Lenovo 30HH002TUS ThinkStation P8 Workstation - Ryzen Threadripper PRO 7945WX 12-Core - 64 GB DDR5 - 2 TB NVMe SSD - 16 GB Graphics - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The workstation's compute foundation is the AMD Ryzen Threadripper PRO 7945WX, a 12-core, 24-thread processor running at 4.70 GHz on the Socket sTR5 platform. This CPU is paired with the AMD WRX90 chipset, which supports advanced memory and I/O configurations. The memory subsystem uses DDR5 SDRAM technology with ECC and registered signal processing for data integrity in mission-critical applications.
Storage performance comes from a PCI Express NVMe 4.0 x4 solid-state drive with 2 TB capacity, delivering fast boot times and rapid data access. The system supports RAID configurations 0, 1, 5, and 10 through NVMe and Serial ATA controllers, allowing for data redundancy or performance optimization based on workload requirements.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This ThinkStation P8 workstation combines professional-grade components with enterprise management features to handle intensive workloads reliably. The Ryzen Threadripper PRO processor includes advanced security and remote management capabilities, while the ECC memory ensures data accuracy during extended computation sessions.
Professional Graphics Performance
The dedicated 16 GB graphics memory accelerates rendering, modeling, and visualization tasks in applications like AutoCAD, SolidWorks, and Adobe Creative Suite.
- 16 GB dedicated memory
- Accelerates professional applications
- Supports multiple displays
Enterprise Connectivity
Dual Ethernet with both Gigabit and 10 Gigabit ports provides high-speed network access for data-intensive workflows, while wireless LAN and Bluetooth offer flexible connectivity options.
- 10 Gigabit Ethernet for fast data transfer
- Wireless LAN for mobility
- Bluetooth for peripheral connectivity
Expansion Ready Platform
With 8 memory slots supporting up to 1 TB of DDR5, multiple storage bays, and comprehensive USB connectivity including high-speed USB-C ports, the workstation can be configured for future growth.
- 8 memory slots
- Up to 1 TB memory support
- Multiple USB 3.2 Gen 2 ports
Deployment / Use Cases
The ThinkStation P8 30HH002TUS is designed for professional environments where computational power and reliability are paramount. Its balanced configuration of high-core-count CPU, substantial memory, fast storage, and dedicated graphics makes it suitable for a range of demanding applications.
In engineering and design firms, this workstation handles CAD/CAM software, finite element analysis, and computational fluid dynamics simulations. Media production studios use it for video editing, 3D animation, and visual effects rendering where both CPU and GPU performance are critical. Research institutions leverage its processing power for data analysis, scientific computing, and machine learning workloads that benefit from high thread counts and large memory capacity.
Engineering & Design
Run applications like Autodesk Revit, Siemens NX, and Dassault Systèmes CATIA with smooth performance for complex modeling and simulation tasks.
Media & Entertainment
Accelerate video editing in Adobe Premiere Pro, 3D rendering in Blender or Maya, and compositing in After Effects with the dedicated graphics and fast storage.
Localization and Operating System
This workstation comes with Windows 11 Pro pre-installed in English language version, providing a familiar interface for business users. Windows 11 Pro includes advanced security features like BitLocker encryption, Windows Defender, and remote desktop capabilities for IT management.
The keyboard is localized for English (US) layout, ensuring compatibility with standard input methods. The operating system is optimized for the workstation hardware, with drivers configured for the AMD processor, chipset, and graphics components to deliver stable performance out of the box.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P8 features a tower form factor measuring 17.10" (434.40 mm) in height, 6.89" (175 mm) in width, and 20" (508 mm) in depth, with a weight of approximately 50.04 lb (22.7 kg). This substantial chassis provides ample internal space for component cooling and future expansion while maintaining a professional appearance suitable for office environments.
The design includes tool-less access for easy maintenance and upgrades. The 1.40 kW power supply ensures stable operation under full load conditions, supporting the high-performance components while maintaining energy efficiency with ENERGY STAR 8.0 certification.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation arrives ready for setup with all necessary components included for immediate operation.
Highlights
- AMD Ryzen Threadripper PRO 7945WX 12-core processor with 4.70 GHz speed
- 64 GB DDR5 SDRAM with ECC and registered signal processing for data integrity
- 2 TB PCI Express NVMe 4.0 x4 SSD for fast storage performance
- 16 GB dedicated graphics memory for accelerated visualization tasks
- Windows 11 Pro operating system with English language localization
- Dual Ethernet with Gigabit and 10 Gigabit ports for high-speed networking
- Wireless LAN and Bluetooth for flexible connectivity options
- 10 USB ports including USB-C 3.2 Gen 2 and 20Gbps variants
- 1.40 kW power supply with ENERGY STAR 8.0 efficiency certification
- 3-year warranty with onsite service and premier support upgrade options
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH002TUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH002TUS |
| Product Name | ThinkStation P8 30HH002TUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7945WX |
| Processor Core | Dodeca-core (12 Core) |
| Processor Threads | 24 |
| Processor Speed | 4.70 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 16 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH002TUS Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does this Lenovo ThinkStation P8 workstation use?
This workstation features the AMD Ryzen Threadripper PRO 7945WX processor, which has 12 cores and 24 threads running at 4.70 GHz. It uses the Socket sTR5 platform and is paired with the AMD WRX90 chipset for professional workstation performance in demanding applications like 3D rendering and engineering simulations.
How much memory is installed and what type does it use?
The system comes with 64 GB of DDR5 SDRAM installed as 4 x 16 GB modules. The memory features ECC (Error-Correcting Code) and registered signal processing for enhanced data integrity, which is crucial for mission-critical workloads. The memory runs at 4.80 GHz and the workstation has 8 total slots supporting expansion up to 1 TB.
What storage configuration does this workstation include?
This ThinkStation P8 includes a 2 TB solid-state drive using the PCI Express NVMe 4.0 x4 interface for high-speed data transfer. The storage system supports RAID configurations 0, 1, 5, and 10 through both NVMe and Serial ATA controllers, allowing for performance optimization or data redundancy based on your specific requirements.
What graphics capabilities does this workstation offer?
The workstation features a dedicated graphics controller with 16 GB of graphics memory. This dedicated GPU accelerates visualization tasks in professional applications like CAD software, 3D modeling tools, and video editing suites, providing smoother performance and faster rendering times compared to integrated graphics solutions.
What networking and connectivity options are available?
The workstation includes both Gigabit Ethernet and 10 Gigabit Ethernet ports for high-speed wired networking, along with Wireless LAN and Bluetooth for wireless connectivity. It has 10 USB ports total, including 2 USB 2.0, 5 USB 3.2 Gen 2, 2 USB-C 3.2 Gen 2, and 1 USB-C 20Gbps port for data transfer only.
What warranty and support comes with this ThinkStation P8?
This workstation includes a 3-year limited warranty with onsite service included. The warranty can be upgraded to 3-year premier support, which provides enhanced technical assistance and service options. The system also carries multiple environmental certifications including EPEAT Gold, GREENGUARD, TCO Certified 9.0, and ENERGY STAR 8.0 compliance.
