MSI PRDP20ZA5M059 PRO DP20ZA Small Form Factor Desktop - AMD Ryzen 5 5600G Hexa-core - 8 GB DDR4 RAM - 250 GB NVMe SSD - Windows 10 Pro - Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the PRO DP20ZA is the AMD Ryzen 5 5600G processor, a 6-core, 12-thread APU with a base clock of 3.90 GHz and a maximum turbo frequency of 4.40 GHz. It is paired with the AMD B300 chipset, forming a stable platform for business computing. System memory is 8 GB of DDR4 SDRAM installed in a dual-channel 2 x 4GB configuration, supporting efficient data handling.
Storage is handled by a single 250 GB M.2 NVMe solid-state drive using the PCI Express interface, offering significantly faster boot times, application loading, and file access compared to traditional hard drives. The integrated AMD Radeon Vega 7 Graphics provides capable on-board visuals for HD video playback, photo editing, and driving multiple displays, utilizing shared system memory.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The PRO DP20ZA balances a professional feature set with a remarkably compact footprint. Its integrated design eliminates the need for a discrete graphics card in many scenarios, reducing power draw and complexity while the small form factor chassis maximizes desk space.
Space-Efficient Performance
The Ryzen 5 5600G APU combines a capable CPU and GPU in one package, delivering strong performance for office productivity, web applications, and media tasks without requiring additional card slots in the compact chassis.
- Hexa-core processing power
- Integrated Radeon Vega 7 graphics
- Low 120W power design
Modern Connectivity Suite
Equipped with both legacy and next-generation ports, including a front-panel USB Type-C port, to connect a wide array of peripherals, displays, and storage devices.
- Front USB 3.2 Gen2 Type-C
- Gigabit Ethernet & Wi-Fi 6
- Multiple USB 2.0/3.2 ports
Deployment / Use Cases
This desktop is ideally suited for general office workstations, point-of-sale systems, digital signage controllers, or as a compact PC for educational and administrative roles. Its size and VESA mount capability make it perfect for environments with limited space, such as retail counters, call centers, or shared workspaces.
The combination of Windows 10 Pro, capable integrated graphics, and fast NVMe storage supports efficient multitasking across business software, web browsers, and communication tools. It serves as a reliable hub for daily productivity, light creative work, and managing multiple peripheral devices through its comprehensive port selection.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Localization and Operating System
The system ships with a full license for Microsoft Windows 10 Pro, providing enhanced security, management, and networking features crucial for business environments. This OS includes BitLocker encryption, Remote Desktop, and greater control over updates and policies.
It is certified for an upgrade path to Windows 11, ensuring future software compatibility. The hardware and software configuration is standardized for the US market, with the operating system and drivers configured accordingly for immediate use upon setup.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Housed in a sleek black small form factor case, the PRO DP20ZA measures just 7.61" high, 3.35" wide, and 6.32" deep, with a weight of approximately 3.35 lbs. This compact design allows for flexible placement on or under a desk, on a shelf, or mounted out of sight.
The rear panel includes a standard 75mm x 75mm VESA mount pattern, enabling secure attachment to the back of compatible monitors or mounting arms for a clean, all-in-one appearance. The finish is a professional matte black, suitable for any office aesthetic.
- Width
- 3.35" (85.09 mm)
- Depth
- 6.32" (160.53 mm)
- Height
- 7.61" (193.29 mm)
- Weight
- 3.35 lb (1519.53 g)
What's in the Box
The retail package includes all essential components to get the system up and running immediately.
