Lenovo 30HA006VUS ThinkStation P3 Ultra Workstation - Intel Core i7-14700K 14th Gen - 64 GB DDR5 RAM - 2 TB NVMe SSD - Ultra Small Form Factor
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P3 Ultra is the Intel Core i7-14700K processor, featuring 20 cores and 28 threads with a base clock speed of 3.40 GHz. This CPU, paired with Intel vPro technology, offers hardware-enhanced security and remote manageability for enterprise IT environments. The system supports up to 128 GB of DDR5 memory across four slots, with the installed 64 GB configuration running at 4.80 GHz for optimal data throughput.
Storage is handled by a 2 TB PCI Express NVMe 4.0 x4 solid-state drive, delivering exceptional read/write speeds for operating system, application, and project file loading. The workstation includes both NVMe and Serial ATA controller support for additional storage expansion. Graphics are handled via shared system memory, suitable for professional applications that leverage CPU compute power.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P3 Ultra combines workstation-grade performance with an exceptionally small footprint, making it ideal for space-constrained professional environments. Its Ultra Small form factor does not compromise on expansion, offering four memory slots and multiple high-speed storage and connectivity options.
Professional-Grade Connectivity
Equipped with five USB 3.2 Gen 2 ports, two Thunderbolt 4 ports, DisplayPort output, 2.5 Gigabit Ethernet, Gigabit Ethernet, Wi-Fi, and Bluetooth for comprehensive peripheral and network support.
- Five high-speed USB ports
- Dual Thunderbolt 4 for fast data transfer
- Dual Ethernet for network flexibility
Enterprise Management & Security
Intel vPro technology provides hardware-based security features and remote management capabilities, allowing IT teams to maintain, update, and secure systems efficiently across the organization.
- Hardware-enhanced security
- Remote manageability
- IT infrastructure integration
Deployment / Use Cases
This workstation is designed for professionals who require reliable, high-performance computing in compact office, lab, or studio settings. Its balanced configuration of CPU power, substantial memory, and fast storage makes it suitable for a range of intensive applications.
Ideal use cases include computer-aided design (CAD), financial modeling, software development, video editing, and scientific research. The small form factor allows for flexible placement under desks, in media consoles, or on shelves, while the professional connectivity supports multiple monitors, external storage arrays, and specialized input devices.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Localization and Operating System
The system comes pre-installed with Windows 11 Pro, providing a professional-grade operating system with enhanced productivity features, security controls, and compatibility with business software. The English-language OS and English-keyboard localization ensure immediate usability in North American and international English-speaking markets.
Windows 11 Pro includes BitLocker device encryption, remote desktop access, and support for domain join and group policy management, aligning with enterprise IT requirements. The out-of-box experience is streamlined for professional setup and integration into existing Windows-based networks.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P3 Ultra features an Ultra Small form factor measuring 7.95 inches in height, 3.43 inches in width, and 8.78 inches in depth, with an approximate weight of 7.94 pounds. This compact design minimizes desk space consumption while maintaining robust cooling and component accessibility.
The small footprint and relatively light weight facilitate easy deployment, relocation, and integration into various workspace configurations. The chassis is built to Lenovo's workstation durability standards, ensuring reliable operation in professional environments.
- Width
- 3.43" (87 mm)
- Depth
- 8.78" (223 mm)
- Height
- 7.95" (202 mm)
- Weight
- 7.94 lb (3600 g)
What's in the Box
The workstation package includes all essential components for immediate setup and operation.
Highlights
- Intel Core i7-14700K 14th Gen processor with 20 cores and 28 threads for high-performance computing
- 64 GB of DDR5 SDRAM running at 4.80 GHz for fast data handling in memory-intensive applications
- 2 TB PCIe NVMe 4.0 SSD provides rapid storage access and ample capacity for large project files
- Ultra Small form factor saves desk space while delivering full workstation capabilities
- Windows 11 Pro operating system with English language and keyboard localization
- Intel vPro technology enables enhanced security and remote management for enterprise IT
- Dual Thunderbolt 4 ports and five USB 3.2 Gen 2 ports for high-speed peripheral connectivity
- 2.5 Gigabit Ethernet and Gigabit Ethernet provide flexible wired network options
- Built-in Wi-Fi and Bluetooth support wireless connectivity for peripherals and networks
- Three-year limited warranty with onsite service and Premier Support upgrade options
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HA006VUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P3 Ultra |
| Product Model | 30HA006VUS |
| Product Name | ThinkStation P3 Ultra SFF 30HA006VUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i7 |
| Processor Generation | 14th Gen |
| Processor Model | i7-14700K |
| Processor Core | Icosa-core (20 Core) |
| Processor Threads | 28 |
| Processor Speed | 3.40 GHz |
| Processor Socket | Socket LGA-1700 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 128 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 4 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 32GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| Display & Graphics | |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet,Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 5 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| DisplayPort | Yes |
| Number of Thunderbolt 4 Ports | 2 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 300 W |
| Physical Characteristics | |
| Form Factor | Ultra Small |
| Height | 7.95" (202 mm) |
| Width | 3.43" (87 mm) |
| Depth | 8.78" (223 mm) |
| Weight (Approximate) | 7.94 lb (3600 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P3 Ultra SFF 30HA006VUS Power Adapter Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does the Lenovo ThinkStation P3 Ultra 30HA006VUS use?
This workstation features an Intel Core i7-14700K 14th Gen processor. It has 20 cores, 28 threads, and a base clock speed of 3.40 GHz. The processor includes Intel vPro technology for enterprise-grade security and manageability, making it suitable for demanding professional workloads like CAD, simulation, and data analysis.
How much memory is installed and what type is it?
The system comes with 64 GB of DDR5 SDRAM installed, configured as two 32 GB modules. The memory operates at 4.80 GHz and is installed in two of the four available memory slots. DDR5 technology provides higher bandwidth and efficiency compared to previous generations, supporting better performance in memory-intensive applications.
What storage capacity and type does this workstation have?
It includes a 2 TB PCI Express NVMe 4.0 x4 solid-state drive. This NVMe SSD offers significantly faster data transfer speeds than traditional SATA drives, reducing load times for applications and large files. The workstation also supports additional storage expansion through its available interfaces.
What operating system is pre-installed?
The ThinkStation P3 Ultra comes with Windows 11 Pro pre-installed in English. Windows 11 Pro provides professional features like BitLocker encryption, remote desktop, and group policy management, making it suitable for business and enterprise environments. The system is ready for immediate use with this OS configuration.
What are the physical dimensions and form factor?
This workstation has an Ultra Small form factor, measuring 7.95 inches in height, 3.43 inches in width, and 8.78 inches in depth. It weighs approximately 7.94 pounds. The compact size allows it to fit in space-constrained environments while still providing full workstation performance and connectivity.
What connectivity ports are available on this system?
The workstation includes five USB 3.2 Gen 2 ports, two Thunderbolt 4 ports, DisplayPort output, 2.5 Gigabit Ethernet, and Gigabit Ethernet. It also features built-in Wi-Fi and Bluetooth for wireless connectivity. These ports support high-speed data transfer, multiple displays, and a wide range of peripherals for professional workflows.
