Lenovo 30E0011TCA ThinkStation P620 Workstation - Ryzen Threadripper Pro 5965WX 24-Core - 64 GB RAM - 2 TB NVMe SSD - Radeon Pro W6400 - Windows 11
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P620 is the AMD Ryzen Threadripper PRO 5965WX, a 24-core processor operating at 3.80 GHz on the Socket SP3 platform. This CPU, paired with the AMD WRX80 chipset, supports advanced memory and I/O configurations essential for workstation reliability and throughput.
The system includes 64 GB of DDR4 ECC Registered memory running at 3.20 GHz across eight slots, supporting error correction and registered signaling for data integrity in critical applications. Storage is handled by a 2 TB PCI Express NVMe SSD, offering high-speed data access, with SATA/600 controller support for RAID 0, 1, 5, and 10 configurations. Graphics are powered by the AMD Radeon Pro W6400 with 4 GB of dedicated GDDR6 memory, optimized for professional visualization and CAD workloads.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P620 combines workstation-class components with Lenovo's reliability engineering to deliver a system that excels in professional environments. Its expandable architecture and robust connectivity make it a versatile foundation for intensive computing tasks.
Professional-Grade Performance
The 24-core Ryzen Threadripper PRO processor and WRX80 chipset provide the multi-threaded horsepower needed for rendering, simulation, and data science workloads, reducing processing times and improving productivity.
- 24-core CPU for parallel tasks
- WRX80 chipset for PCIe 4.0 support
- ECC memory for data accuracy
Expansion and Reliability
With eight memory slots supporting up to 1 TB, multiple storage bays, and a 1 kW power supply, the P620 offers long-term upgradeability. ECC memory and registered DIMMs ensure stability in 24/7 operation.
- Up to 1 TB memory capacity
- RAID support for data redundancy
- 1 kW power for add-in cards
Professional Graphics and I/O
The AMD Radeon Pro W6400 delivers certified performance for CAD and content creation applications, while 10 Gigabit Ethernet and multiple USB 3.2 Gen 2 ports provide high-speed data transfer and network connectivity.
- 4 GB dedicated graphics memory
- 10GbE for network-intensive tasks
- USB-C for modern peripherals
Deployment / Use Cases
The ThinkStation P620 is ideally suited for technical professionals and organizations that require dependable high-performance computing. Its balanced configuration supports a wide range of demanding applications across multiple industries.
In engineering and design, the P620 accelerates 3D CAD modeling, finite element analysis, and architectural visualization. For media and entertainment, it handles video editing, animation rendering, and visual effects compositing. In scientific and financial sectors, the system performs complex data analysis, computational fluid dynamics, and quantitative modeling with precision. The tower form factor and extensive connectivity also make it suitable for server-room deployments where expansion and reliability are critical.
Engineering and Design Workstation
Run applications like AutoCAD, SolidWorks, and ANSYS with smooth viewport performance and reduced simulation times, thanks to the 24-core CPU and professional graphics.
Media Production and Rendering
Handle 4K video editing in DaVinci Resolve, 3D rendering in Blender or V-Ray, and real-time compositing with the high core count and fast NVMe storage.
Localization and Operating System
This ThinkStation P620 comes pre-installed with Windows 11 Pro 64-bit, providing a full-featured operating system tailored for business and professional use. Windows 11 Pro includes enhanced security features like BitLocker encryption, Windows Defender, and secure boot, along with productivity tools such as Remote Desktop and Hyper-V for virtualization.
The operating system leverages the 64-bit architecture to fully utilize the 64 GB of RAM and multi-core processor, ensuring optimal performance for memory-intensive applications. Windows 11 Pro also offers streamlined management through Group Policy and Azure AD integration, making it suitable for both standalone and networked deployments in corporate environments.
Physical Profile
The ThinkStation P620 uses a traditional tower form factor measuring 17.56" high, 6.50" wide, and 18.11" deep (446 x 165 x 460 mm), with a weight of approximately 52.91 lb (24 kg). This design provides ample internal space for additional storage drives, expansion cards, and cooling solutions, supporting long-term customization.
The chassis is built for durability and efficient thermal management, with tool-less access panels for easy maintenance and upgrades. The compact footprint relative to its expansion capabilities makes it suitable for desk-side or rack-mounted installations in office and data center environments.
