Minuteman ED6KRT-5KTF Endeavor 6000VA Rack/Tower UPS - 4U Double Conversion Online - 5. 18kW - 120/230V Input - 208/220/230/240V Output
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This UPS delivers 6 kVA (5.18 kW) of power capacity with a 0.9 power factor, supporting single-phase operation across wide input voltage ranges. The unit accepts 120V or 230V AC input and provides flexible output voltages including 208V, 220V, 230V, and 240V configurations.
The double-conversion online topology ensures complete isolation from utility power issues, while the automatic internal bypass and Independent Battery Bypass (IBB) maintain continuous operation during maintenance or fault conditions.
This section brings together practical product details such as Plug/Connector Type, Phase, Efficiency Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Endeavor ED6KRT-5KTF combines enterprise-grade power protection with flexible deployment options for data centers, server rooms, and industrial applications. Its rack/tower convertible design accommodates both standard rack mounting and standalone tower installation.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Advanced Battery Management, Comprehensive Monitoring.
Advanced Battery Management
Hot-swappable batteries enable maintenance without downtime, while smart fan control optimizes cooling and extends component life.
- Replaceable battery design
- 7-minute runtime at half load
- Cold start capability
Comprehensive Monitoring
RS-232 and USB connectivity support integration with network management systems, while the EPO port enables emergency power-off functionality.
- Multi-function LCD touchscreen
- Serial communication interface
- EPO safety port
Deployment / Use Cases
This UPS is engineered for IT, telecommunications, security systems, business infrastructure, servers, networks, industrial applications, enterprise installations, corporate environments, and VoIP deployments. Its robust construction and wide operating parameters make it suitable for diverse commercial and industrial settings.
The 4U rack-mountable form factor optimizes data center space utilization, while the tower configuration supports standalone deployment in server rooms or equipment closets. The unit's 15000-foot maximum operating elevation and wide temperature range ensure reliable performance in challenging environments.
This section brings together practical product details such as Plug/Connector Type, Phase, Efficiency Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
The Endeavor ED6KRT-5KTF measures 10.22" H × 17.24" W × 23.82" D (259.59 × 437.90 × 605.03 mm) and occupies 4U of rack space. At 243.54 pounds, the unit features a sturdy construction suitable for rack mounting with proper support. The rack/tower convertible design includes mounting hardware for both installation methods.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 10.22" (259.59 mm), 17.24" (437.90 mm), 243.54 lb (110467.89 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.24" (437.90 mm)
- Height
- 10.22" (259.59 mm)
- Weight
- 243.54 lb (110467.89 g)
- Length
- 23.82" (605.03 mm)
What's in the Box
The package includes the Endeavor ED6KRT-5KTF 6000VA Rack/Tower UPS unit and necessary communication cables for immediate deployment.
Package contents include Endeavor ED6KRT-5KTF 6000VA Rack/Tower UPS Comm. Cables, Endeavor ED6KRT-5KTF 6000VA Rack/Tower UPS. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 6000VA/5.18kW double-conversion online UPS
- Rack/tower convertible 4U form factor
- True sine wave output with 93% efficiency
- 2-minute full load, 7-minute half load runtime
- 120V/230V input, multi-voltage output (208-240V)
- Hot-swappable, replaceable batteries
- Color LCD touchscreen with intuitive interface
- RS-232 and USB management connectivity
- ENERGY STAR 2.0 and RoHS 2 compliant
- 3-year warranty covering electronics and batteries
Specifications
| Specifications | |
|---|---|
| Manufacturer | Para Systems, Inc |
| Manufacturer Part Number | ED6KRT-5KTF |
| Brand Name | Minuteman |
| Product Line | Endeavor |
| Product Model | ED6KRT-5KTF |
| Product Name | Endeavor ED6KRT-5KTF 6000VA Rack/Tower UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | Hardwired |
| Phase | Single Phase |
| Efficiency Detail | 93% (AC Mode) |
| Application/Usage | IT,Telecommunication,Security,Business,Infrastructure,Server,Network,Industrial,Enterprise Installation,Corporate,VoIP |
| Surge Suppression | Yes |
| Features | Cold Start Function |
| Power Description | |
| Load Capacity (VA) | 6 kVA |
| Load Capacity (Watt) | 5.18 kW |
| Input Voltage | 120 V AC,230 V AC |
| Input Voltage Range | 0 V AC - 300 V AC,156 V AC - 280 V AC |
| Input Current | 38 A |
| Output Voltage | 208 V AC,220 V AC,230 V AC,240 V AC,120 V AC,110 V AC,115 V AC |
| Input Frequency | 40 Hz,70 Hz |
| Output Frequency | 50 Hz,60 Hz |
| Waveform Type | True Sine Wave |
| Surge Energy Rating | 3140 J |
| Circuit Breaker | Yes |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | RS-232 |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| EPO Port | Yes |
| Battery Information | |
| Backup/Run Time (Full Load) | 2 Minute |
| Backup/Run Time (Half Load) | 7 Minute |
| Hot Swappable | Yes |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Elevation | 15000 ft (4572000 mm) |
| Maximum Storage Elevation | 50000 ft (15240000 mm) |
| Storage Temperature | 5°F (-15°C) - 131°F (55°C) |
| Operating Humidity | 0% - 95% |
| Storage Relative Humidity | 0% - 95% |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Physical Characteristics | |
| Height | 10.22" (259.59 mm) |
| Width | 17.24" (437.90 mm) |
| Length | 23.82" (605.03 mm) |
| Rack Height | 4U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 243.54 lb (110467.89 g) |
| Miscellaneous | |
| Package Contents | Endeavor ED6KRT-5KTF 6000VA Rack/Tower UPS Comm. Cables |
| Energy Star | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2 |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3 Years (Electronics and Batteries) |
User Manual
FAQ
What is the power capacity of this Minuteman UPS?
The Endeavor ED6KRT-5KTF provides 6000VA (6 kVA) of apparent power and 5.18 kW of real power capacity with a 0.9 power factor. This capacity supports critical IT equipment including servers, network gear, and telecommunications systems during power disturbances.
How long does the battery backup last during an outage?
At full load, the UPS provides 2 minutes of runtime, while at half load it delivers 7 minutes of backup power. These runtime figures allow for orderly shutdown of connected equipment or transition to generator power in extended outage scenarios.
What input voltages does this UPS support?
The unit accepts 120V AC or 230V AC input with wide input ranges from 0-300V AC and 156-280V AC. This flexibility allows deployment in different electrical environments without requiring voltage conversion equipment.
Can this UPS be mounted in a standard server rack?
Yes, the Endeavor ED6KRT-5KTF is designed for 4U rack mounting with dimensions of 10.22" H × 17.24" W × 23.82" D. It also functions as a standalone tower unit, providing deployment flexibility for data centers, server rooms, and equipment closets.
What management interfaces are available for monitoring?
The UPS includes RS-232 serial connectivity and USB ports for integration with network management systems. The multi-function color LCD touchscreen provides local status monitoring, while the EPO port enables emergency power-off functionality for safety compliance.
Are the batteries replaceable without downtime?
Yes, the hot-swappable battery design allows replacement without interrupting power to connected equipment. The replaceable batteries and cold start function ensure continuous operation during maintenance procedures and extended outage situations.
What power capacity is listed for this UPS?
The listed power specification is 6 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 120 V AC,230 V AC, which helps position the unit for the right load level and installation role.
