Lenovo 30HH0039US ThinkStation P8 Workstation - AMD Ryzen Threadripper PRO 7955WX 4. 5GHz - 32GB DDR5 ECC - 1TB NVMe SSD - 16GB Dedicated Graphics
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The technical foundation of the ThinkStation P8 centers on the AMD WRX90 platform, designed specifically for Threadripper PRO processors. This chipset supports advanced memory configurations with eight DDR5 slots capable of accommodating up to 1TB of ECC registered memory, providing both massive capacity and critical error correction for mission-critical applications.
Storage is handled by a high-performance NVMe PCIe 4.0 x4 solid-state drive delivering exceptional read/write speeds. The system supports multiple RAID configurations (0, 1, 5, 10) for data redundancy or performance optimization. Networking capabilities include both Gigabit and 10 Gigabit Ethernet interfaces for high-bandwidth data transfer, complemented by integrated Wi-Fi and Bluetooth for wireless connectivity.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P8 delivers workstation-class performance with components validated for professional use. The AMD Ryzen Threadripper PRO processor provides exceptional multi-core performance for rendering, simulation, and data analysis applications. The dedicated 16GB graphics controller accelerates visualization workloads without relying on system memory.
Professional-Grade Reliability
ECC registered DDR5 memory with error checking ensures data accuracy during intensive computational tasks, while the robust 1.4kW power supply provides stable energy delivery for all components.
- ECC memory protection
- Registered DIMM stability
- High-efficiency 1.4kW PSU
Expansion & Future-Proofing
Eight memory slots support up to 1TB of RAM, while multiple USB 3.2 Gen 2 and USB-C ports provide high-speed connectivity for peripherals and external storage devices.
- 8 memory slots
- 10 total USB ports
- PCIe 4.0 architecture
Deployment / Use Cases
This workstation is designed for professional environments where computational performance and system reliability are paramount. The combination of high-core-count processing, ECC memory protection, and dedicated graphics makes it suitable for engineering firms, research institutions, media production studios, and financial analysis departments.
The system's comprehensive connectivity options facilitate integration into networked environments, while the tower form factor provides accessibility for maintenance and upgrades. With Windows 11 Pro pre-installed, users benefit from enterprise management features and security enhancements alongside productivity tools optimized for professional workflows.
Engineering & Design
Ideal for CAD/CAM applications, finite element analysis, and 3D modeling where multi-core CPU performance and dedicated graphics acceleration are essential.
- CAD/CAM workflows
- 3D rendering
- Simulation analysis
Scientific Computing
Suited for computational research, data science, and financial modeling where large datasets and complex calculations require both memory capacity and processing power.
- Data analysis
- Scientific simulations
- Financial modeling
Localization and Operating System
This workstation ships with Windows 11 Pro pre-installed in English language. The professional edition includes enhanced security features, remote desktop capabilities, and enterprise management tools suitable for business environments. The keyboard localization is configured for English (US) layout, ensuring compatibility with standard input devices and software interfaces.
Windows 11 Pro provides a modern computing environment with productivity enhancements, virtualization support through Hyper-V, and BitLocker encryption for data protection. The operating system is optimized to leverage the hardware capabilities of the Threadripper PRO platform, including multi-core scheduling and memory management for demanding applications.
Physical Profile
The ThinkStation P8 utilizes a substantial tower chassis measuring 17.1" high, 6.89" wide, and 20" deep (434.4 x 175 x 508 mm). This form factor provides ample internal space for component cooling and future expansion. The system weighs approximately 50.04 pounds (22.7 kg), reflecting its robust construction and comprehensive internal components.
The tower design facilitates maintenance and upgrades with accessible internal bays and standard component mounting. The chassis supports efficient airflow for thermal management during sustained high-performance operation. The physical dimensions accommodate standard rack-mount solutions for data center deployment when paired with appropriate mounting hardware.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation ships complete with all essential components for immediate deployment. The package includes the fully assembled ThinkStation P8 system configured as specified, along with a matching keyboard and mouse for immediate productivity.
Highlights
- AMD Ryzen Threadripper PRO 7955WX 16-core processor at 4.5GHz
- 32GB DDR5 ECC Registered memory with 4.8GHz speed
- 1TB NVMe PCIe 4.0 x4 solid-state drive for rapid storage
- 16GB dedicated graphics controller for accelerated visualization
- Windows 11 Pro operating system with English language
- Dual Ethernet (Gigabit & 10Gb) plus Wi-Fi and Bluetooth
- 10 total USB ports including multiple USB-C connections
- 1.4kW power supply for stable system operation
- 3-year warranty with onsite service included
- EPEAT Gold, ENERGY STAR 8.0, and TCO Certified 9.0 environmental certifications
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH0039US |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH0039US |
| Product Name | ThinkStation P8 30HH0039US |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7955WX |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Threads | 32 |
| Processor Speed | 4.50 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 16 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH0039US Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does this workstation use and what are its key specifications?
This workstation features the AMD Ryzen Threadripper PRO 7955WX processor. It's a 16-core (hexadeca-core) CPU with 32 threads operating at a base speed of 4.5GHz. The processor uses the Socket sTR5 interface and is paired with the AMD WRX90 chipset, providing a platform designed for professional workstation applications requiring high multi-threaded performance.
How much memory is installed and what type of memory technology does it use?
The system comes with 32GB of DDR5 SDRAM installed as two 16GB modules. This is ECC (Error-Correcting Code) registered memory operating at 4.8GHz. The workstation has eight total memory slots, supporting expansion up to 1TB maximum capacity. The ECC functionality provides data integrity protection critical for professional applications where computational accuracy is essential.
What storage configuration does this workstation include?
Storage is provided by a 1TB NVMe solid-state drive using the PCI Express 4.0 x4 interface for high-speed data transfer. The system supports RAID configurations including levels 0, 1, 5, and 10 for either performance optimization or data redundancy. The controller supports both NVMe and Serial ATA interfaces, allowing for additional storage expansion through various drive types.
What graphics capabilities does this workstation offer?
The workstation includes a dedicated graphics controller with 16GB of dedicated graphics memory. This separate graphics memory ensures that visualization and rendering tasks don't consume system RAM, maintaining optimal performance for both graphics-intensive applications and general computing tasks. The dedicated configuration accelerates professional visualization workloads commonly used in design, engineering, and media production.
What connectivity options are available on this workstation?
Connectivity includes both Gigabit Ethernet and 10 Gigabit Ethernet for high-speed wired networking, plus integrated wireless LAN and Bluetooth. The system provides 10 total USB ports: two USB 2.0 ports, five USB 3.2 Gen 2 ports, and three USB-C ports (including one USB 3.2 Gen 2x2 port supporting 20Gbps data transfer). This comprehensive connectivity supports multiple peripherals and high-speed data transfer requirements.
What warranty and environmental certifications come with this workstation?
The workstation includes a 3-year limited warranty with onsite service included. It carries multiple environmental certifications: EPEAT Gold for comprehensive environmental performance, ENERGY STAR 8.0 for energy efficiency, TCO Certified 9.0 for sustainability, GREENGUARD for low chemical emissions, and RoHS compliance for restricted substance management. These certifications demonstrate the product's environmental responsibility throughout its lifecycle.
