Lenovo 30HH003PUS ThinkStation P8 Workstation - Ryzen Threadripper PRO 7965WX 24-Core - 32 GB DDR5 - 1 TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P8 is the AMD WRX90 chipset, designed to support the Threadripper PRO platform's advanced features, including extensive PCIe lanes and memory bandwidth. The system's 8 memory slots accommodate DDR5 modules running at 4.80 GHz, with ECC and Registered signal processing for enhanced data integrity in server-like environments.
Storage is handled by a PCI Express NVMe 4.0 x4 SSD, offering sequential read/write speeds that significantly reduce load times for large datasets and applications. The integrated storage controller supports NVMe and Serial ATA drives with hardware RAID 0, 1, 5, and 10 configurations, providing flexibility for performance or redundancy needs.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This workstation combines extreme processing power with enterprise-grade reliability features, making it suitable for professionals who cannot afford downtime or data corruption. The Threadripper PRO processor's high core count accelerates parallelized tasks, while the ECC memory and robust power supply ensure stable operation under sustained loads.
Professional-Grade Reliability
ECC Registered DDR5 memory corrects single-bit errors on the fly, preventing crashes and data corruption in critical applications like financial modeling or scientific computing.
- 3-year onsite warranty with Premier Support upgrade option
- ENERGY STAR 8.0 and EPEAT Gold certified for energy efficiency
- RoHS compliant and TCO Certified 9.0 for environmental responsibility
Expansion and Future-Proofing
With 8 memory slots supporting up to 1 TB of RAM and multiple high-speed storage interfaces, the P8 can scale to meet growing workload demands without requiring a full system replacement.
- Dual network interfaces including 10 Gigabit Ethernet for high-bandwidth tasks
- Multiple USB-C ports with 20 Gbps data transfer capabilities
- Tool-less chassis design for easy maintenance and upgrades
Deployment / Use Cases
The ThinkStation P8 is engineered for environments where computational intensity and data integrity are paramount. Its balanced configuration of high-core-count CPU, ample fast memory, and dedicated graphics makes it versatile across multiple professional disciplines.
In engineering and design studios, it handles CAD/CAM software, finite element analysis, and photorealistic rendering with ease. Research institutions leverage its parallel processing capabilities for genomic sequencing, computational fluid dynamics, and machine learning model training. Media production houses use it for 4K/8K video editing, color grading, and visual effects compositing, where the fast storage and GPU memory accelerate timeline performance.
Engineering and Simulation
Run complex simulations like computational fluid dynamics or structural analysis with reduced solve times, thanks to the 24-core processor and high-bandwidth memory architecture.
Content Creation and Visualization
Accelerate rendering pipelines in applications like Blender, V-Ray, or Unreal Engine, where the dedicated graphics memory and NVMe storage minimize bottlenecks in asset loading and frame output.
Localization and Operating System
This workstation ships with a fully licensed copy of Windows 11 Pro in English, providing a familiar and secure operating environment for business and professional use. Windows 11 Pro includes features like BitLocker encryption, Remote Desktop, and Hyper-V virtualization, which are essential for IT-managed deployments.
The included keyboard is localized for English (US) layouts, ensuring compatibility with standard input methods and software shortcuts. The operating system's hardware resource management optimizes performance for workstation-class applications, while regular security updates maintain protection against emerging threats.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Housed in a durable tower chassis measuring 17.10" x 6.89" x 20" (434.4 x 175 x 508 mm), the ThinkStation P8 offers a compact footprint relative to its internal expansion capabilities. The design prioritizes efficient cooling and serviceability, with tool-less access panels that simplify component upgrades or maintenance.
Weighing approximately 50.04 lb (22.7 kg), the system is built with robust materials to withstand the rigors of professional environments. The chassis includes multiple airflow pathways and dust filters to maintain optimal thermal conditions during extended compute sessions, ensuring consistent performance without thermal throttling.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation arrives ready for setup with all essential components included for immediate deployment.
Highlights
- AMD Ryzen Threadripper PRO 7965WX processor with 24 cores and 48 threads for extreme multi-threaded performance
- 32 GB of DDR5 ECC Registered memory running at 4.80 GHz for high bandwidth and data integrity
- 1 TB PCIe NVMe 4.0 SSD delivers fast boot times and rapid access to large project files
- Dedicated 32 GB graphics controller accelerates visualization and GPU compute tasks
- Dual Ethernet with Gigabit and 10 Gigabit ports for high-speed network connectivity
- Windows 11 Pro operating system with professional features like encryption and virtualization
- 8 memory slots support expansion up to 1 TB of RAM for future scalability
- Hardware RAID support (0,1,5,10) provides data redundancy or performance striping options
- 3-year onsite warranty with optional Premier Support upgrades for business continuity
- ENERGY STAR 8.0 and EPEAT Gold certified for energy-efficient operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH003PUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH003PUS |
| Product Name | ThinkStation P8 30HH003PUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7965WX |
| Processor Core | Tetracosa-core (24 Core) |
| Processor Threads | 48 |
| Processor Speed | 4.20 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 32 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C® 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH003PUS Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What type of workloads is this ThinkStation P8 best suited for?
The ThinkStation P8 30HH003PUS is optimized for compute-intensive professional applications including 3D rendering, engineering simulation, scientific computing, data analysis, and media production. Its 24-core Threadripper PRO processor, ECC memory, and dedicated graphics make it particularly effective for parallelized tasks that benefit from high thread counts and data integrity protection.
Can the memory be expanded beyond the installed 32 GB?
Yes, the workstation features 8 DDR5 memory slots, with 2 currently populated by 16 GB modules for the total 32 GB configuration. It supports a maximum of 1 TB of RAM using compatible ECC Registered DDR5 modules. This extensive expansion capability allows the system to scale for increasingly demanding workloads like large dataset analysis or virtual machine hosting.
What storage interfaces and expansion options are available?
The primary storage is a 1 TB PCI Express NVMe 4.0 x4 SSD, which connects directly to the CPU for maximum bandwidth. The system includes an NVMe/Serial ATA storage controller that supports additional drives, with hardware RAID 0, 1, 5, and 10 configurations available for performance or redundancy. Multiple internal drive bays allow for straightforward expansion with additional SSDs or HDDs.
Does this workstation include a dedicated graphics card?
Yes, the system includes a dedicated graphics controller with 32 GB of dedicated memory. This configuration provides substantial GPU resources for visualization, rendering, and compute tasks without sharing system memory, which is essential for applications like CAD, video editing, or GPU-accelerated scientific computing that benefit from dedicated graphics memory bandwidth.
What networking capabilities does the ThinkStation P8 offer?
The workstation includes both Gigabit Ethernet and 10 Gigabit Ethernet ports for flexible network connectivity. The 10GbE port is ideal for high-bandwidth tasks like transferring large media files or accessing network-attached storage at speeds up to 10 times faster than standard Gigabit Ethernet. It also features built-in Wireless LAN and Bluetooth for wireless peripheral connectivity and network access where wired connections are impractical.
What warranty and support options are included with this workstation?
Lenovo provides a 3-year limited warranty that includes onsite service, meaning a technician will come to your location for repairs. This base warranty can be upgraded to 3-year Premier Support, which offers enhanced service levels including priority response and 24/7 technical assistance. The system is also certified for energy efficiency (ENERGY STAR 8.0) and environmental standards (EPEAT Gold, TCO Certified 9.0).
