Lenovo 30HA001ECA ThinkStation P3 Ultra Small Workstation - Intel Core i9-13900T 13th Gen - 16GB DDR5 - 4 Slots - 2. 5GbE - Thunderbolt 4
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P3 30HA001ECA is the Intel Core i9-13900T processor, a 13th Gen 32-core CPU operating at 1.10 GHz on the Socket LGA-1700 platform. This processor, combined with the Intel W680 chipset, delivers advanced security features, remote management capabilities, and efficient power handling for professional workflows. The system supports a single processor installation with dedicated cooling to maintain optimal performance.
Memory architecture utilizes DDR5 SDRAM technology running at 4.80 GHz, providing faster data transfer rates and improved bandwidth over previous generations. The workstation comes configured with one 16 GB module, leaving three additional slots open for expansion up to the 128 GB maximum. Storage flexibility is offered through Serial ATA/600 and NVMe controllers, with hardware RAID 0 and 1 support for data redundancy or performance striping.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This workstation balances high-end compute power with a remarkably compact design, making it ideal for professional environments where desk space is limited but performance cannot be compromised. The 13th Gen Intel Core i9 processor provides more threads and higher effective clock speeds for faster multitasking and reduced render times in creative and engineering applications.
Compact Professional Power
The Ultra Small form factor delivers full workstation capabilities in a chassis measuring just 7.95" x 3.43" x 8.78", allowing deployment in tight spaces without performance trade-offs.
- Saves valuable desk or rack space
- Maintains full thermal performance
- Easy to position in multi-system setups
Modern Connectivity Suite
Dual Thunderbolt 4 ports enable high-speed data transfers, daisy-chaining of displays, and connection to external GPU enclosures, while 2.5 Gigabit Ethernet ensures network throughput keeps pace with data-intensive tasks.
- Thunderbolt 4 for 40 Gbps bandwidth
- 2.5GbE for faster file transfers
- Five USB 3.2 Gen 2 ports for peripherals
Enterprise-Grade Reliability
Built with workstation-specific components and validated for stability under continuous load, the system includes a 3-year warranty with Premier Support upgrade options for business-critical deployments.
- 3-year limited warranty
- Premier Support available
- TCO Certified 9.0 for sustainability
Deployment / Use Cases
The ThinkStation P3 30HA001ECA is designed for professional environments that require dependable computational performance in a space-efficient package. Its balance of processor power, memory bandwidth, and high-speed I/O makes it suitable for engineering workstations, financial modeling desks, media editing suites, and scientific research stations where multiple applications run concurrently.
In architectural and manufacturing firms, the workstation handles CAD, BIM, and finite element analysis software with the responsiveness needed for complex designs. Creative studios benefit from the Thunderbolt 4 connectivity for high-resolution video editing workflows and color-grading monitor arrays. The compact size allows deployment in trading floors, control rooms, or educational labs where multiple units must fit within limited footprints without sacrificing individual system capability.
Physical Profile
The Ultra Small form factor measures 7.95 inches in height, 3.43 inches in width, and 8.78 inches in depth (202 mm x 87 mm x 223 mm), with a weight of approximately 7.94 pounds (3600 grams). This compact design enables placement on desks, in rack shelves with appropriate mounting, or in other confined spaces where traditional tower workstations would not fit. The chassis is engineered for efficient airflow to maintain component temperatures during extended operation, ensuring reliability in professional settings.
- Width
- 3.43" (87 mm)
- Depth
- 8.78" (223 mm)
- Height
- 7.95" (202 mm)
- Weight
- 7.94 lb (3600 g)
What's in the Box
The package includes the ThinkStation P3 30HA001ECA workstation and a power adapter, providing everything needed for initial setup and operation.