- Width
- 6.50" (165 mm)
- Depth
- 18.11" (460 mm)
- Height
- 17.56" (446 mm)
- Weight
- 52.91 lb (24000 g)
Highlights
- AMD Ryzen Threadripper PRO 5965WX 24-core processor at 3.80 GHz
- 64 GB DDR4 ECC Registered memory, expandable to 1 TB across 8 slots
- 2 TB PCI Express NVMe SSD for high-speed storage and application loading
- AMD Radeon Pro W6400 graphics with 4 GB dedicated GDDR6 memory
- Windows 11 Pro 64-bit pre-installed for professional productivity and security
- 10 Gigabit Ethernet for high-speed network connectivity and data transfer
- 10 USB ports including 6x USB 3.2 Gen 2 and 2x USB-C 3.2 Gen 2
- Tower form factor with tool-less design for easy upgrades and maintenance
- 1 kW power supply supporting additional components and expansion cards
- 3-year limited warranty with 3YR Premier NBD service for reliable support
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30E0011TCA |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P620 |
| Product Model | 30E0011TCA |
| Product Name | ThinkStation P620 |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 5965WX |
| Processor Core | Tetracosa-core (24 Core) |
| Processor Speed | 3.80 GHz |
| Processor Socket | Socket SP3 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX80 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR4 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 3.20 GHz |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Graphics Controller Model | Radeon Pro W6400 |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 6 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x USB-C 3.2 Gen 2 |
| DisplayPort | Yes |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Architecture | 64-bit |
| Power Description | |
| Maximum Power Supply Wattage | 1 kW |
| Physical Characteristics | |
| Form Factor | Tower |
| Height | 17.56" (446 mm) |
| Width | 6.50" (165 mm) |
| Depth | 18.11" (460 mm) |
| Weight (Approximate) | 52.91 lb (24000 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | GREENGUARD |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3YR Premier NBD |
User Manual
FAQ
What processor does this ThinkStation P620 use, and how many cores does it have?
This workstation is equipped with an AMD Ryzen Threadripper PRO 5965WX processor, which features 24 cores (tetracosa-core) and operates at a base clock speed of 3.80 GHz. This high core count is designed for parallel processing tasks like 3D rendering, simulation, and data analysis, providing significant performance advantages in multi-threaded professional applications.
How much memory is installed, and what type of memory technology is used?
The system comes with 64 GB of DDR4 SDRAM installed, utilizing ECC (Error-Correcting Code) and Registered signal processing for enhanced data integrity and stability. Memory runs at 3.20 GHz, and the workstation has eight total memory slots, supporting expansion up to 1 TB for memory-intensive workloads such as virtualization or large dataset processing.
What storage configuration is included, and does it support RAID?
Storage includes a 2 TB PCI Express NVMe solid-state drive, offering fast boot times and rapid data access for applications and files. The workstation supports RAID configurations 0, 1, 5, and 10 via its Serial ATA/600 controller, allowing for performance optimization or data redundancy through multiple drives, though additional drives would need to be installed separately.
What graphics card is installed, and is it suitable for professional applications?
Graphics are handled by an AMD Radeon Pro W6400 with 4 GB of dedicated GDDR6 memory. This is a professional-grade GPU certified for CAD, content creation, and visualization software, providing reliable performance and driver support for applications like AutoCAD, SolidWorks, and Adobe Creative Suite, making it ideal for engineering and design work.
What operating system comes pre-installed, and what are its key features?
The workstation comes with Windows 11 Pro 64-bit pre-installed. This operating system includes professional features such as BitLocker encryption for data security, Remote Desktop for remote access, Hyper-V for virtualization, and enhanced management tools via Group Policy. It is optimized to leverage the 64 GB of RAM and multi-core processor for maximum performance in business environments.
What connectivity options are available, including networking and USB ports?
Connectivity includes 10 Gigabit Ethernet for high-speed network access, ideal for data-intensive tasks or server connections. For peripherals, there are 10 USB ports total: 6 USB 3.2 Gen 2 ports, 2 USB-C 3.2 Gen 2 ports, and 2 USB 2.0 ports, along with DisplayPort output for monitors. This setup supports fast data transfer and modern devices in professional settings.
