Lenovo 30H0006SUS ThinkStation P3 Tiny Workstation - Intel Core i9-14900 14th Gen - 16GB DDR5512GB NVMe SSD - NVIDIA T400 4GB - Windows 11 Pro - Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the heart of the ThinkStation P3 Tiny is the Intel Core i9-14900 processor, a 14th Gen chip with 24 cores (8 Performance-cores and 16 Efficient-cores) and 32 threads. Operating at a base frequency of 2 GHz with Intel Turbo Boost Max Technology 3.0 support, this CPU delivers exceptional single-threaded and multi-threaded performance for compute-intensive applications. The processor is paired with the Intel Q670 chipset, which provides platform stability and supports Intel vPro technology for enhanced security and remote manageability.
Memory performance is driven by 16 GB of DDR5 SDRAM running at 5600 MHz, configured as a single 16 GB module in one of two available slots. This allows for straightforward expansion up to 64 GB to accommodate growing workloads. Storage is handled by a 512 GB PCI Express NVMe 4.0 x4 SSD, which offers sequential read speeds up to 7000 MB/s for rapid boot times, application loading, and file transfers.
Key Product Advantages
The ThinkStation P3 Tiny combines workstation-class components with a remarkably small chassis, offering unique advantages for professionals who need powerful computing without sacrificing desk space. The dedicated NVIDIA T400 graphics card provides certified driver support for CAD, CAM, and visualization software, ensuring compatibility and stability in professional workflows.
Compact Powerhouse
Despite its tiny dimensions, this workstation packs a 24-core Intel Core i9 processor and dedicated NVIDIA graphics, delivering performance comparable to much larger systems.
- Ideal for space-constrained offices
- Easy to mount behind monitors or under desks
- Low-profile design blends into any environment
Professional-Grade Components
Every component is selected and tested for reliability in demanding workstation applications, from the Intel vPro platform to the ISV-certified NVIDIA graphics.
- Intel Q670 chipset for platform stability
- NVIDIA T400 with certified drivers
- DDR5 memory for bandwidth-intensive tasks
Comprehensive Connectivity
With 7 USB ports (including USB-C 10Gbps), HDMI, DisplayPort, Gigabit Ethernet, Wi-Fi, and Bluetooth, this system connects to all your peripherals and networks.
- Dual display support via HDMI and DisplayPort
- High-speed USB-C for modern devices
- Wireless connectivity built-in
Deployment / Use Cases
The ThinkStation P3 Tiny is engineered for professional environments where space is at a premium but performance cannot be compromised. Its compact form factor makes it particularly suitable for financial trading desks, healthcare imaging stations, engineering workbenches, and digital signage control points where traditional towers would be impractical.
For CAD and BIM professionals, the NVIDIA T400 graphics provide the necessary OpenGL acceleration for applications like AutoCAD, Revit, and SolidWorks. Data analysts and researchers benefit from the 24-core processor's parallel processing capabilities for statistical modeling and simulation workloads. The system's quiet operation and low thermal footprint also make it ideal for audio/video editing suites and broadcast control rooms where noise and heat must be minimized.
Engineering & Design
Run CAD, CAM, and visualization software with certified NVIDIA graphics drivers and ample processing power for complex models and renderings.
Financial & Trading
Handle multiple data streams and analytical applications simultaneously in space-constrained trading environments or branch offices.
Localization and Operating System
This workstation ships with Microsoft Windows 11 Pro pre-installed in English language. Windows 11 Pro includes BitLocker device encryption, Windows Defender Advanced Threat Protection, and remote desktop capabilities for secure enterprise deployment. The keyboard localization is configured for English (US) layout, with support for additional language packs available through Windows settings.
The operating system is fully activated and ready for domain joining or Azure Active Directory integration. Windows 11 Pro's modern interface and productivity features, combined with the hardware's performance capabilities, create an efficient platform for professional workflows.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring just 1.46 inches in height, 7.05 inches in width, and 7.20 inches in depth, the ThinkStation P3 Tiny occupies minimal desk space while offering full workstation capabilities. The all-black chassis features a professional aesthetic that blends seamlessly into office environments. At 3.09 pounds, the system is lightweight enough for wall mounting or portable deployment scenarios.
The included VESA mount allows for secure attachment to monitor arms or wall brackets, enabling clean cable management and optimal space utilization. Despite its compact size, the chassis provides adequate thermal design to maintain performance under sustained loads, with intelligent fan control that balances cooling with acoustic comfort.
