it?
The system comes with 64 GB of DDR5 SDRAM installed across four 16 GB modules. The memory operates at 4000 MHz, providing high bandwidth for memory-intensive applications. This configuration supports demanding multitasking scenarios and professional workloads that benefit from substantial RAM capacity.
What storage configuration does this desktop include?
Storage is provided by a 512 GB solid-state drive using the PCI Express NVMe 4.0 x4 interface in M.2 form factor. This high-speed SSD delivers fast boot times, rapid application loading, and quick file transfers. The system also includes a DVD±RW optical drive for reading and writing CDs and DVDs.
Does this system have dedicated graphics?
Yes, the desktop includes an Intel Arc A310 LP discrete graphics card with 4 GB of dedicated GDDR6 memory. This dedicated GPU accelerates multimedia tasks, supports multiple displays, and provides better performance for graphics-intensive applications compared to integrated graphics solutions.
What operating system is pre-installed?
The system comes with Windows 11 Pro pre-installed in English language. Windows 11 Pro includes enterprise features such as BitLocker encryption, Windows Information Protection, and enhanced security capabilities. It provides a stable, modern computing environment suitable for business and professional use cases.
What are the physical dimensions and form factor?
This ThinkCentre desktop uses a small form factor design measuring 13.37 inches in height, 3.64 inches in width, and 11.72 inches in depth. It weighs approximately 11.68 pounds. The compact black chassis saves desk space while housing high-performance components, making it suitable for space-constrained work environments.