Highlights
- AMD Ryzen 5 5600G hexa-core APU with Radeon Vega 7 integrated graphics
- 8 GB of DDR4 RAM in a dual-channel configuration for responsive multitasking
- 250 GB PCIe NVMe M.2 SSD for fast boot times and application loading
- Windows 10 Pro operating system with a clear upgrade path to Windows 11
- Compact Small Form Factor black chassis with a minimal desktop footprint
- VESA 75x75 mount compatible for space-saving behind-monitor installation
- Comprehensive connectivity: Gigabit Ethernet, Wi-Fi 6, and 6 USB ports including front Type-C
- Energy-efficient 120W power supply with ErP compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | MSI |
| Manufacturer Part Number | PRDP20ZA5M059 |
| Brand Name | MSI |
| Product Series | PRO DP20ZA 5M |
| Product Model | Pro DP20ZA 5M-059US |
| Product Name | Pro DP20ZA 5M-059US Desktop Computer |
| Package Type | Retail |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | AMD |
| Processor Type | Ryzen 5 |
| Processor Model | 5600G |
| Processor Core | Hexa-core (6 Core) |
| Processor Speed | 3.90 GHz |
| Maximum Turbo Speed | 4.40 GHz |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | B300 |
| Memory | |
| Standard Memory | 8 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Configuration | 2 x 4GB |
| Storage | |
| Total Solid State Drive Capacity | 250 GB |
| Solid State Drive Interface | PCI Express NVMe |
| SSD Form Factor | M.2 |
| Solid State Drive Configuration | 1 x 250GB |
| Display & Graphics | |
| Graphics Controller Manufacturer | AMD |
| Graphics Controller Model | Radeon Vega 7 Graphics |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| LAN Model | RTL8111H |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 2.0 Ports (Rear) | 3 |
| Number of USB 3.2 Gen 2 Ports | 2 |
| USB Type-C (Front) | Yes |
| USB Type-C Detail | 1 x USB 3.2 Gen2 Type-C |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 10 Pro |
| Upgradable Operating System | Windows 11 |
| Power Description | |
| Maximum Power Supply Wattage | 120 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Small Form Factor |
| VESA Mount Standard | 75 x 75 |
| Height | 7.61" (193.29 mm) |
| Width | 3.35" (85.09 mm) |
| Depth | 6.32" (160.53 mm) |
| Weight (Approximate) | 3.35 lb (1519.53 g) |
| Miscellaneous | |
| Package Contents | Pro DP20ZA 5M-059US Desktop Computer AC Adapter |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What processor is in the MSI PRO DP20ZA desktop?
This desktop is powered by an AMD Ryzen 5 5600G processor. It is a hexa-core (6-core) APU with a base clock speed of 3.90 GHz and a maximum turbo frequency of 4.40 GHz. This processor also integrates AMD Radeon Vega 7 graphics, providing solid performance for both general computing and light graphical tasks without requiring a separate graphics card.
How much memory and storage does this computer have?
The system comes configured with 8 GB of DDR4 SDRAM, installed as two 4 GB modules to enable dual-channel operation for better memory bandwidth. For storage, it includes a 250 GB M.2 solid-state drive that uses the high-speed PCI Express NVMe interface, offering significantly faster data access and system responsiveness compared to SATA-based drives.
What operating system does it come with, and can it be upgraded?
It comes pre-installed with a full license for Microsoft Windows 10 Pro, which includes business-oriented features like BitLocker and enhanced networking tools. The hardware meets the requirements for Windows 11, and Microsoft provides a clear, supported upgrade path to Windows 11, ensuring long-term software compatibility and security updates.
What are the physical dimensions, and is it mountable?
The PRO DP20ZA is a Small Form Factor desktop measuring 7.61 inches in height, 3.35 inches in width, and 6.32 inches in depth, weighing about 3.35 lbs. Yes, it is designed for flexible deployment. The chassis supports a standard 75mm x 75mm VESA mount, allowing you to securely attach it to the back of a compatible monitor or a VESA arm to save valuable desk space.
What connectivity and ports are available?
The desktop offers comprehensive connectivity. For networking, it has a Gigabit Ethernet port (RTL8111H controller) and built-in Wi-Fi 6 (802.11ax) for fast wireless connections. It provides a total of six USB ports: three USB 2.0 ports on the rear, two USB 3.2 Gen 2 ports, and one front-panel USB 3.2 Gen 2 Type-C port for modern peripherals.
Is this system suitable for business or office use?
Absolutely. The combination of the AMD Ryzen 5 processor, 8 GB of RAM, a fast NVMe SSD, and Windows 10 Pro makes it an excellent choice for general office productivity, administrative tasks, point-of-sale systems, and light multimedia work. Its compact size, quiet operation, and professional OS are tailored for business environments where reliability and space efficiency are priorities.
