Lenovo 30HH0031US ThinkStation P8 Workstation - Ryzen Threadripper PRO 7945WX 12-Core 4. 7GHz - 64GB DDR5 - 2TB NVMe SSD - 32GB Graphics - Windows 11
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P8 is the AMD Ryzen Threadripper PRO 7945WX, a 12-core processor with 24 threads and a 4.70 GHz clock speed. It utilizes the Socket sTR5 platform and is paired with the AMD WRX90 chipset, providing a robust foundation for professional applications.
The memory subsystem features 64 GB of DDR5 SDRAM operating at 4.80 GHz, configured as four 16 GB modules. This ECC Registered memory ensures data integrity for critical computations. Storage is handled by a 2 TB PCI Express NVMe 4.0 x4 solid-state drive, offering high sequential read/write speeds. The system supports multiple RAID levels for performance or redundancy.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This workstation combines professional-grade components with thoughtful engineering to handle intensive tasks efficiently. The Threadripper PRO processor and WRX90 platform offer exceptional multi-core performance and platform stability for extended workloads.
Professional Memory Architecture
The 64 GB DDR5 ECC Registered memory configuration ensures high bandwidth and data integrity, crucial for scientific computing, financial modeling, and large dataset processing.
- 4.80 GHz clock speed
- Error-correcting code (ECC)
- Registered signal processing
High-Speed Storage & Expansion
The 2 TB NVMe SSD provides fast boot times and rapid file access, while the system supports additional drives and RAID configurations for scalable storage solutions.
- PCI Express NVMe 4.0 x4 interface
- RAID 0, 1, 5, 10 support
- NVMe and SATA controller support
Comprehensive Connectivity
Dual Ethernet (Gigabit and 10 Gigabit), wireless LAN, Bluetooth, and ten USB ports including high-speed USB-C ensure seamless integration with peripherals and networks.
- 10 total USB ports
- 2x USB-C 3.2 Gen 2
- 1x USB-C 20Gbps
Deployment / Use Cases
The ThinkStation P8 30HH0031US is ideal for environments where computational power, data integrity, and system reliability are paramount. Its balanced configuration of CPU, memory, and storage makes it suitable for a range of professional applications.
In engineering and design studios, it can handle CAD modeling, finite element analysis, and 3D rendering. For media production, it accelerates video editing, visual effects, and audio processing. Research institutions and data science teams benefit from its ability to process large datasets and run complex simulations. The system also serves well in financial analytics and software development where compile times and data processing are critical.
Engineering & Simulation
Run complex computational fluid dynamics, structural analysis, and electronic design automation tools with the multi-core Threadripper PRO processor and ECC memory.
Content Creation & Media
Accelerate 4K/8K video editing, 3D animation, and graphic design workflows with the dedicated graphics memory and high-speed NVMe storage.
Localization and Operating System
This workstation comes with Microsoft Windows 11 Pro pre-installed in English. Windows 11 Pro provides advanced security features, BitLocker encryption, remote desktop capabilities, and support for domain join, making it suitable for business and enterprise environments.
The keyboard is localized for English (US) layouts. The operating system language is set to English, ensuring a consistent user interface for English-speaking professionals.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P8 features a tower form factor designed for expandability and cooling. Its dimensions are 17.10" height, 6.89" width, and 20" depth (434.40 mm x 175 mm x 508 mm), with an approximate weight of 50.04 lb (22.7 kg). The chassis provides ample space for additional drives, expansion cards, and cooling solutions, supporting long-term reliability under heavy loads.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The package includes the ThinkStation P8 30HH0031US workstation, a keyboard, and a mouse, providing the essential components to get started immediately.
Package contents include ThinkStation P8 30HH0031US Keyboard Mouse, ThinkStation P8 30HH0031US. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- AMD Ryzen Threadripper PRO 7945WX 12-core processor at 4.70 GHz
- 64 GB DDR5 ECC Registered memory (4 x 16 GB) at 4.80 GHz
- 2 TB PCI Express NVMe 4.0 x4 solid-state drive
- 32 GB dedicated graphics memory for professional visualization
- Dual Ethernet: Gigabit and 10 Gigabit for high-speed networking
- Wireless LAN and Bluetooth for wireless connectivity
- Windows 11 Pro operating system with English localization
- 1.40 kW power supply for stable operation under load
- 3-year limited warranty with onsite service upgrade options
- ENERGY STAR 8.0 and EPEAT Gold certified for energy efficiency
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH0031US |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH0031US |
| Product Name | ThinkStation P8 30HH0031US |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7945WX |
| Processor Core | Dodeca-core (12 Core) |
| Processor Threads | 24 |
| Processor Speed | 4.70 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 32 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH0031US Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does this Lenovo ThinkStation P8 workstation use?
This workstation is equipped with an AMD Ryzen Threadripper PRO 7945WX processor. It features 12 cores (dodeca-core) and 24 threads, with a base clock speed of 4.70 GHz. This processor is built on the Socket sTR5 platform and is designed for high-performance computing tasks that benefit from parallel processing, such as 3D rendering, simulation, and data analysis.
How much memory is installed and what type is it?
The system comes with 64 GB of DDR5 SDRAM installed, configured as four 16 GB modules. This memory operates at a clock speed of 4.80 GHz and features ECC (Error-Correcting Code) and Registered signal processing, which enhances data integrity and stability for mission-critical applications. The workstation has eight memory slots total, supporting expansion up to 1 TB.
What storage configuration does this workstation have?
Storage is provided by a 2 TB solid-state drive with a PCI Express NVMe 4.0 x4 interface. This NVMe SSD offers high sequential read and write speeds, significantly reducing load times for applications and large files. The system supports RAID configurations (levels 0, 1, 5, 10) for additional performance or data redundancy if additional drives are added.
Does this workstation include a dedicated graphics card?
Yes, it includes a dedicated graphics controller with 32 GB of dedicated graphics memory. This dedicated GPU is suitable for professional visualization, CAD, video editing, and other graphics-intensive workloads, providing better performance than integrated graphics for such tasks.
What networking and connectivity options are available?
The workstation features dual Ethernet ports: one Gigabit Ethernet and one 10 Gigabit Ethernet for high-speed wired networking. It also includes wireless LAN (Wi-Fi) and Bluetooth for wireless connectivity. For peripherals, there are ten USB ports total, including two USB 2.0 ports, five USB 3.2 Gen 2 ports, and three USB-C ports (two USB-C 3.2 Gen 2 and one USB-C 20Gbps).
What warranty and certifications come with this ThinkStation?
Lenovo provides a 3-year limited warranty for this workstation, which includes a base 3-year onsite service option with an upgrade available to 3Y Premier Support. The system is ENERGY STAR 8.0 certified for energy efficiency and holds EPEAT Gold, GREENGUARD, and TCO Certified 9.0 environmental certifications, indicating compliance with strict environmental and health standards.
