Lenovo 7162C4U Flex System x240 Blade Server - 1x Xeon E5-2630 v2 2. 60 GHz Hexa-core - 16 GB DDR3 - 2 x 2. 5" Bays - 10GbE - RAID 0 - 1 - 1E
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This blade server features a balanced technical profile centered on the Intel C600 chipset, supporting up to two processors for future expansion. The installed 16 GB of DDR3 SDRAM operates across 24 available memory slots, allowing significant memory scaling to meet growing application demands. Storage is handled by a 6Gb/s SAS and Serial ATA/600 controller with hardware RAID 0, 1, and 1E support, ensuring data protection and performance for the two internal 2.5" drive bays.
Network connectivity is delivered through integrated 10 Gigabit Ethernet, providing high-speed data transfer essential for clustered and virtualized environments. The server includes three USB ports for peripheral attachment and supports remote management capabilities for out-of-band administration. Graphics are managed by a dedicated 16 MB controller suitable for console redirection and basic display output.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Flex System x240 blade server offers distinct advantages for organizations prioritizing infrastructure density and operational efficiency. Its design reduces physical footprint and power consumption per compute unit compared to traditional rack servers, while maintaining full enterprise capabilities.
High-Density Compute
The blade form factor packs processing power, memory, and storage into a 2U chassis slot, enabling more servers per rack and lowering data center real estate costs.
- Optimized for energy savings
- Shared power and cooling in chassis
Scalable Architecture
With support for a second processor and 24 memory slots, the server can scale compute and memory resources to match workload growth without replacing the entire unit.
- Dual-processor capable
- Extensive memory expansion
Integrated Data Protection
The hardware RAID controller supports multiple RAID levels, allowing administrators to balance performance, capacity, and redundancy based on application requirements.
- RAID 0 for performance
- RAID 1 and 1E for redundancy
Deployment / Use Cases
This blade server is ideally suited for deployment in consolidated data center environments where multiple servers are managed within a Flex System chassis. Its profile supports a range of enterprise applications that benefit from high-density compute and efficient resource sharing.
Common use cases include virtualization hosts for VMware or Hyper-V, where the hexa-core processor and memory scalability support multiple virtual machines. The server also serves well for mid-tier database servers, web application hosting, and network infrastructure roles, leveraging the 10 Gigabit Ethernet for fast network throughput. In disaster recovery or branch office scenarios, the blade's remote management capabilities enable centralized administration across distributed locations.
Virtualization Host
Deploy as a hypervisor host, running multiple virtualized workloads with the Xeon processor and expandable memory supporting consolidated server environments.
Business Application Server
Run database, ERP, or CRM applications that require reliable compute performance and RAID-protected storage for data integrity and availability.
Localization and Operating System
This server ships without a pre-installed operating system, providing flexibility for organizations to deploy their preferred OS, such as Windows Server, Linux distributions, or virtualization hypervisors. The lack of a bundled OS allows IT teams to standardize on current versions and apply their own licensing, security policies, and configuration management tools.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
The blade server measures 2.20" in height, 8.60" in width, and 19.40" in depth, with an approximate weight of 15.60 lb. This compact form factor is designed to slide into a Lenovo Flex System chassis, which provides shared power supplies, cooling fans, and network switches. The blade's physical design emphasizes serviceability, with tool-less installation and hot-swap capabilities for drives and other components when used within the supported chassis.
- Width
- 8.60" (218.44 mm)
- Depth
- 19.40" (492.76 mm)
- Height
- 2.20" (55.88 mm)
- Weight
- 15.60 lb (7076.04 g)
What's in the Box
The package includes the Flex System x240 7162C4U server unit, a statement of limited warranty, important notices, and a documentation CD. This provides all necessary hardware and basic documentation to begin installation and configuration.
Highlights
- Intel Xeon E5-2630 v2 hexa-core processor at 2.60 GHz for enterprise performance
- 16 GB DDR3 SDRAM installed with 24 memory slots for extensive expansion
- 2 internal 2.5" drive bays with 6Gb/s SAS and SATA controller
- Hardware RAID support for levels 0, 1, and 1E to protect critical data
- 10 Gigabit Ethernet for high-speed network connectivity in data centers
- Blade form factor optimized for density and energy efficiency in Flex System chassis
- Remote management capabilities for out-of-band administration and monitoring
- Three USB ports for peripheral connectivity and maintenance tasks
- Supports up to two processors for future compute scalability
- 3-year limited warranty for reliable long-term deployment
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7162C4U |
| Brand Name | Lenovo |
| Product Line | Flex System |
| Product Series | x240 |
| Product Model | 7162C4U |
| Product Name | Flex System x240 7162C4U Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | E5-2630 v2 |
| Processor Core | Hexa-core (6 Core) |
| Processor Speed | 2.60 GHz |
| Cache | 15 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C600 |
| Memory | |
| Standard Memory | 16 GB |
| Memory Technology | DDR3 SDRAM |
| Total Number of Memory Slots | 24 |
| Controllers | |
| Controller Type | 6Gb/s SAS,Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 1E |
| I/O Expansions | |
| Number of Total Expansion Bays | 2 |
| Number of Internal 2.5" Bays | 2 |
| Total Number of Expansion Slots | 2 |
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 3 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Operating System | |
| Operating System | No |
| Miscellaneous | |
| Package Contents | Flex System x240 7162C4U Server Statement of Limited Warranty Important Notices Documentation CD |
| Physical Characteristics | |
| Form Factor | Blade |
| Height | 2.20" (55.88 mm) |
| Width | 8.60" (218.44 mm) |
| Depth | 19.40" (492.76 mm) |
| Weight (Approximate) | 15.60 lb (7076.04 g) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What processor is installed in this Lenovo blade server?
The server comes with one Intel Xeon E5-2630 v2 processor installed. This is a hexa-core CPU running at 2.60 GHz with 15 MB of cache, providing robust performance for virtualization, database, and general business workloads.
How much memory does the server have and can it be expanded?
It includes 16 GB of DDR3 SDRAM standard. The server has 24 memory slots total, allowing significant expansion beyond the installed capacity to meet growing application demands, with support for dual-processor configurations when upgraded.
What storage options are available on this blade server?
The server features two internal 2.5" drive bays, controlled by a 6Gb/s SAS and Serial ATA/600 controller. It supports hardware RAID 0, 1, and 1E, enabling administrators to configure storage for performance, redundancy, or a balance of both based on workload requirements.
What networking capabilities does the server provide?
Integrated 10 Gigabit Ethernet delivers high-speed network connectivity, essential for data-intensive applications and virtualized environments. The server also includes three USB ports for peripherals and supports remote management for efficient administration.
Is an operating system included with this server?
No, the server ships without a pre-installed operating system. This allows organizations to install their preferred OS, such as Windows Server, Linux, or a virtualization hypervisor, applying their own licensing and security configurations.
What is the form factor and how does it fit into a data center?
This is a blade server designed for the Lenovo Flex System chassis. Its compact dimensions (2.20" H x 8.60" W x 19.40" D) allow multiple blades to be housed in a single chassis, sharing power, cooling, and networking for high-density, efficient data center deployments.
What processor or CPU is listed for this server or storage platform?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 2.60 GHz processor for everyday performance and multitasking.
