Lenovo 30F30042US ThinkStation P7 Workstation - Xeon w5-3433 16-Core - 16 GB RAM - 512 GB NVMe SSD - Windows 11 Pro for Workstations
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P7 is the Intel Xeon w5-3433 processor, a hexadeca-core CPU operating at 2 GHz on the Socket LGA-4677 platform. This processor supports Intel vPro technology, providing enhanced security, remote management capabilities, and hardware-based stability features essential for enterprise deployment.
The system utilizes the Intel W790 chipset to manage its high-bandwidth components. Memory is handled by 16 GB of DDR5 SDRAM running at 4.80 GHz with ECC (Error-Correcting Code) and registered signal processing for maximum data integrity in critical applications. Storage is delivered through a 512 GB PCI Express NVMe 4.0 x4 solid-state drive, offering exceptional read/write speeds for operating system and application loading.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P7 combines enterprise-grade reliability with workstation-class performance. Its architecture is specifically designed to handle sustained heavy computational loads without thermal throttling or stability issues, making it suitable for 24/7 operation in research, engineering, and creative professional environments.
Enterprise Management Ready
Intel vPro technology enables IT administrators to perform remote diagnostics, maintenance, and security management, reducing onsite support requirements and minimizing downtime.
- Remote management capabilities
- Hardware-enhanced security
- Out-of-band management support
High-Bandwidth Connectivity
Dual Ethernet support includes both standard Gigabit and 10 Gigabit interfaces for high-speed network transfers, while multiple USB 3.2 Gen 2 and USB-C ports provide versatile peripheral connectivity.
- 10 Gigabit Ethernet for fast data transfer
- Multiple high-speed USB ports
- Wireless LAN and Bluetooth included
Deployment / Use Cases
This workstation is ideally suited for professional environments where computational power and data integrity are paramount. Its balanced configuration of multi-core processing, ECC memory, and fast NVMe storage makes it effective across multiple demanding use cases.
In engineering and architectural firms, the system can handle complex CAD/CAM designs and finite element analysis. For media production studios, it provides the horsepower for 4K video editing, 3D animation rendering, and audio production workflows. Research institutions benefit from its ability to process large datasets and run scientific simulations, while financial analysts can leverage its processing power for quantitative modeling and data analysis.
Engineering & Design
Run demanding CAD applications like AutoCAD, SolidWorks, and CATIA with smooth viewport performance and rapid model regeneration.
Media Production
Handle 4K video editing in Adobe Premiere Pro, 3D rendering in Blender or Maya, and complex audio production in digital audio workstations.
Localization and Operating System
The workstation comes pre-installed with Windows 11 Pro for Workstations, Microsoft's premium operating system designed for high-performance computing. This edition includes features like support for up to 4 CPUs and 6 TB of memory, ReFS file system for data integrity, and persistent memory support.
Both the operating system and keyboard are localized for English-speaking markets. The English-language Windows 11 Pro for Workstations provides a familiar interface for users in North America, the UK, Australia, and other English-dominant regions, with all system prompts, menus, and documentation presented in English.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P7 utilizes a substantial tower form factor measuring 17.10" in height, 6.89" in width, and 20" in depth (434.40 mm × 175 mm × 508 mm). With an approximate weight of 54.01 lb (24.5 kg), this workstation is designed for stationary placement in office environments, server rooms, or dedicated workstation areas.
The chassis provides ample internal space for component upgrades and optimal airflow to maintain thermal performance during extended computational tasks. The substantial power supply unit rated at 1.40 kW ensures stable power delivery even under maximum load conditions.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 54.01 lb (24500 g)
What's in the Box
The workstation ships complete with all essential components for immediate deployment.
Highlights
- Intel Xeon w5-3433 processor with 16 cores and 32 threads for demanding computational workloads
- 16 GB of DDR5 ECC registered memory running at 4.80 GHz for data integrity and performance
- 512 GB PCI Express NVMe 4.0 x4 SSD for fast operating system and application loading
- Windows 11 Pro for Workstations pre-installed with English language localization
- Intel vPro technology for enhanced security and remote management capabilities
- Dual Ethernet with both Gigabit and 10 Gigabit interfaces for flexible networking
- 10 USB ports including multiple USB 3.2 Gen 2 and USB-C connections
- Wireless LAN and Bluetooth for wireless connectivity options
- 3-year limited warranty with onsite service included
- EPEAT Gold and TCO Certified 9.0 environmental certifications
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30F30042US |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P7 |
| Product Model | 30F30042US |
| Product Name | ThinkStation P7 30F30042US |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | w5-3433 |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Threads | 32 |
| Processor Speed | 2 GHz |
| Processor Socket | Socket LGA-4677 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W790 |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 1 x 16GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | Serial ATA,NVMe |
| RAID Supported | No |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C® 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro for Workstations |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 54.01 lb (24500 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P7 30F30042US Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What type of processor does this workstation use?
This Lenovo ThinkStation P7 workstation features an Intel Xeon w5-3433 processor. This is a hexadeca-core (16-core) CPU with 32 threads, operating at a base frequency of 2 GHz. It utilizes the Socket LGA-4677 platform and includes Intel vPro technology for enhanced security and remote management capabilities in business environments.
How much memory is installed and what type is it?
The workstation comes with 16 GB of DDR5 SDRAM installed. This is ECC (Error-Correcting Code) registered memory running at 4.80 GHz. The system has 8 memory slots total and currently uses a 1 x 16GB configuration, leaving 7 slots available for expansion up to a maximum supported capacity of 1 TB.
What storage configuration does this workstation have?
Storage is provided by a 512 GB solid-state drive using the PCI Express NVMe 4.0 x4 interface. This NVMe SSD delivers significantly faster data transfer speeds compared to traditional SATA drives, resulting in quicker operating system boot times, faster application loading, and improved overall system responsiveness for storage-intensive tasks.
What operating system is pre-installed?
The workstation comes with Windows 11 Pro for Workstations pre-installed. This is Microsoft's premium workstation edition of Windows 11, specifically optimized for high-performance computing tasks. It includes features like support for larger memory configurations, the ReFS file system for data integrity, and persistent memory support. The operating system is localized in English.
What connectivity options are available?
The workstation offers comprehensive connectivity with 10 USB ports total, including 2 USB 2.0 ports, 5 USB 3.2 Gen 2 ports, 2 USB-C 3.2 Gen 2 ports, and 1 USB-C port supporting 20Gbps transfer speeds. For networking, it includes both Gigabit Ethernet and 10 Gigabit Ethernet interfaces, plus Wireless LAN and Bluetooth capabilities for wireless connectivity options.
What warranty coverage is included with this workstation?
Lenovo provides a 3-year limited warranty for this ThinkStation P7 workstation. The warranty includes onsite service, meaning a technician will come to your location for repairs if needed. There's also an upgrade option available to 3-year Premier Support, which extends beyond the base onsite coverage to include additional support features and services.
