Lenovo 30GA0087US ThinkStation P5 Workstation - Xeon w5-2455 x 12-Core 3. 20 GHz - 64 GB DDR5 - 2 TB NVMe SSD - Windows 11 Pro for Workstations
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ThinkStation P5 is the Intel Xeon w5-2455X processor, a 12-core CPU with a base clock of 3.20 GHz and support for Intel vPro technology for enhanced security and remote management capabilities. The processor interfaces with the system through the Intel W790 chipset, which provides the foundation for the workstation's expansion and I/O capabilities.
Memory architecture features eight DDR5 slots populated with four 16 GB modules for 64 GB total capacity, with support for up to 512 GB of ECC Registered memory. The DDR5 technology delivers higher bandwidth and improved power efficiency compared to previous generations, while ECC ensures data accuracy for critical computations.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This workstation combines enterprise-grade components with professional validation to deliver reliable performance for demanding applications. The dedicated graphics controller with 24 GB of memory accelerates visualization tasks without taxing the main system memory, while the comprehensive connectivity options ensure compatibility with professional peripherals and network environments.
Professional-Grade Storage
The 2 TB NVMe SSD utilizes the PCI Express 4.0 interface for sequential read/write speeds that dramatically reduce application load times and file transfer durations. The NVMe controller manages data flow efficiently for sustained performance during extended workloads.
- PCI Express NVMe 4.0 x4 interface
- 2 TB capacity for large project files
- Faster than SATA SSDs for data-intensive tasks
Comprehensive Connectivity
Ten USB ports include multiple high-speed options with two USB-C 3.2 Gen 2 ports and one USB-C port supporting 20 Gbps transfer rates. Gigabit Ethernet provides reliable wired networking, while integrated wireless LAN and Bluetooth enable flexible connectivity options.
- 10 total USB ports
- 3x USB-C including 20 Gbps variant
- Gigabit Ethernet + Wireless LAN
Deployment / Use Cases
The ThinkStation P5 30GA0087US is optimized for professional environments where computational accuracy and system stability are paramount. Engineering firms will appreciate the ECC memory protection during finite element analysis and computational fluid dynamics simulations, while media production studios can leverage the dedicated graphics memory for real-time video editing and color grading.
Scientific research applications benefit from the multi-core processor architecture when running parallelized computations, and financial modeling teams can utilize the large memory capacity for in-memory analytics. The workstation's 1 kW power supply ensures stable operation even when fully loaded with additional expansion cards or storage devices.
Engineering & Simulation
Run complex CAD/CAM applications, finite element analysis, and computational fluid dynamics simulations with confidence in data integrity thanks to ECC memory protection.
Media Production & Visualization
Accelerate 3D rendering, video editing, and visual effects workflows with dedicated graphics memory and fast NVMe storage for large media files.
Localization and Operating System
This workstation ships with Windows 11 Pro for Workstations pre-installed in English. The professional workstation edition of Windows 11 includes features specifically designed for high-performance computing environments, including support for up to 6 TB of memory (with appropriate hardware), persistent memory support, and enhanced reliability features.
The keyboard localization is English, with standard US layout and key labeling. The operating system language cannot be changed without a complete reinstallation, making this configuration ideal for English-speaking professional environments in North America and other regions using English as the primary business language.
Physical Profile
The ThinkStation P5 utilizes a traditional tower form factor measuring 17.56 inches in height, 6.50 inches in width, and 17.87 inches in depth (446 x 165 x 453.90 mm). This design provides ample internal space for expansion cards, additional storage drives, and cooling components while maintaining a professional appearance suitable for office environments.
Weighing approximately 41.89 pounds (19,000 grams), the workstation is substantial enough to remain stable during operation while still being manageable for IT staff to position in rack enclosures or under desks. The tower orientation allows for efficient thermal management with multiple airflow paths to maintain optimal component temperatures during extended compute sessions.
- Width
- 6.50" (165 mm)
- Depth
- 17.87" (453.90 mm)
- Height
- 17.56" (446 mm)
- Weight
- 41.89 lb (19000 g)
What's in the Box
The workstation ships complete with all necessary components for immediate deployment in a professional environment.
