Lenovo 30HA006RUS ThinkStation P3 Ultra Workstation - Intel Core i9-14900 14th Gen - 64 GB DDR5 - 2 TB NVMe SSD - Windows 11 Pro - Ultra Small Form
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The workstation's technical foundation includes the Intel W680 chipset with vPro Technology for enhanced security, remote management, and hardware-based stability. The processor operates on the LGA-1700 socket, providing a modern platform for the 14th Gen Intel architecture.
Storage is handled by a PCI Express NVMe 4.0 x4 interface, delivering maximum throughput for the 2 TB solid-state drive. The system includes comprehensive connectivity with five USB 3.2 Gen 2 ports and two Thunderbolt 4 ports for high-speed data transfer and peripheral expansion. Networking capabilities cover both wired and wireless needs, featuring 2.5 Gigabit Ethernet, standard Gigabit Ethernet, Wi-Fi, and Bluetooth.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
Beyond raw performance, the ThinkStation P3 Ultra includes enterprise features like Intel vPro for out-of-band management and security, a 300 W power supply designed for stable operation under load, and environmental certifications including EPEAT Gold and ENERGY STAR 8.0 compliance.
Professional-Grade Performance
The Intel Core i9-14900 processor, combined with 64 GB of DDR5 RAM, provides the computational muscle required for complex simulations, 3D modeling, software development, and data analysis workflows.
- 24-core, 32-thread CPU architecture
- High-bandwidth DDR5 memory at 4.80 GHz
- Dedicated 8 GB graphics for accelerated tasks
Compact Professional Footprint
The Ultra Small form factor measures just 7.95" x 3.43" x 8.78", allowing the workstation to fit in space-constrained environments without sacrificing expansion or cooling.
- Desk-side or under-desk placement flexibility
- Maintains full workstation I/O and upgradeability
- Weighs 7.94 lb for easy relocation
Deployment / Use Cases
The system is equally suited for financial modeling and quantitative analysis, video editing and motion graphics production, and software development environments requiring compilation power and virtualization. Its compact size makes it ideal for office settings, lab benches, or broadcast control rooms where space is at a premium but professional computing resources are non-negotiable.
With Windows 11 Pro pre-installed, the workstation integrates seamlessly into existing IT infrastructures, supporting domain join, Group Policy, BitLocker encryption, and remote management protocols for streamlined enterprise deployment.
Engineering & Design Workstations
Deploy in mechanical engineering, architectural design, or product development teams where CAD, CAM, and finite element analysis software require sustained multi-core performance and reliable graphics acceleration.
Data Science & Research Computing
Use for statistical analysis, machine learning prototyping, and scientific computing where large datasets and parallel processing benefit from the high core count and fast NVMe storage.
Localization and Operating System
This workstation ships with a fully licensed copy of Windows 11 Pro in English, providing the professional feature set required for business and technical environments. The operating system includes advanced security tools, Hyper-V virtualization, and enterprise management capabilities.
Keyboard localization is configured for English (US) layouts, ensuring compatibility with standard input devices and user expectations in North American markets. The OS language setting aligns with the keyboard for a consistent user experience out of the box.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The Ultra Small form factor delivers a footprint of 3.43" wide by 8.78" deep, with a height of 7.95". This compact design allows the workstation to be positioned vertically or horizontally in tight spaces, such as on a desk shelf, in a media console, or mounted behind a display.
Weighing approximately 7.94 lb, the system remains portable enough for relocation between worksites or lab stations. The chassis is built to maintain thermal performance and acoustic levels appropriate for office environments, even under sustained processor and graphics loads.
- Width
- 3.43" (87 mm)
- Depth
- 8.78" (223 mm)
- Height
- 7.95" (202 mm)
- Weight
- 7.94 lb (3600 g)
What's in the Box
The workstation package includes the ThinkStation P3 Ultra SFF system (model 30HA006RUS), a keyboard, a mouse, and the power adapter necessary for operation. All components are supplied to get the system up and running immediately upon unboxing.
Highlights
- Intel Core i9-14900 14th Gen processor with 24 cores and 32 threads
- 64 GB of DDR5 SDRAM installed, expandable to 128 GB across four slots
- 2 TB PCI Express NVMe 4.0 x4 solid-state drive for fast storage
- Dedicated 8 GB graphics controller for accelerated visual workloads
- Ultra Small form factor measuring 7.95" H x 3.43" W x 8.78" D
- Windows 11 Pro operating system with English language and localization
- Comprehensive connectivity: 5x USB 3.2 Gen 2, 2x Thunderbolt 4, DisplayPort
- Dual networking: 2.5 Gigabit Ethernet and Gigabit Ethernet plus Wireless LAN and Bluetooth
- Intel vPro Technology and W680 chipset for security and manageability
- 3-year limited warranty with onsite service and Premier Support upgrade options
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HA006RUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P3 Ultra |
| Product Model | 30HA006RUS |
| Product Name | ThinkStation P3 Ultra SFF 30HA006RUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i9 |
| Processor Generation | 14th Gen |
| Processor Model | i9-14900 |
| Processor Core | Tetracosa-core (24 Core) |
| Processor Threads | 32 |
| Processor Speed | 2 GHz |
| Processor Socket | Socket LGA-1700 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 128 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 4 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 32GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 8 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet,Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 5 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| DisplayPort | Yes |
| Number of Thunderbolt 4 Ports | 2 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 300 W |
| Physical Characteristics | |
| Form Factor | Ultra Small |
| Height | 7.95" (202 mm) |
| Width | 3.43" (87 mm) |
| Depth | 8.78" (223 mm) |
| Weight (Approximate) | 7.94 lb (3600 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P3 Ultra SFF 30HA006RUS Keyboard Mouse Power Adapter |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does the Lenovo ThinkStation P3 Ultra 30HA006RUS use?
This workstation is equipped with an Intel Core i9-14900 processor from the 14th Gen family. It features a tetracosa-core (24-core) design with 32 threads and a base clock speed of 2 GHz, built on the Socket LGA-1700 platform. The CPU includes Intel vPro Technology for enhanced security and remote management capabilities in business environments.
How much memory is installed and what type is it?
The system comes with 64 GB of DDR5 SDRAM installed as two 32 GB modules. The memory operates at a clock speed of 4.80 GHz and uses a non-ECC configuration. There are four total memory slots, allowing for expansion up to a maximum of 128 GB if future upgrades are required for more demanding applications.
What storage configuration does this workstation have?
Storage is provided by a 2 TB solid-state drive using the PCI Express NVMe 4.0 x4 interface. This NVMe SSD delivers high sequential read and write speeds, significantly reducing load times for applications, project files, and the operating system. The storage controller supports both NVMe and Serial ATA protocols for flexibility.
What graphics capabilities are included?
The workstation includes a dedicated graphics controller with 8 GB of dedicated memory. This provides accelerated performance for professional visualization, rendering, and compute tasks compared to integrated graphics solutions. It supports multiple displays via the available DisplayPort and Thunderbolt 4 outputs.
What operating system is pre-installed?
The system ships with Windows 11 Pro already installed and activated. This is the English language version, aligned with the English keyboard localization. Windows 11 Pro includes features like BitLocker encryption, Hyper-V virtualization, remote desktop hosting, and enterprise management tools suitable for professional and business use.
What are the physical dimensions and form factor?
The ThinkStation P3 Ultra uses an Ultra Small form factor, with dimensions of 7.95 inches in height, 3.43 inches in width, and 8.78 inches in depth. It weighs approximately 7.94 lb. This compact design allows the workstation to fit in space-constrained environments while still providing full workstation performance and connectivity options.
