Lenovo 30HH0057US ThinkStation P8 Workstation - Ryzen Threadripper PRO 7995WX 96-Core - 64 GB RAM - 2 TB SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the heart of the ThinkStation P8 30HH0057US is the AMD Ryzen Threadripper PRO 7995WX, a 96-core processor operating at 2.50 GHz on the Socket sTR5 platform. This CPU, paired with the AMD WRX90 chipset, delivers workstation-class performance for multi-threaded applications. The system supports up to 1 TB of memory across eight DDR5 slots, with the installed 64 GB (4 x 16 GB) running at 4.80 GHz with ECC and Registered signal processing for enhanced reliability.
Storage is handled by a 2 TB PCI Express NVMe 4.0 x4 solid-state drive, offering high throughput and low latency for large datasets. The storage subsystem supports hardware RAID 0, 1, 5, and 10 via NVMe and Serial ATA controllers. Graphics are powered by a dedicated controller with 32 GB of dedicated memory, suitable for CAD, visualization, and moderate GPU computing tasks.
Key Product Advantages
The ThinkStation P8 combines extreme multi-core performance with professional reliability features, making it a robust platform for critical workloads. Its architecture is designed to minimize downtime and ensure consistent output in production environments.
Professional-Grade Reliability
ECC Registered DDR5 memory and a robust power supply (1.40 kW) provide stability for 24/7 operation, reducing the risk of data corruption and system crashes during long computations.
- ECC error correction for memory integrity
- High-capacity 1.40 kW power supply
- Supported by 3-year onsite warranty
High-Speed Connectivity
Dual Ethernet with 10 Gigabit support ensures fast network transfers, while multiple USB 3.2 Gen 2 and USB-C ports offer versatile peripheral connectivity for modern workstations.
- 10 Gigabit Ethernet for network-intensive tasks
- USB-C with 20 Gbps data transfer
- Built-in Wi-Fi and Bluetooth for wireless flexibility
Deployment / Use Cases
The Lenovo ThinkStation P8 30HH0057US is engineered for environments where computational power and data integrity are non-negotiable. Its high core count and large memory capacity make it ideal for parallel processing tasks that benefit from massive thread counts.
Common deployments include engineering firms running finite element analysis (FEA) and computational fluid dynamics (CFD), media studios handling 8K video editing and 3D animation, research institutions performing genomic sequencing or financial modeling, and architectural practices rendering complex building designs. The system's RAID support and ECC memory also make it suitable for small-scale server roles in test labs or as a node in a render farm.
Engineering & Simulation
Run complex simulations and CAD workloads with the 96-core Threadripper PRO CPU and dedicated graphics, reducing iteration times and improving productivity.
Content Creation & Rendering
Accelerate 3D rendering, video editing, and visual effects work with high-speed NVMe storage and ample memory for large asset files.
Localization and Operating System
This workstation ships with Windows 11 Pro pre-installed in English, providing a familiar and secure operating system for professional use. Windows 11 Pro includes advanced management features, BitLocker encryption, and support for domain join, making it suitable for enterprise IT environments. The keyboard is localized for English (US) layouts, ensuring compatibility with standard input devices and software shortcuts.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The ThinkStation P8 features a tower form factor with dimensions of 17.10" (434.40 mm) in height, 6.89" (175 mm) in width, and 20" (508 mm) in depth, offering a substantial footprint for its internal expansion capabilities. Weighing approximately 50.04 lb (22.7 kg), it is designed for stationary deployment in office, lab, or studio settings. The chassis provides ample space for additional storage drives, expansion cards, and cooling to maintain performance under load.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The package includes the ThinkStation P8 30HH0057US workstation, a keyboard, and a mouse, providing everything needed to set up and start working out of the box.
Highlights
- AMD Ryzen Threadripper PRO 7995WX processor with 96 cores and 192 threads for extreme multi-threaded performance
- 64 GB of DDR5 SDRAM with ECC and Registered technology for reliable operation under heavy loads
- 2 TB PCIe NVMe 4.0 x4 SSD delivers fast boot times and rapid access to large files
- Dedicated 32 GB graphics controller accelerates visualization and GPU-accelerated tasks
- Windows 11 Pro operating system with English localization for professional software compatibility
- Dual Ethernet including 10 Gigabit for high-speed network connectivity in data-intensive environments
- Comprehensive USB connectivity with 10 ports, including USB-C 20 Gbps for modern peripherals
- 1.40 kW power supply ensures stable operation even with additional expansion cards and drives
- Supports hardware RAID 0, 1, 5, 10 for data redundancy and performance optimization
- Backed by a 3-year limited warranty with onsite service for added peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH0057US |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH0057US |
| Product Name | ThinkStation P8 30HH0057US |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7995WX |
| Processor Core | Hexanonaconta-core (96 Core) |
| Processor Threads | 192 |
| Processor Speed | 2.50 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 32 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH0057US Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Base Warranty 3-year, Onsite Included Upgrade 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does the Lenovo ThinkStation P8 30HH0057US use, and how many cores does it have?
This workstation is equipped with an AMD Ryzen Threadripper PRO 7995WX processor. It features 96 cores (hexanonaconta-core) and 192 threads, operating at a base clock speed of 2.50 GHz. This high core count makes it exceptionally well-suited for parallel processing tasks like 3D rendering, scientific simulations, and video encoding, where workload distribution across many threads significantly reduces processing time.
How much memory is installed, and what is the maximum supported memory capacity?
The system comes with 64 GB of DDR5 SDRAM installed across four 16 GB modules. It supports a maximum memory capacity of 1 TB across eight memory slots. The memory runs at 4.80 GHz and includes ECC (Error-Correcting Code) and Registered signal processing, which enhances data integrity and stability—critical for professional workstations handling sensitive or large-scale computations.
What type of storage is included, and does the workstation support RAID configurations?
It includes a 2 TB PCI Express NVMe 4.0 x4 solid-state drive (SSD), offering high-speed data transfer rates for fast boot times and quick access to applications and files. The workstation supports hardware RAID configurations, specifically levels 0, 1, 5, and 10, allowing you to set up striping, mirroring, or parity-based arrays for improved performance, data redundancy, or a combination of both using additional drives.
What graphics capabilities does this workstation have?
The ThinkStation P8 30HH0057US includes a dedicated graphics controller with 32 GB of dedicated memory. This provides substantial graphics power for tasks such as CAD modeling, 3D visualization, moderate GPU computing, and multi-display setups. While not a top-tier professional GPU, it is suitable for many visualization-heavy applications and can accelerate workloads that benefit from GPU parallelism.
What networking and connectivity options are available on this workstation?
For wired networking, it features both Gigabit Ethernet and 10 Gigabit Ethernet ports, enabling high-speed network transfers essential for data-intensive environments. Wireless connectivity includes Wi-Fi (Wireless LAN) and Bluetooth for peripheral connections. The system also offers 10 USB ports in total: 2 USB 2.0, 5 USB 3.2 Gen 2, 2 USB-C 3.2 Gen 2, and 1 USB-C port supporting 20 Gbps (USB 3.2 Gen 2x2) for data transfer.
What operating system is pre-installed, and what warranty coverage is provided?
This workstation comes with Windows 11 Pro pre-installed in English, offering a professional-grade OS with features like BitLocker encryption and domain join capabilities for enterprise management. It is backed by a 3-year limited warranty that includes onsite service. The warranty covers base support with an upgrade option to 3-year Premier Support, ensuring reliable technical assistance and minimizing downtime in professional settings.
