Lenovo 30HH003FUS ThinkStation P8 Workstation - Ryzen Threadripper PRO 7955WX 16-Core 4. 5 GHz - 64 GB DDR5 - 2 TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P8 is the AMD Ryzen Threadripper PRO 7955WX processor, featuring 16 physical cores and 32 threads with a base clock of 4.5 GHz. This CPU utilizes the Socket sTR5 interface and is paired with the enterprise-oriented AMD WRX90 chipset, which supports advanced memory configurations and extensive PCIe connectivity.
The memory subsystem employs DDR5 SDRAM technology with ECC (Error-Correcting Code) and Registered signal processing for enhanced data integrity in mission-critical applications. Four 16 GB modules populate the eight available memory slots, leaving room for expansion up to the 1 TB maximum supported capacity. Storage is handled by a 2 TB PCI Express NVMe 4.0 ×4 solid-state drive, delivering exceptional read/write speeds for large datasets and applications.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P8 combines professional-grade components with Lenovo's workstation validation to deliver reliable performance for engineering, scientific, creative, and financial applications. The system is designed to handle complex simulations, 3D rendering, data analysis, and multi-threaded software development without compromise.
Enterprise Memory Architecture
DDR5 ECC Registered memory ensures data accuracy during intensive computations, while eight DIMM slots support future expansion to 1 TB for growing workload demands.
- 64 GB installed (4 × 16 GB)
- ECC for error correction
- Registered for signal stability
- 8 total slots for expansion
Professional Connectivity Suite
Dual Ethernet (Gigabit and 10 Gigabit), wireless LAN, Bluetooth, and ten USB ports including high-speed USB-C connections provide flexible peripheral and network integration.
- 10 Gigabit Ethernet for fast transfers
- Wireless LAN and Bluetooth
- Multiple USB 3.2 Gen 2 ports
- USB-C 20 Gbps for high-bandwidth devices
Validated Workstation Platform
Lenovo's extensive testing and certification with professional applications ensures compatibility and stability with industry-standard software from Autodesk, Dassault Systèmes, Siemens, and others.
Deployment / Use Cases
The ThinkStation P8 30HH003FUS is optimized for professional environments where computational power, data integrity, and system reliability are paramount. Its balanced configuration of high-core-count CPU, substantial ECC memory, and fast NVMe storage makes it suitable for a wide range of technical and creative applications.
Engineering teams will appreciate the system's ability to handle finite element analysis, computational fluid dynamics, and electronic design automation. Media professionals can leverage the dedicated graphics memory and multi-threaded CPU for video editing, 3D animation, and visual effects rendering. Research and financial analysts benefit from the ECC memory protection during complex data modeling and quantitative analysis.
Engineering & Simulation
Run CAD/CAM software, structural analysis, and computational simulations with confidence in the ECC memory protection and sustained multi-threaded performance.
Content Creation & Visualization
Accelerate rendering pipelines for 3D animation, video production, and architectural visualization with the 16-core processor and dedicated graphics memory.
Localization and Operating System
This workstation ships with Windows 11 Pro pre-installed in English, providing a complete out-of-box experience for English-speaking users. Windows 11 Pro includes essential business features such as BitLocker encryption, Remote Desktop, and Group Policy management for enterprise deployment.
The keyboard is localized for English (US) layout, ensuring familiar key placement for productivity. The operating system is fully licensed and activated, ready for immediate use in professional environments without additional software procurement.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P8 utilizes a substantial tower form factor measuring 17.10" (434.40 mm) in height, 6.89" (175 mm) in width, and 20" (508 mm) in depth. This chassis provides ample internal space for additional storage drives, expansion cards, and enhanced cooling solutions. The system weighs approximately 50.04 lb (22.7 kg), reflecting its robust construction and component density.
The design prioritizes serviceability with tool-less access to internal components, making upgrades and maintenance straightforward for IT professionals. The chassis includes multiple cooling zones with optimized airflow to maintain component temperatures during extended high-load operation.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation arrives complete with all essential components for immediate setup and operation.
Highlights
- AMD Ryzen Threadripper PRO 7955WX processor with 16 cores and 32 threads at 4.5 GHz
- 64 GB of DDR5 ECC Registered memory for data-intensive applications
- 2 TB PCI Express NVMe 4.0 ×4 SSD for rapid storage performance
- Dedicated 32 GB graphics memory for visualization workloads
- Dual Ethernet with 10 Gigabit capability for high-speed networking
- Windows 11 Pro pre-installed with English localization
- 1.40 kW power supply for stable operation under full load
- 3-year onsite warranty with Premier Support for business continuity
- Eight memory slots supporting up to 1 TB total capacity
- Ten USB ports including multiple USB-C 3.2 Gen 2 connections
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH003FUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH003FUS |
| Product Name | ThinkStation P8 30HH003FUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7955WX |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Threads | 32 |
| Processor Speed | 4.50 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 32 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH003FUS Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year, Onsite 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does this Lenovo ThinkStation P8 workstation use?
This workstation features the AMD Ryzen Threadripper PRO 7955WX processor, which has 16 physical cores and 32 threads with a clock speed of 4.5 GHz. This high-core-count CPU is designed for demanding multi-threaded applications in engineering, scientific computing, content creation, and data analysis workflows.
How much memory is installed and what type is it?
The system comes with 64 GB of DDR5 SDRAM installed as four 16 GB modules. This is ECC (Error-Correcting Code) Registered memory, which provides enhanced data integrity for mission-critical applications. The memory operates at 4.8 GHz and there are eight total slots available, supporting expansion up to 1 TB maximum capacity.
What storage configuration does this workstation include?
Storage is provided by a 2 TB solid-state drive using the PCI Express NVMe 4.0 ×4 interface. This delivers significantly faster data transfer speeds compared to SATA SSDs or traditional hard drives. The system supports RAID configurations (0, 1, 5, 10) for additional storage performance or redundancy through the included controller.
What networking capabilities does the ThinkStation P8 offer?
This workstation includes both Gigabit Ethernet and 10 Gigabit Ethernet ports for wired networking, providing flexibility for standard office networks or high-bandwidth applications. It also features built-in wireless LAN (Wi-Fi) and Bluetooth connectivity for wireless peripheral connections and network access where cabling is impractical.
What operating system comes pre-installed?
The system ships with Windows 11 Pro already installed and activated. This is the English language version, which includes professional features such as BitLocker encryption, Remote Desktop capability, and enterprise management tools. The keyboard is also localized for English (US) layout for immediate productivity.
What warranty and support are included with this workstation?
Lenovo provides a 3-year limited warranty with onsite service. This includes the 3Y Premier Support Upgrade, which means a technician will come to your location for repairs rather than requiring you to ship the system. This onsite coverage helps minimize downtime in business environments where workstation availability is critical.
