Lenovo 30HH003KCA ThinkStation P8 Workstation - Ryzen Threadripper PRO 7965WX 24-Core - 32GB DDR5 - 1TB NVMe SSD - NVIDIA T400 4GB - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P8 lies the AMD Ryzen Threadripper PRO 7965WX processor, operating at 4.20 GHz with 24 cores and 48 threads. This CPU is paired with the AMD WRX90 chipset, providing enterprise-grade stability and extensive I/O capabilities. The system supports up to 1TB of DDR5 ECC Registered memory across eight slots, running at 4800 MHz for optimal bandwidth and data integrity.
Storage is handled by a 1TB PCIe NVMe 4.0 x4 solid-state drive, delivering sequential read/write speeds that significantly reduce load times for large datasets and applications. The integrated NVMe and SATA/600 controller supports hardware RAID 0, 1, 5, and 10 configurations for data redundancy or performance striping.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P8 combines workstation-class components with Lenovo's reliability engineering to create a platform capable of handling the most demanding professional workloads. Its balanced configuration of high-core-count processing, fast error-correcting memory, and professional graphics makes it suitable for a wide range of intensive applications.
Professional Graphics Performance
The NVIDIA T400 graphics card provides dedicated 4GB GDDR6 memory for accelerated rendering, CAD visualization, and multi-display setups without taxing system memory.
- 4GB dedicated GDDR6 memory
- Supports up to 4 displays via 3x Mini DisplayPort
- Professional driver certification
Enterprise Connectivity
Dual Ethernet ports with both Gigabit and 10GbE capabilities provide flexible network connectivity options for high-speed data transfer and network storage access.
- 10Gb Ethernet for high-bandwidth workflows
- Integrated Wi-Fi and Bluetooth
- Multiple USB 3.2 Gen 2 ports for fast peripherals
Expansion & Reliability
The tower chassis offers extensive internal expansion options while ECC memory and hardware RAID support ensure data integrity for critical workloads.
- 8 memory slots for future upgrades
- Hardware RAID 0/1/5/10 support
- 3-year Premier Next Business Day warranty
Deployment / Use Cases
The ThinkStation P8 is designed for professional environments where computational power, data integrity, and system stability are paramount. Its configuration makes it particularly well-suited for engineering firms, research institutions, media production studios, and financial analysis departments.
In engineering applications, the 24-core processor accelerates finite element analysis, computational fluid dynamics, and 3D rendering tasks. For scientific research, the ECC memory ensures data accuracy in simulations and modeling. Media professionals benefit from the combination of fast NVMe storage and professional graphics for video editing, animation, and visual effects work.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Localization and Operating System
This workstation comes pre-installed with Windows 11 Pro 64-bit, providing enterprise management features, enhanced security protocols, and compatibility with professional software applications. The French (Canada) keyboard localization ensures proper key labeling and layout for Canadian French users, supporting efficient workflow in bilingual environments.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P8 utilizes a traditional tower form factor measuring 17.10" high × 6.89" wide × 20" deep (434.4 × 175 × 508 mm), providing substantial internal space for component upgrades and cooling. Weighing approximately 50.04 lbs (22.7 kg), the chassis features robust construction with tool-less access panels for easy maintenance and expansion. The design prioritizes thermal management with optimized airflow paths to maintain component temperatures during sustained heavy workloads.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation arrives ready for setup with all essential components included for immediate deployment in professional environments.
Highlights
- AMD Ryzen Threadripper PRO 7965WX 24-core processor with 4.20 GHz clock speed
- 32GB DDR5 ECC Registered memory with 4800 MHz speed and 8 expansion slots
- 1TB PCIe NVMe 4.0 x4 SSD for ultra-fast storage performance
- NVIDIA T400 professional graphics card with 4GB dedicated GDDR6 memory
- Windows 11 Pro 64-bit operating system pre-installed
- Dual Ethernet with Gigabit and 10GbE connectivity options
- Tower form factor with extensive internal expansion capabilities
- Hardware RAID 0/1/5/10 support for data protection
- French (Canada) keyboard localization for Canadian users
- 3-year Premier Next Business Day warranty with onsite service
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH003KCA |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH003KCA |
| Product Name | ThinkStation P8 |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7965WX |
| Processor Core | Tetracosa-core (24 Core) |
| Processor Threads | 48 |
| Processor Speed | 4.20 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Graphics Controller Model | T400 |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | French (Canada) |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 3 |
| USB Type-C | Yes |
| USB Type-C Detail | 1x USB-C (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Mini DisplayPort | Yes |
| Number of Mini DisplayPort | 3 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Architecture | 64-bit |
| Physical Characteristics | |
| Form Factor | Tower |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 Keyboard |
| Environmentally Friendly | Yes |
| Environmental Certification | GREENGUARD |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3YR Premier NBD |
User Manual
FAQ
What type of workloads is the ThinkStation P8 best suited for?
The ThinkStation P8 is optimized for professional workloads requiring substantial computational power and data integrity. Its 24-core AMD Ryzen Threadripper PRO processor, ECC memory, and professional graphics make it ideal for engineering simulations, scientific research, 4K/8K video editing, architectural visualization, financial modeling, and data analysis applications where accuracy and performance are critical.
Can the memory be expanded beyond the installed 32GB?
Yes, the ThinkStation P8 features eight DDR5 memory slots supporting up to 1TB total capacity. The system comes with 32GB of DDR5 ECC Registered memory installed, leaving seven additional slots available for expansion. Memory upgrades must use compatible DDR5 ECC Registered modules to maintain error correction functionality and system stability.
What storage expansion options are available?
The workstation includes a 1TB PCIe NVMe 4.0 x4 SSD as primary storage, with additional expansion available through multiple internal drive bays. The system supports both NVMe and SATA drives via its integrated controller, with hardware RAID 0, 1, 5, and 10 configurations available for performance or redundancy requirements. The tower chassis provides ample space for multiple additional storage devices.
What professional graphics capabilities does the NVIDIA T400 provide?
The NVIDIA T400 is a professional graphics card with 4GB of dedicated GDDR6 memory, certified for CAD applications and professional visualization software. It supports up to four displays simultaneously via its three Mini DisplayPort outputs and features driver optimizations for professional applications like AutoCAD, SolidWorks, and Adobe Creative Suite. The dedicated graphics memory ensures complex models and high-resolution textures don't consume system RAM.
What networking features are included?
The ThinkStation P8 includes dual Ethernet ports with both Gigabit and 10 Gigabit Ethernet capabilities, providing flexibility for standard office networks or high-bandwidth applications like network-attached storage. The system also features integrated Wi-Fi and Bluetooth for wireless connectivity. The 10GbE port is particularly valuable for data-intensive workflows involving large file transfers or real-time collaboration on network resources.
What warranty and support options are provided?
Lenovo provides a 3-year Premier Next Business Day warranty with onsite service. This comprehensive coverage includes next-business-day technician dispatch for hardware issues, minimizing downtime in professional environments. The warranty covers all components and labor, with additional support available through Lenovo's professional services for deployment assistance and extended coverage options.