Package contents include ThinkStation P5 30GA0087US Keyboard Mouse, ThinkStation P5 30GA0087US. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Xeon w5-2455X processor with 12 cores and 24 threads for parallel computing
- 64 GB of DDR5 ECC Registered memory operating at 4.80 GHz for data-intensive workloads
- 2 TB NVMe SSD with PCI Express 4.0 interface for rapid data access
- Dedicated graphics controller with 24 GB memory for visualization acceleration
- Windows 11 Pro for Workstations with professional features and security
- Intel vPro technology for enhanced security and remote management
- 10 USB ports including 3x USB-C with high-speed data transfer
- Gigabit Ethernet, Wireless LAN, and Bluetooth connectivity options
- 1 kW power supply for stable operation with expansion components
- 3-year onsite warranty with premier support upgrade option
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30GA0087US |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P5 |
| Product Model | 30GA0087US |
| Product Name | ThinkStation P5 30GA0087US |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | w5-2455X |
| Processor Core | Dodeca-core (12 Core) |
| Processor Threads | 24 |
| Processor Speed | 3.20 GHz |
| Processor Socket | Socket LGA-4677 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W790 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 512 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 4 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 2 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | No |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 24 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro for Workstations |
| Operating System Language | English |
| Power Description | |
| Maximum Power Supply Wattage | 1 kW |
| Physical Characteristics | |
| Height | 17.56" (446 mm) |
| Width | 6.50" (165 mm) |
| Depth | 17.87" (453.90 mm) |
| Weight (Approximate) | 41.89 lb (19000 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P5 30GA0087US Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year, Onsite 3Y Premier Support Upgrade from 3Y Onsite |
User Manual
FAQ
What type of processor does this workstation use?
This Lenovo ThinkStation P5 workstation features an Intel Xeon w5-2455X processor. This is a 12-core (dodeca-core) CPU with 24 threads, operating at a base clock speed of 3.20 GHz. It utilizes the Socket LGA-4677 interface and includes Intel vPro technology for enhanced security and remote management capabilities in business environments.
How much memory is installed and what type is it?
The workstation comes with 64 GB of DDR5 SDRAM installed across four 16 GB modules. The memory operates at 4.80 GHz and features Error Correcting Code (ECC) technology with registered signal processing. This combination ensures data integrity during critical computations while providing high bandwidth for memory-intensive applications. The system has eight total memory slots, supporting expansion up to 512 GB.
What storage configuration does this workstation include?
Storage is provided by a 2 TB solid-state drive utilizing the PCI Express NVMe 4.0 x4 interface. This NVMe SSD delivers significantly faster data transfer speeds compared to SATA-based storage, reducing application load times and improving overall system responsiveness. The storage controller supports both NVMe and Serial ATA protocols, though RAID functionality is not enabled in this configuration.
What operating system is pre-installed?
The workstation ships with Windows 11 Pro for Workstations pre-installed in English. This specialized edition of Windows 11 includes features tailored for high-performance computing environments, such as support for extremely large memory configurations, persistent memory support, and enhanced reliability features. It is designed specifically for professional workloads that demand maximum system stability and performance.
What connectivity options are available?
Connectivity includes 10 USB ports total: 2 USB 2.0 ports, 5 USB 3.2 Gen 2 ports, and 3 USB-C ports (two supporting USB 3.2 Gen 2 and one supporting 20 Gbps transfer rates). Networking features Gigabit Ethernet for wired connections, plus integrated Wireless LAN and Bluetooth for wireless connectivity. The system also includes dedicated graphics outputs through the installed graphics controller.
What are the physical dimensions and warranty terms?
The tower workstation measures 17.56 inches in height, 6.50 inches in width, and 17.87 inches in depth (446 x 165 x 453.90 mm), weighing approximately 41.89 pounds. It includes a 3-year limited warranty with onsite service, specifically a 3-year onsite premier support upgrade from the standard 3-year onsite coverage. The system also carries multiple environmental certifications including EPEAT Gold, TCO Certified 9.0, ENERGY STAR 8.0, and RoHS compliance.
What processor is listed for this desktop or workstation?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 3.20 GHz processor for everyday performance and multitasking.