Package contents include ThinkStation P3 30HA001ECA Workstation Power Adapter, ThinkStation P3 30HA001ECA Workstation. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Core i9-13900T 13th Gen 32-core processor for high-thread-count workloads
- 16 GB DDR5 SDRAM running at 4.80 GHz with four total memory slots
- Ultra Small form factor: 7.95" H x 3.43" W x 8.78" D for space-constrained deployments
- 2.5 Gigabit Ethernet and Gigabit Ethernet for high-speed network connectivity
- Two Thunderbolt 4 ports and five USB 3.2 Gen 2 ports for versatile peripheral support
- Serial ATA/600 and NVMe storage controllers with RAID 0 and 1 support
- Intel W680 chipset with advanced security and management features
- 3-year limited warranty with Premier Support upgrade options
- TCO Certified 9.0 and ENERGY STAR 8.0 compliant for sustainable IT
- Input voltage support for 120 V AC and 230 V AC operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HA001ECA |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P3 |
| Product Model | 30HA001ECA |
| Product Name | ThinkStation P3 30HA001ECA Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i9 |
| Processor Generation | 13th Gen |
| Processor Model | i9-13900T |
| Processor Core | Dotriaconta-core (32 Core) |
| Processor Speed | 1.10 GHz |
| Processor Socket | Socket LGA-1700 |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 128 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 4 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 1 x 16GB |
| Controllers | |
| Controller Type | Serial ATA/600,NVMe |
| RAID Supported | Yes |
| RAID Levels | 0, 1 |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet,Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 5 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| DisplayPort | Yes |
| Number of Thunderbolt 4 Ports | 2 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Physical Characteristics | |
| Form Factor | Ultra Small |
| Height | 7.95" (202 mm) |
| Width | 3.43" (87 mm) |
| Depth | 8.78" (223 mm) |
| Weight (Approximate) | 7.94 lb (3600 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P3 30HA001ECA Workstation Power Adapter |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does this Lenovo ThinkStation P3 workstation use?
This workstation features the Intel Core i9-13900T, a 13th Gen processor with 32 cores (dotriaconta-core) operating at a base speed of 1.10 GHz. It uses the Socket LGA-1700 platform and is paired with the Intel W680 chipset, providing advanced performance for demanding professional applications like 3D rendering, simulation, and data analysis.
How much memory is installed and what are the expansion options?
The system comes with 16 GB of DDR5 SDRAM installed in a single module, running at 4.80 GHz. It has four total memory slots, allowing expansion up to a maximum of 128 GB. This configuration supports adding three additional DDR5 modules to increase capacity for memory-intensive tasks such as virtualization, large dataset processing, or complex multimedia projects.
What storage interfaces and RAID capabilities does this workstation support?
Storage connectivity includes both Serial ATA/600 and NVMe controllers, supporting a mix of SATA and PCIe NVMe drives. The workstation offers hardware RAID support for levels 0 (striping for performance) and 1 (mirroring for redundancy), enabling flexible storage configurations for speed or data protection in professional environments.
What networking and connectivity ports are available?
Networking features 2.5 Gigabit Ethernet and Gigabit Ethernet ports for high-speed wired connections. The workstation includes five USB 3.2 Gen 2 ports for peripherals, two Thunderbolt 4 ports for ultra-fast data transfer and display connectivity, and DisplayPort output. This suite supports modern peripherals, external storage, and multi-monitor setups.
How compact is the Ultra Small form factor and where can it be deployed?
The chassis measures 7.95 inches in height, 3.43 inches in width, and 8.78 inches in depth (202 mm x 87 mm x 223 mm), weighing approximately 7.94 pounds. This compact size makes it suitable for desks, shelves, or rack mounting in space-constrained environments like trading floors, control rooms, design studios, or educational labs without sacrificing workstation performance.
What warranty and certifications come with this ThinkStation?
Lenovo provides a 3-year limited warranty for this workstation, with an available upgrade to 3Y Premier Support for enhanced service options. The system is TCO Certified 9.0 for environmental sustainability, ENERGY STAR 8.0 compliant for energy efficiency, and meets Restriction of Hazardous Substances (RoHS) standards, aligning with corporate responsibility goals.
