Lenovo 30F3004DUS ThinkStation P7 Workstation - Xeon w5-3425 3. 20 GHz - 64 GB DDR5 - 2 TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P7 is the Intel Xeon w5-3425 processor, a 12-core, 24-thread CPU operating at 3.20 GHz on the LGA-4677 socket. This processor supports Intel vPro technology for enhanced security and remote manageability in business environments. The platform is paired with 64 GB of DDR5 SDRAM running at 4.80 GHz, configured across four of the eight available memory slots, with support for up to 1 TB of total memory capacity.
Storage is handled by a 2 TB PCI Express NVMe 4.0 x4 solid-state drive, offering high sequential read/write speeds for rapid file access and application loading. The system includes a dedicated graphics controller with 16 GB of dedicated memory, suitable for GPU-accelerated tasks in CAD, rendering, and simulation software.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P7 combines workstation-grade components with Lenovo's reliability engineering to deliver a stable platform for professional use. Its expandable architecture and robust connectivity make it suitable for both standalone and networked deployment in technical environments.
Professional-Grade Memory
64 GB of DDR5 ECC Registered memory ensures data integrity and high bandwidth for memory-intensive applications, with error-checking and correction for critical workloads.
- ECC protection
- Registered DIMMs
- 8-slot expandability
High-Speed Storage & I/O
The 2 TB NVMe SSD provides low-latency storage, while multiple USB 3.2 Gen 2 and USB-C ports support fast peripheral connectivity and data transfer.
- PCIe 4.0 interface
- USB 20Gbps support
- 10 Gigabit Ethernet
Deployment / Use Cases
This workstation is designed for environments where computational power, data integrity, and system stability are paramount. Its hardware configuration supports a range of professional applications that benefit from multi-core processing, large memory capacity, and accelerated graphics.
Common deployment scenarios include engineering design and simulation, where the Xeon processor and ECC memory ensure accurate calculations; media production and 3D rendering, leveraging the dedicated GPU and fast storage; and scientific research or financial modeling, handling large datasets and complex algorithms.
Engineering & CAD
Run applications like AutoCAD, SolidWorks, or ANSYS with the precision and reliability required for design validation and finite element analysis.
Content Creation & Visualization
Accelerate video editing, 3D animation, and visual effects workflows with the combination of CPU power, GPU memory, and high-speed storage.
Localization and Operating System
The system ships with Windows 11 Pro for Workstations pre-installed in English. This edition includes features for high-performance computing, such as support for larger memory configurations, persistent memory, and advanced hardware management. The keyboard is localized for English, matching the operating system language for a consistent user experience.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P7 chassis measures 17.10" in height, 6.89" in width, and 20" in depth, with an approximate weight of 54.01 lb. This tower form factor provides ample internal space for component upgrades and cooling, making it suitable for desk-side or under-desk placement in office and lab environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 17.10" (434.40 mm), 6.89" (175 mm), 20" (508 mm), 54.01 lb (24500 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 54.01 lb (24500 g)
What's in the Box
The package includes the ThinkStation P7 30F3004DUS workstation, a keyboard, and a mouse, providing the essential components for immediate setup and use.
Package contents include ThinkStation P7 30F3004DUS Keyboard Mouse, ThinkStation P7 30F3004DUS. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Xeon w5-3425 processor with 12 cores and 24 threads for multi-threaded performance
- 64 GB of DDR5 ECC Registered memory ensures data integrity and high bandwidth
- 2 TB PCI Express NVMe 4.0 x4 SSD delivers fast storage access and application loading
- Dedicated 16 GB graphics memory supports GPU-accelerated professional applications
- Dual Ethernet with Gigabit and 10 Gigabit connectivity for high-speed networking
- Windows 11 Pro for Workstations pre-installed for optimized hardware management
- 1.40 kW power supply provides stable energy delivery for demanding workloads
- 3-year Onsite Premier Support warranty for reliable business deployment
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30F3004DUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P7 |
| Product Model | 30F3004DUS |
| Product Name | ThinkStation P7 30F3004DUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | w5-3425 |
| Processor Core | Dodeca-core (12 Core) |
| Processor Threads | 24 |
| Processor Speed | 3.20 GHz |
| Processor Socket | Socket LGA-4677 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W790 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | Serial ATA,NVMe |
| RAID Supported | No |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 16 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 1x USB-C (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only; 2 x USB-C 3.2 Gen 2 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro for Workstations |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 54.01 lb (24500 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P7 30F3004DUS Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year, Onsite 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does the Lenovo ThinkStation P7 30F3004DUS use?
This workstation features an Intel Xeon w5-3425 processor, a 12-core, 24-thread CPU operating at 3.20 GHz on the LGA-4677 socket. It includes Intel vPro technology for enhanced security and remote management capabilities in business environments.
How much memory is installed, and what type is it?
The system comes with 64 GB of DDR5 SDRAM installed, configured as 4 x 16 GB modules running at 4.80 GHz. This is ECC Registered memory, which provides error-checking and correction for data integrity in critical applications, with eight total slots supporting expansion up to 1 TB.
What storage configuration does this workstation have?
Storage is handled by a 2 TB solid-state drive using the PCI Express NVMe 4.0 x4 interface. This provides high sequential read/write speeds for fast file access, application loading, and data transfer, suitable for large project files and datasets.
Does this system include dedicated graphics?
Yes, the ThinkStation P7 includes a dedicated graphics controller with 16 GB of dedicated memory. This supports GPU-accelerated tasks in professional applications like CAD, 3D rendering, simulation, and video editing, enhancing performance for visual workloads.
What networking and connectivity options are available?
The workstation offers dual Ethernet with Gigabit and 10 Gigabit ports for high-speed wired networking, along with Wireless LAN and Bluetooth for wireless connectivity. It includes 10 USB ports total, with five USB 3.2 Gen 2 ports and three USB-C ports, including one supporting 20 Gbps data transfer.
What operating system and warranty come with this workstation?
The system ships with Windows 11 Pro for Workstations pre-installed in English, optimized for high-performance computing. It includes a 3-year Onsite Premier Support warranty, providing onsite service and support for reliable deployment in business and professional environments.
