Lenovo 30GA004DUS ThinkStation P5 Workstation - Intel Xeon w3-2425 3 GHz - 32 GB DDR5 - 1 TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P5 is the Intel Xeon w3-2425 processor, a hexa-core CPU operating at 3 GHz with 12 threads and Socket LGA-4677 compatibility. This processor supports Intel vPro technology for enhanced security and remote management capabilities in business environments.
The memory subsystem utilizes DDR5 SDRAM technology running at 4.80 GHz with ECC and Registered signal processing for data integrity. The workstation ships with 32 GB configured across two of eight available slots, supporting expansion up to 512 GB total capacity.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This workstation combines professional-grade components with Lenovo's engineering expertise to deliver a balanced platform for technical computing. The system is designed to maintain performance under sustained loads while providing expansion headroom for future upgrades.
Enterprise Security & Management
Intel vPro technology provides hardware-based security features and remote management capabilities, allowing IT administrators to maintain and secure systems efficiently across distributed environments.
- Hardware-enhanced security
- Remote management support
- Business-grade reliability
High-Speed Storage Architecture
The PCI Express NVMe 4.0 x4 SSD interface delivers exceptional storage performance, significantly reducing load times for large files and improving overall system responsiveness during data-intensive operations.
- NVMe 4.0 interface
- 1 TB capacity
- Fast data transfer rates
Comprehensive Connectivity
With 10 USB ports including multiple USB 3.2 Gen 2 and USB-C connections, plus Gigabit Ethernet and wireless networking, the workstation supports diverse peripheral and network configurations.
- Multiple USB-C ports
- Gigabit Ethernet
- Wireless LAN & Bluetooth
Deployment / Use Cases
The ThinkStation P5 30GA004DUS is purpose-built for professional environments where computational power, data integrity, and system stability are paramount. Its balanced configuration makes it suitable for a range of technical applications.
Engineering and design teams will appreciate the dedicated graphics memory and processing power for CAD, CAM, and simulation software. Research and development departments can leverage the ECC memory and reliable platform for data analysis and scientific computing.
Engineering & Design Workloads
The combination of Xeon processing, dedicated graphics, and fast NVMe storage supports demanding applications like Autodesk AutoCAD, Dassault Systèmes SOLIDWORKS, and Siemens NX for product development and architectural design.
Scientific & Technical Computing
With ECC memory protection and stable platform architecture, this workstation handles data-intensive tasks in fields such as computational fluid dynamics, finite element analysis, and statistical modeling with confidence.
Localization and Operating System
This workstation ships with Windows 11 Pro for Workstations pre-installed in English language. This specialized edition of Windows includes features optimized for high-performance computing, including support for larger memory configurations, faster file systems, and enhanced reliability features.
The keyboard localization is English, matching the operating system language for a consistent user experience. The Windows 11 Pro for Workstations environment provides professional tools for creative and productivity workflows while maintaining enterprise security standards.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P5 utilizes a traditional tower form factor measuring 17.56" (446 mm) in height, 6.50" (165 mm) in width, and 17.87" (453.90 mm) in depth. With an approximate weight of 41.89 lb (19000 g), the chassis provides substantial internal space for component installation and cooling.
The tower design accommodates standard rack mounting options and offers accessible internal layout for maintenance and upgrades. The physical dimensions support adequate airflow for thermal management during extended operation under load.
- Width
- 6.50" (165 mm)
- Depth
- 17.87" (453.90 mm)
- Height
- 17.56" (446 mm)
- Weight
- 41.89 lb (19000 g)
What's in the Box
The workstation ships complete with essential components for immediate deployment in professional environments.
Highlights
- Intel Xeon w3-2425 hexa-core processor with 3 GHz base frequency
- 32 GB DDR5 SDRAM with ECC and Registered signal processing
- 1 TB PCI Express NVMe 4.0 x4 solid state drive
- Dedicated 16 GB graphics controller for visualization workloads
- Windows 11 Pro for Workstations operating system pre-installed
- Intel vPro technology for enhanced security and manageability
- 10 USB ports including multiple USB-C 3.2 Gen 2 connections
- Gigabit Ethernet, Wireless LAN, and Bluetooth connectivity
- 1 kW power supply for stable operation under load
- 3-year warranty with onsite support included
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30GA004DUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P5 |
| Product Model | 30GA004DUS |
| Product Name | ThinkStation P5 30GA004DUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | w3-2425 |
| Processor Core | Hexa-core (6 Core) |
| Processor Threads | 12 |
| Processor Speed | 3 GHz |
| Processor Socket | Socket LGA-4677 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W790 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 512 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | No |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 16 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro for Workstations |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1 kW |
| Physical Characteristics | |
| Height | 17.56" (446 mm) |
| Width | 6.50" (165 mm) |
| Depth | 17.87" (453.90 mm) |
| Weight (Approximate) | 41.89 lb (19000 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P5 30GA004DUS Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does the Lenovo ThinkStation P5 30GA004DUS workstation use?
This workstation features the Intel Xeon w3-2425 processor, a hexa-core CPU operating at 3 GHz with 12 threads. It utilizes Socket LGA-4677 and includes Intel vPro technology for enterprise security and remote management capabilities in business environments.
How much memory is installed and what type does this workstation support?
The system comes with 32 GB of DDR5 SDRAM installed across two memory modules (2 x 16 GB configuration). It supports ECC (Error-Correcting Code) and Registered signal processing for data integrity, with a total of 8 memory slots allowing expansion up to 512 GB maximum capacity.
What storage configuration does this ThinkStation P5 include?
Storage is provided by a 1 TB solid state drive using the PCI Express NVMe 4.0 x4 interface. This high-speed storage technology delivers fast data transfer rates ideal for loading large files and applications quickly in professional computing environments.
What operating system is pre-installed on this workstation?
The workstation ships with Windows 11 Pro for Workstations pre-installed in English language. This specialized edition includes features optimized for high-performance computing, supporting larger memory configurations and providing enhanced reliability for professional applications.
What connectivity options are available on the ThinkStation P5 30GA004DUS?
Connectivity includes 10 USB ports total, with 2 USB 2.0 ports, 5 USB 3.2 Gen 2 ports, and multiple USB-C connections including 2x USB-C 3.2 Gen 2 and 1x USB-C 20Gbps port. The system also features Gigabit Ethernet, Wireless LAN, and Bluetooth for comprehensive networking options.
What warranty coverage comes with this Lenovo workstation?
Lenovo provides a 3-year base warranty that includes onsite support. This coverage ensures professional technical assistance and hardware repair services at your location, minimizing downtime for critical workstation deployments in business environments.
