Lenovo 30HH004MUS ThinkStation P8 Workstation - AMD Threadripper™ PRO 7985WX 3. 20GHz - 64GB DDR5 - 2TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the heart of the ThinkStation P8 is the AMD WRX90 platform, featuring the Socket sTR5 for the Threadripper PRO 7985WX processor. This 64-core CPU operates at a base frequency of 3.20GHz and is paired with a 256MB L3 cache, delivering immense parallel processing capability for rendering, scientific computing, and virtualization tasks.
The memory subsystem utilizes DDR5 technology running at 4800MHz, with ECC and Registered signal processing to ensure data integrity in mission-critical applications. Storage is handled by a PCI Express 4.0 NVMe SSD, offering sequential read/write speeds that significantly reduce load times for large datasets and project files.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ThinkStation P8 combines workstation-grade components with Lenovo's reliability engineering to create a system that excels in stability under sustained heavy loads. Its thermal design and power delivery are optimized for the high thermal output of the Threadripper PRO processor, maintaining consistent clock speeds during extended compute sessions.
Professional-Grade Expandability
Eight DDR5 memory slots and support for multiple storage devices allow this workstation to grow with project demands. The 1.4kW power supply provides ample headroom for adding high-performance GPUs, additional drives, or expansion cards.
- 8 memory slots (1TB max capacity)
- RAID 0/1/5/10 support
- 10 total USB ports including USB-C 3.2 Gen 2x2
Comprehensive Connectivity
Dual Ethernet ports including 10GbE provide high-bandwidth network access for collaborative workflows and storage arrays. Wireless connectivity includes the latest Wi-Fi 6E standard for reduced latency in crowded RF environments.
- 10GbE + Gigabit Ethernet
- Wi-Fi 6E with Bluetooth 5.2
- Multiple USB-C with 20Gbps data transfer
Deployment / Use Cases
This workstation is purpose-built for professional environments where time-to-solution directly impacts business outcomes. Its massive core count and memory bandwidth make it ideal for rendering farms, where it can significantly reduce frame times for animation and visual effects production.
Engineering and scientific applications benefit from the Threadripper PRO's compute density for finite element analysis, computational fluid dynamics, and genomic sequencing. The ECC memory protection ensures accuracy in these data-sensitive calculations, while the NVMe storage accelerates access to large simulation datasets.
Media Production & 3D Rendering
Handle 8K video editing, complex compositing, and ray-traced rendering with the 64-core processor and dedicated graphics. The system maintains responsiveness during multitasking across creative applications.
Scientific Research & Simulation
Run parallelized simulations, machine learning training, and data analysis workflows with the high core count and large memory capacity. ECC memory prevents silent data corruption in long-running computations.
Localization and Operating System
This workstation ships with Windows 11 Pro 64-bit edition pre-installed in English, providing immediate productivity with professional features like BitLocker encryption, Remote Desktop, and Hyper-V virtualization. The US English keyboard localization ensures compatibility with standard input devices and software shortcuts.
Windows 11 Pro includes enhanced security features that are particularly valuable in professional environments, including hardware-based isolation and Microsoft Defender Application Guard. The 64-bit architecture fully utilizes the system's 64GB of RAM and multi-core processor for maximum application performance.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P8 utilizes a tower form factor measuring 17.1" high × 6.89" wide × 20" deep (434.4 × 175 × 508mm), providing ample internal space for component upgrades and optimal airflow. At approximately 50 pounds (22.7kg), the system has a substantial build quality with tool-less access panels for easy maintenance.
Finished in professional black, the workstation features a clean aesthetic suitable for office environments, labs, or studio settings. The chassis design prioritizes cooling efficiency with strategically placed vents and fan mounts to maintain optimal operating temperatures during sustained heavy workloads.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
This workstation ships as a complete system ready for setup and immediate use. The package includes all necessary components to begin productivity upon unboxing.
Highlights
- AMD Ryzen Threadripper PRO 7985WX processor with 64 cores and 128 threads for extreme parallel processing
- 64GB of DDR5 ECC Registered memory running at 4800MHz for data-intensive applications
- 2TB NVMe SSD with PCIe 4.0 interface for rapid storage access and reduced load times
- Dedicated graphics with 16GB of video memory for professional visualization and rendering
- Dual Ethernet with 10GbE and Gigabit ports for high-bandwidth network connectivity
- Windows 11 Pro 64-bit pre-installed with English language and US keyboard localization
- Eight DDR5 memory slots supporting expansion up to 1TB total system memory
- 1.4kW power supply with 80 Plus Platinum efficiency for stable operation under load
- Comprehensive environmental certifications including EPEAT Gold and ENERGY STAR 8.0
- 3-year limited warranty with premier next-business-day onsite service
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH004MUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH004MUS |
| Product Name | ThinkStation P8 30HH004MUS Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7985WX |
| Processor Core | Tetrahexaconta-core (64 Core) |
| Processor Threads | 128 |
| Processor Speed | 3.20 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express 4.0 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 16 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Wi-Fi Generation | Wi-Fi 6E |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English (US) |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Operating System Architecture | 64-bit |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH004MUS Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3YR Premier NBD 3 Year On-site |
User Manual
FAQ
What type of workloads is this ThinkStation P8 workstation best suited for?
This workstation excels at professional applications requiring high parallel processing power, including 3D rendering and animation, scientific simulations, engineering analysis, video production, and data science. The 64-core Threadripper PRO processor and 64GB of ECC memory make it ideal for computationally intensive tasks that benefit from massive core counts and data integrity protection.
Can the memory be expanded beyond the installed 64GB?
Yes, the ThinkStation P8 features eight DDR5 memory slots and supports up to 1TB of total system memory. The current configuration uses four 16GB modules, leaving four slots available for expansion. The system utilizes ECC Registered memory technology, which provides error correction for mission-critical applications while maintaining high bandwidth operation at 4800MHz.
What storage expansion options are available?
This workstation includes a 2TB NVMe SSD connected via PCI Express 4.0 for maximum performance. The system supports RAID configurations (0, 1, 5, 10) through its NVMe and SATA controllers, allowing for additional drives to be added for capacity or redundancy. The 1.4kW power supply provides ample power for multiple high-performance storage devices.
What networking capabilities does this workstation include?
The ThinkStation P8 features dual Ethernet ports with both Gigabit and 10 Gigabit capabilities, providing flexible connectivity for high-speed network storage or clustered computing environments. Wireless connectivity includes Wi-Fi 6E for reduced latency in crowded wireless environments, along with Bluetooth 5.2 for peripheral devices. The system also includes ten USB ports with multiple USB-C connections supporting 20Gbps data transfer.
What operating system is pre-installed and what language/keyboard does it use?
This workstation ships with Windows 11 Pro 64-bit edition pre-installed in English language. The keyboard localization is US English, ensuring compatibility with standard keyboard layouts and software shortcuts. Windows 11 Pro includes professional features like BitLocker encryption, Remote Desktop, and Hyper-V virtualization that are valuable in business and research environments.
What warranty and support are included with this workstation?
Lenovo provides a 3-year limited warranty with premier next-business-day onsite service for this ThinkStation P8. This support package includes hardware repair or replacement with a technician dispatched to your location. The system also carries multiple environmental certifications including EPEAT Gold, ENERGY STAR 8.0, and TCO Certified 9.0, reflecting its energy efficiency and reduced environmental impact.
