Lenovo 30HH004FCA ThinkStation P8 Tower Workstation - Ryzen Threadripper PRO 7985WX 64-Core - 32 GB RAM - 1 TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The ThinkStation P8 leverages AMD's WRX90 platform to support the Ryzen Threadripper PRO 7985WX processor on the sTR5 socket. This 64-core CPU operates at a base frequency of 3.20 GHz and supports 128 simultaneous threads, providing immense parallel processing capability for multithreaded applications.
Memory architecture utilizes eight DDR5 slots with ECC Registered DIMMs running at 4800 MHz, ensuring data integrity and scalability up to 1 TB. Storage is handled by a PCI Express NVMe 4.0 x4 interface delivering exceptional throughput, with RAID 0, 1, 5, and 10 support via the integrated SATA/600 controller.
Connectivity includes dual Ethernet (Gigabit and 10GbE), Wi-Fi, and Bluetooth, plus six USB ports with one USB-C 20Gbps (USB 3.2 Gen 2x2) port and three Mini DisplayPort outputs from the dedicated NVIDIA T400 graphics card.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This workstation combines raw compute power with professional features that distinguish it from consumer-grade systems. The 64-core Threadripper PRO processor delivers exceptional multithreading performance for rendering, simulation, and development tasks, while the NVIDIA T400 graphics provides certified driver support for professional applications.
Dual Ethernet connectivity with 10GbE enables high-speed network storage access, and the comprehensive USB portfolio supports modern peripherals. The French-Canadian localized keyboard ensures seamless integration in Canadian professional environments.
Professional-Grade Reliability
ECC Registered memory and comprehensive RAID support ensure data integrity and availability for critical workloads, while the 3-year Premier Next Business Day onsite warranty provides enterprise-level support.
Expansion Flexibility
The tower form factor offers ample internal space for additional storage drives, expansion cards, and memory upgrades, supported by eight DDR5 slots and multiple PCIe lanes from the WRX90 chipset.
Deployment / Use Cases
The ThinkStation P8 excels in environments where computational intensity meets professional reliability requirements. Its balanced configuration of high-core-count CPU, substantial memory, and professional graphics makes it suitable for engineering firms, research institutions, and media production studios.
For financial modeling, software development, and virtualization scenarios, the system's 128 threads and 1 TB memory expansion capability provide headroom for demanding multitasking. The tower chassis facilitates future upgrades as workload requirements evolve, protecting long-term investment.
Engineering & Design
Ideal for CAD/CAM, finite element analysis, and 3D modeling applications where processor cores and memory bandwidth directly impact productivity and iteration speed.
Scientific Computing
Supports computational research, data science, and simulation workloads that benefit from high core counts, ECC memory protection, and fast NVMe storage.
Localization and Operating System
This workstation ships with Windows 11 Pro 64-bit pre-installed, providing a familiar, secure operating environment with BitLocker encryption, remote desktop capabilities, and enterprise management features. The French-Canadian keyboard localization ensures proper key legends and layout compliance for Canadian French users.
Windows 11 Pro enhances productivity with improved multitasking tools, native security features like Windows Hello, and compatibility with professional software suites. The 64-bit architecture fully utilizes the system's 32 GB of RAM and multicore processor for optimal application performance.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
The tower chassis measures 17.10" (434.4 mm) in height, 6.89" (175 mm) in width, and 20" (508 mm) in depth, with a weight of approximately 50.04 lb (22.7 kg). This substantial form factor provides excellent thermal management for sustained high-performance operation while offering ample internal expansion space.
The design supports standard rack mounting options for data center deployment and includes tool-less access panels for easy maintenance and upgrades. GREENGUARD certification and RoHS compliance demonstrate environmental responsibility in manufacturing.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation ships with the ThinkStation P8 tower system and a matching French-Canadian localized keyboard, providing everything needed for immediate deployment in professional environments.
Highlights
- AMD Ryzen Threadripper PRO 7985WX processor with 64 cores and 128 threads
- 32 GB of DDR5 ECC Registered memory with eight slots supporting up to 1 TB
- 1 TB NVMe PCIe 4.0 x4 SSD for exceptional storage performance
- NVIDIA T400 professional graphics card with 4 GB dedicated memory
- Dual Ethernet ports including 10GbE for high-speed networking
- Windows 11 Pro 64-bit operating system with French-Canadian keyboard
- Tower form factor with tool-less access for easy expansion
- 3-year Premier Next Business Day onsite warranty
- GREENGUARD certified and RoHS compliant
- Comprehensive USB connectivity including USB-C 20Gbps
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH004FCA |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH004FCA |
| Product Name | ThinkStation P8 |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7985WX |
| Processor Core | Tetrahexaconta-core (64 Core) |
| Processor Threads | 128 |
| Processor Speed | 3.20 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Graphics Controller Model | T400 |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | French (Canada) |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 3 |
| USB Type-C | Yes |
| USB Type-C Detail | 1x USB-C (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Mini DisplayPort | Yes |
| Number of Mini DisplayPort | 3 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Architecture | 64-bit |
| Physical Characteristics | |
| Form Factor | Tower |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 Keyboard |
| Environmentally Friendly | Yes |
| Environmental Certification | GREENGUARD |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3YR Premier NBD, Upgrade from 3Y Onsite |
User Manual
FAQ
What processor does this ThinkStation P8 workstation use?
This workstation features the AMD Ryzen Threadripper PRO 7985WX processor, a 64-core CPU with 128 threads operating at a base frequency of 3.20 GHz. Built on AMD's professional platform, it delivers exceptional multithreaded performance for demanding applications like 3D rendering, simulation, and data analysis.
How much memory is installed and what type is it?
The system comes with 32 GB of DDR5 SDRAM installed, utilizing ECC Registered technology for enhanced data integrity. Memory operates at 4800 MHz across eight available slots, with support for expansion up to 1 TB total capacity for memory-intensive workloads.
What storage configuration does this workstation include?
Storage consists of a 1 TB NVMe SSD using the PCI Express 4.0 x4 interface for maximum throughput. The storage controller supports both NVMe and SATA/600 drives with hardware RAID 0, 1, 5, and 10 capabilities for data protection and performance optimization.
What graphics card is installed in this ThinkStation?
This configuration includes the NVIDIA T400 professional graphics card with 4 GB of dedicated GDDR6 memory. This GPU provides certified driver support for CAD, visualization, and professional applications, along with three Mini DisplayPort outputs for multi-monitor setups.
What networking capabilities does this workstation offer?
The system features dual Ethernet connectivity with both Gigabit and 10 Gigabit Ethernet ports for flexible network deployment. It also includes integrated Wi-Fi and Bluetooth for wireless connectivity, supporting a range of networking scenarios from office environments to data center deployments.
What warranty coverage comes with this ThinkStation P8?
Lenovo provides a 3-year Premier Next Business Day onsite warranty with this workstation. This service includes next-business-day onsite repair by a technician, offering enterprise-level support coverage for mission-critical professional environments.
What processor is listed for this desktop or workstation?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 3.20 GHz processor for everyday performance and multitasking.
