Lenovo 30HH0053US ThinkStation P8 Workstation - Ryzen Threadripper PRO 7995WX 96-Core - 32 GB RAM - 1 TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the heart of the ThinkStation P8 is the AMD Ryzen Threadripper PRO 7995WX, a Socket sTR5 processor operating at a base frequency of 2.50 GHz. This Hexanonaconta-core (96-core) CPU is paired with the professional-grade AMD WRX90 chipset, which provides the platform stability and I/O capabilities required for workstation-class expansion and multi-threaded performance.
Memory performance is driven by DDR5 SDRAM technology running at 4.80 GHz. The installed 32 GB configuration uses two 16 GB modules, leaving six additional slots free for expansion up to a massive 1 TB capacity. ECC (Error-Correcting Code) and Registered signal processing ensure data integrity and reliability in mission-critical applications. Storage is handled by a 1 TB PCI Express NVMe 4.0 x4 solid-state drive, which connects via a high-bandwidth interface to minimize latency. The storage controller supports NVMe and Serial ATA drives with hardware RAID 0, 1, 5, and 10 functionality for data redundancy or performance striping.
Key Product Advantages
The ThinkStation P8 30HH0053US combines extreme multi-core processing with professional-grade reliability features, making it a cornerstone for technical computing environments. Its balanced configuration is optimized for both immediate productivity and long-term scalability.
Professional-Grade Reliability
ECC memory corrects single-bit errors on the fly, preventing data corruption and system crashes during extended computational sessions. The registered memory design improves signal integrity in fully populated memory configurations.
- ECC error correction for data integrity
- Registered memory for stability at high capacities
- Dedicated graphics with ample video memory
High-Speed Data Pipeline
DDR5 memory and PCIe NVMe 4.0 storage work in concert to keep the high-core-count processor fed with data, reducing bottlenecks in data-intensive workflows like simulation and video editing.
- DDR5 SDRAM at 4.80 GHz
- PCI Express NVMe 4.0 x4 SSD interface
- 10 Gigabit Ethernet for fast network transfers
Expansion and Serviceability
The tower chassis provides ample internal space and cooling for additional storage drives, expansion cards, and memory upgrades. Eight memory slots and support for multiple storage controllers allow the system to grow with project demands.
- Eight DDR5 memory slots
- Support for hardware RAID arrays
- Tool-less chassis design for easy access
Deployment / Use Cases
This workstation is purpose-built for professional and enterprise scenarios where time-to-solution and computational accuracy directly impact business outcomes. Its hardware profile suits it for sustained, heavy workloads rather than general office tasks.
In engineering and design studios, the 96-core Threadripper PRO processor accelerates finite element analysis (FEA), computational fluid dynamics (CFD), and high-resolution 3D rendering. The dedicated graphics with 32 GB of memory handles large assemblies and complex visualizations in CAD and BIM applications. For research and data science teams, the combination of high core count, large memory bandwidth, and fast NVMe storage speeds up genomic sequencing, financial modeling, and machine learning training tasks. Media production houses will benefit from the system's ability to manage 8K video editing, color grading, and visual effects rendering with multiple applications running concurrently.
Localization and Operating System
The workstation ships with a fully licensed copy of Microsoft Windows 11 Pro in English. Windows 11 Pro includes BitLocker device encryption, Remote Desktop, Hyper-V for virtualization, and enhanced security features suitable for business networks. The operating system is pre-configured for the hardware, ensuring optimal driver support and stability out of the box.
Keyboard localization is English, matching the OS language. This configuration is standard for North American markets and ensures consistency between input devices, on-screen prompts, and software interfaces.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P8 utilizes a substantial tower form factor measuring 17.10" (434.40 mm) in height, 6.89" (175 mm) in width, and 20" (508 mm) in depth. This design accommodates robust cooling solutions, multiple expansion slots, and ample drive bays while maintaining a professional appearance. The system weighs approximately 50.04 lb (22.7 kg), reflecting its solid construction and component density. The chassis is engineered for serviceability with tool-less access panels, making upgrades and maintenance straightforward for IT staff.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation arrives with all necessary components to begin operation immediately.
Highlights
- AMD Ryzen Threadripper PRO 7995WX processor with 96 cores and 192 threads for extreme multi-threaded performance
- 32 GB of DDR5 SDRAM running at 4.80 GHz with ECC and Registered technology for data integrity
- 1 TB PCI Express NVMe 4.0 x4 solid-state drive for fast boot times and application loading
- Dedicated graphics controller with 32 GB of dedicated video memory for professional visualization
- Windows 11 Pro operating system with advanced security and management features for business use
- Dual Ethernet with Gigabit and 10 Gigabit ports for high-speed network connectivity
- Wireless LAN and Bluetooth for flexible peripheral and network connections
- Ten USB ports including multiple USB 3.2 Gen 2 and USB-C ports for modern peripherals
- Hardware RAID support (0, 1, 5, 10) for data redundancy or performance acceleration
- Three-year onsite warranty with premier support for reliable long-term operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH0053US |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH0053US |
| Product Name | ThinkStation P8 30HH0053US |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7995WX |
| Processor Core | Hexanonaconta-core (96 Core) |
| Processor Threads | 192 |
| Processor Speed | 2.50 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 32 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH0053US Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year, Onsite 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor is in the Lenovo ThinkStation P8 30HH0053US?
This workstation features the AMD Ryzen Threadripper PRO 7995WX processor. It is a Socket sTR5 CPU with 96 cores (Hexanonaconta-core) and 192 threads, operating at a base clock speed of 2.50 GHz. This processor is designed for professional workloads that benefit from massive parallel processing, such as 3D rendering, simulation, and data analysis.
How much memory does it have, and can it be expanded?
The system comes standard with 32 GB of DDR5 SDRAM, configured as two 16 GB modules running at 4.80 GHz. The memory uses ECC (Error-Correcting Code) and Registered technology for enhanced reliability. There are eight total memory slots, allowing for expansion up to a maximum of 1 TB of system RAM, providing significant headroom for memory-intensive applications.
What type of storage is included?
Storage is provided by a 1 TB solid-state drive using the PCI Express NVMe 4.0 x4 interface. This offers very high sequential read and write speeds compared to SATA SSDs, reducing load times for large files and applications. The storage controller supports both NVMe and Serial ATA drives and includes hardware RAID support for levels 0, 1, 5, and 10.
Does this workstation include a dedicated graphics card?
Yes, the ThinkStation P8 30HH0053US includes a dedicated graphics controller with 32 GB of dedicated video memory. This dedicated GPU is essential for professional applications like CAD, 3D modeling, video editing, and scientific visualization, where integrated graphics would be insufficient for handling complex models and high-resolution displays.
What operating system is pre-installed?
It comes with Microsoft Windows 11 Pro (English version) pre-installed and licensed. Windows 11 Pro includes features like BitLocker encryption, Remote Desktop, Hyper-V virtualization, and enhanced security controls that are valuable in business and professional environments. The OS is configured to work optimally with the workstation's hardware.
What are the warranty and support terms?
Lenovo provides a 3-year limited warranty for this workstation. The warranty includes onsite service, meaning a technician will come to your location for repairs. It is further enhanced with a 3Y Premier Support upgrade from the standard onsite service, offering prioritized support and potentially faster resolution times for critical issues in professional settings.
