Lenovo ThinkSystem NVIDIA ConnectX-7 10/25GbE SFP28 4-Port PCIe Ethernet Adapter - PCI Express 4.0 x16 - Optical Fiber - Full-height, (4XC7A99191)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- ThinkSystem NVIDIA ConnectX-7 10/25GbE SFP28 4-Port PCIe Ethernet Adapter
- Full-height (3U) Bracket Attached with Low Profile (2U) Bracket
- Documentation Flyer
Features: RDMA over Converged Ethernet (RoCE),Single Root I/O Virtualization (SR-IOV),Virtual Extensible LAN (VXLAN),Network Virtualization using Generic Routing Encapsulation (NVGRE),UEFI Support,PXE Support,Extended Message-Signaled Interrupts (MSI-X),Generic Network Virtualization Encapsulation (GENEVE),TCP Segmentation Offload (TSO),RDMA Support
Host Interface: PCI Express 4.0 x16
Total Number of Expansion Slots: 4
Expansion Slot Type: SFP28
Media Type Supported: Optical Fiber
Network Technology: 25GBase-X,10GBase-X
Form Factor: Plug-in Card
Bracket Height: Full-height, Low profile
Height: 2.72" (69 mm)
Package Contents:
Device Supported: Server
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 1 Year
- Accelerated Networking and Security: ConnectX-7 provides a broad set of software-defined, hardware-accelerated networking, storage, and security capabilities which enable organizations to modernize and secure their IT infrastructures. Moreover, ConnectX-7 empowers agile and high-performance solutions from edge to core data centers to clouds, all while enhancing network security and reducing the total cost of ownership.
- Accelerate Data-Driven Scientific Computing: ConnectX-7 provides ultra-low latency, extreme throughput, and innovative NVIDIA In-Network Computing engines to deliver the acceleration, scalability, and feature- rich technology needed for today's modern scientific computing workloads.
- Accelerate Software- Defined Networking: NVIDIA ASAP technology accelerates software-defined networking, delivering line-rate performance with no CPU penalty.
- Enhance Storage Performance: ConnectX-7 enables high-performance and efficient data storage by leveraging RDMA/RoCE, GPUDirect Storage, and hardware-based NVMe-oF offload engines.
[custom-specifications]
| Specifications | |
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 4XC7A99191 |
| Manufacturer Website Address | http://www.lenovo.com |
| Brand Name | Lenovo |
| Product Line | ConnectX-7 |
| Product Name | ThinkSystem NVIDIA ConnectX-7 10/25GbE SFP28 4-Port PCIe Ethernet Adapter |
| Packaged Quantity | 1 |
| Product Type | 10/25Gigabit Ethernet Card |
| Technical Information | |
| Features | RDMA over Converged Ethernet (RoCE),Single Root I/O Virtualization (SR-IOV),Virtual Extensible LAN (VXLAN),Network Virtualization using Generic Routing Encapsulation (NVGRE),UEFI Support,PXE Support,Extended Message-Signaled Interrupts (MSI-X),Generic Network Virtualization Encapsulation (GENEVE),TCP Segmentation Offload (TSO),RDMA Support |
| Interfaces/Ports | |
| Host Interface | PCI Express 4.0 x16 |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP28 |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Network & Communication | |
| Network Technology | 25GBase-X,10GBase-X |
| Physical Characteristics | |
| Form Factor | Plug-in Card |
| Bracket Height | Full-height, Low profile |
| Height | 2.72" (69 mm) |
| Miscellaneous | |
| Package Contents |
|
| Device Supported | Server |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
[/custom-specifications]
