Lenovo 30HH004XUS ThinkStation P8 Workstation - Ryzen Threadripper PRO 7995WX 96-Core - 64 GB DDR5 - 2 TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The ThinkStation P8's technical foundation centers on the Socket sTR5 platform with AMD's WRX90 chipset, designed specifically for Threadripper PRO processors. This architecture supports 8 memory slots capable of accommodating up to 1 TB of DDR5 ECC Registered memory, providing exceptional scalability for growing computational demands.
Storage flexibility comes through NVMe and Serial ATA controllers with hardware RAID 0, 1, 5, and 10 support, allowing for performance-optimized or redundancy-focused storage configurations. The 1.4 kW power supply ensures stable operation even under maximum load conditions, while comprehensive connectivity includes dual Ethernet (Gigabit and 10 Gigabit), Wi-Fi, Bluetooth, and multiple USB ports including high-speed USB-C interfaces.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This workstation combines extreme processing power with professional-grade reliability features. The Threadripper PRO 7995WX's 96-core architecture provides parallel processing capabilities that accelerate compute-intensive tasks significantly compared to traditional workstation processors.
Professional Memory Architecture
DDR5 ECC Registered memory ensures data accuracy for critical calculations while the 8-slot design supports expansion to 1 TB for future growth.
- ECC error correction
- Registered signal stability
- 4.8 GHz clock speed
Enterprise Connectivity
Dual Ethernet with 10 Gigabit capability supports high-bandwidth network storage and cluster computing, while multiple USB 3.2 Gen 2 and USB-C ports accommodate modern peripherals.
- 10GbE for fast data transfer
- USB-C 20Gbps support
- Wi-Fi and Bluetooth integrated
Reliability & Support
The 3-year onsite warranty with Premier Support provides professional technical assistance, while environmental certifications demonstrate sustainable manufacturing practices.
- 3-year onsite service
- EPEAT Gold certified
- ENERGY STAR 8.0 compliant
Deployment / Use Cases
The ThinkStation P8 30HH004XUS excels in environments requiring substantial computational resources and data integrity. Engineering firms utilize these workstations for finite element analysis, computational fluid dynamics, and structural simulations where processor core count directly impacts solution times.
Media production studios deploy these systems for 8K video editing, complex visual effects rendering, and real-time animation where the combination of high-core-count processing and fast storage accelerates project timelines. Research institutions leverage the ECC memory and processing power for genomic sequencing, climate modeling, and financial simulations where accuracy and performance are equally critical.
Engineering & Simulation
Handle complex CAD models, multiphysics simulations, and product design validation with the 96-core processor and professional memory architecture.
Media & Entertainment
Accelerate 8K video editing, 3D animation rendering, and visual effects processing with the high-core-count CPU and fast NVMe storage.
Localization and Operating System
This workstation ships with Windows 11 Pro pre-installed in English, providing a familiar interface for professional users while delivering enterprise management capabilities, enhanced security features, and productivity optimizations. The English keyboard localization ensures compatibility with standard North American input methods and software conventions.
Windows 11 Pro includes BitLocker device encryption, Windows Defender Antivirus, Remote Desktop functionality, and Group Policy management tools that simplify administration in organizational environments. The operating system leverages the workstation's hardware capabilities through optimized scheduling for high-core-count processors and support for professional applications requiring Windows certification.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The tower chassis measures 17.1" high × 6.89" wide × 20" deep (434.4 × 175 × 508 mm) with a weight of approximately 50.04 lb (22.7 kg), providing substantial internal volume for component cooling and expansion while maintaining a professional appearance suitable for office environments. The design incorporates efficient airflow management to maintain optimal operating temperatures during sustained heavy workloads.
The form factor supports standard workstation placement on or under desks, with front-panel connectivity including USB ports for convenient peripheral access. The robust construction and 1.4 kW power supply accommodate additional storage drives, expansion cards, or specialized computing accelerators as workload requirements evolve.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation arrives ready for setup with all essential components included for immediate deployment in professional environments.
Highlights
- AMD Ryzen Threadripper PRO 7995WX processor with 96 cores and 192 threads for extreme parallel processing
- 64 GB DDR5 ECC Registered memory operating at 4.8 GHz across four 16 GB modules
- 2 TB PCIe NVMe 4.0 x4 SSD delivers rapid storage performance for large datasets
- AMD WRX90 chipset provides professional platform stability and expansion capabilities
- Windows 11 Pro operating system with English language and keyboard localization
- Dual Ethernet with 10 Gigabit support for high-bandwidth network connectivity
- 1.4 kW power supply ensures stable operation under maximum computational loads
- 3-year onsite warranty with Premier Support for professional technical assistance
- 8 memory slots support expansion to 1 TB of DDR5 ECC Registered memory
- Hardware RAID 0, 1, 5, and 10 support for storage performance or redundancy configurations
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH004XUS |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH004XUS |
| Product Name | ThinkStation P8 30HH004XUS |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7995WX |
| Processor Core | Hexanonaconta-core (96 Core) |
| Processor Threads | 192 |
| Processor Speed | 2.50 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH004XUS Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year, Onsite 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What professional applications benefit most from the Threadripper PRO 7995WX processor?
The 96-core Threadripper PRO 7995WX excels in applications that leverage parallel processing, including engineering simulations (ANSYS, SOLIDWORKS), scientific computing (MATLAB, computational chemistry), media production (DaVinci Resolve, Blender rendering), and data analysis workloads. The high core count significantly reduces computation times for tasks that can be distributed across multiple processor cores.
How does ECC memory benefit workstation applications?
ECC (Error-Correcting Code) memory detects and corrects single-bit memory errors that can occur during data processing. This is critical for scientific computing, financial modeling, engineering simulations, and other applications where data accuracy is paramount. The Registered memory modules also provide signal stability when operating at high speeds (4.8 GHz) with large capacities.
What storage expansion options does this workstation support?
The ThinkStation P8 supports NVMe and Serial ATA storage devices through its controllers, with hardware RAID 0, 1, 5, and 10 capabilities. The 2 TB NVMe SSD serves as primary storage, while additional drives can be added for capacity or redundancy. The AMD WRX90 chipset provides multiple PCIe lanes for storage expansion cards if needed.
What networking capabilities are included?
This workstation features both Gigabit Ethernet and 10 Gigabit Ethernet ports for flexible network connectivity. The 10GbE capability supports high-bandwidth applications like network-attached storage, render farming, or cluster computing. Wireless LAN and Bluetooth provide additional connectivity options for peripherals and internet access.
What warranty and support services are provided?
Lenovo provides a 3-year onsite warranty with Premier Support, which includes technical assistance and hardware service at your location. This professional support level ensures minimal downtime for critical workstation applications. The system also carries multiple environmental certifications including EPEAT Gold and ENERGY STAR 8.0.
What are the physical dimensions and power requirements?
The tower measures 17.1" H × 6.89" W × 20" D (434.4 × 175 × 508 mm) and weighs approximately 50.04 lb (22.7 kg). It includes a 1.4 kW power supply that provides ample capacity for the processor, memory, storage, and potential expansion cards while maintaining stable operation under maximum load conditions.