- Width
- 7.05" (179 mm)
- Depth
- 7.20" (182.90 mm)
- Height
- 1.46" (37 mm)
- Weight
- 3.09 lb (1400 g)
What's in the Box
The workstation arrives ready for setup with all necessary components included.
Highlights
- Intel Core i9-14900 14th Gen processor with 24 cores and 32 threads
- 16 GB DDR5 memory running at 5600 MHz, expandable to 64 GB
- 512 GB PCI Express NVMe 4.0 x4 SSD for fast storage performance
- NVIDIA T400 dedicated graphics with 4 GB GDDR6 memory
- Windows 11 Pro operating system with English language
- Ultra-compact Tiny form factor (1.46" H x 7.05" W x 7.20" D)
- Comprehensive connectivity: 7 USB ports, HDMI, DisplayPort, Gigabit Ethernet, Wi-Fi, Bluetooth
- Intel vPro technology for enhanced security and manageability
- Includes VESA mount for flexible installation options
- 3-year warranty with onsite service
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30H0006SUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P3 |
| Product Model | 30H0006SUS |
| Product Name | ThinkStation P3 Tiny 30H0006SUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i9 |
| Processor Generation | 14th Gen |
| Processor Model | i9-14900 |
| Processor Core | Tetracosa-core (24 Core) |
| Processor Threads | 32 |
| Processor Speed | 2 GHz |
| Processor Socket | Socket LGA-1700 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | Q670 |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 2 |
| Memory Clock Speed | 5.60 GHz |
| Memory Configuration | 1 x 16GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Controller Model | T400 |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 4 |
| USB Type-C | Yes |
| USB Type-C Detail | 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only |
| DisplayPort | Yes |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 300 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Tiny |
| Height | 1.46" (37 mm) |
| Width | 7.05" (179 mm) |
| Depth | 7.20" (182.90 mm) |
| Weight (Approximate) | 3.09 lb (1400 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P3 Tiny 30H0006SUS Power Adapter Keyboard Mouse 1 x Vesa Mount |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | TCO Certified 9.0,Electronic Product Environmental Assessment Tool Gold (EPEAT Gold) |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 3 (ErP Lot 3) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does this ThinkStation P3 Tiny workstation use?
This workstation features the Intel Core i9-14900 processor from the 14th Gen family. It has 24 cores (8 Performance-cores and 16 Efficient-cores) and 32 threads, with a base clock speed of 2 GHz and support for Intel Turbo Boost Max Technology 3.0. The processor uses the LGA-1700 socket and includes Intel vPro technology for enterprise security and management features.
How much memory is installed and what type is it?
The system comes with 16 GB of DDR5 SDRAM installed as a single 16 GB module running at 5600 MHz. There are two memory slots total, allowing for expansion up to 64 GB by adding a second module. The memory uses a non-ECC configuration suitable for workstation applications where error correction is not required.
What graphics card is included and how much memory does it have?
This workstation includes the NVIDIA T400 dedicated graphics card with 4 GB of GDDR6 memory. The T400 is a professional-grade GPU that provides certified driver support for CAD, design, and visualization applications. With dedicated graphics memory, it can handle complex 3D models and rendering tasks without sharing system RAM.
What storage configuration does this workstation have?
Storage is provided by a 512 GB PCI Express NVMe 4.0 x4 solid-state drive. This NVMe SSD connects directly to the PCIe bus for maximum bandwidth, offering sequential read speeds up to 7000 MB/s. The drive uses the NVMe controller protocol for low latency and high input/output operations per second (IOPS) performance.
What operating system is pre-installed and what are the localization details?
The workstation comes with Microsoft Windows 11 Pro pre-installed in English language. Windows 11 Pro includes professional features like BitLocker encryption, remote desktop, and enhanced security controls. The keyboard is localized for English (US) layout, and additional language packs can be installed through Windows settings if needed.
What are the physical dimensions and weight of this Tiny workstation?
The ThinkStation P3 Tiny measures 1.46 inches in height, 7.05 inches in width, and 7.20 inches in depth (37 mm x 179 mm x 182.9 mm). It weighs approximately 3.09 pounds (1400 grams). This compact form factor makes it ideal for space-constrained environments, and it includes a VESA mount for flexible installation behind monitors or on walls.
