Netgear GS324-200NAS 24-Port Gigabit Ethernet Switch - Layer 2 - Desktop/Wall/Rack Mount - 10/100/1000Base-T - Fanless
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This unmanaged switch provides 24 Gigabit Ethernet ports with a dedicated uplink port for network expansion. The Layer 2 architecture supports IGMP snooping, port mirroring, and spanning tree protocols, offering a complete feature set for basic network segmentation and traffic management.
The switch complies with multiple IEEE networking standards including 802.3ab, 802.3u, 802.3i, 802.3x, 802.1p, 802.3, and 802.3az for energy-efficient Ethernet operation. With a maximum data transfer rate of 128 MB/s, it handles high-speed data transmission across all connected devices.
Relevant factors for this section include Features, Total Number of Network Ports, Network (RJ-45), Uplink Port. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The GS324 combines plug-and-play simplicity with robust networking capabilities, eliminating the need for configuration or ongoing management. Its energy-efficient design reduces operational costs while the fanless construction ensures silent operation in office environments.
Flexible Deployment Options
Multiple mounting options including desktop, wall, enclosure, and rack installation provide deployment flexibility for various office layouts and network closet configurations.
- Desktop placement for open office areas
- Wall mounting for space-constrained locations
- Rack installation for organized network closets
Network Protection Features
Built-in security features protect your network infrastructure without requiring technical expertise or additional software.
- Auto Denial of Service prevention
- LED indicators for port status monitoring
- Standard-compliant network protocols
Deployment / Use Cases
The Netgear GS324 is ideal for small businesses, home offices, and educational environments requiring reliable wired networking without management complexity. Its desktop-friendly form factor makes it suitable for deployments outside traditional wiring closets, while rack-mount capability supports organized network infrastructure.
Common deployment scenarios include expanding existing networks with additional wired connections, creating segmented network zones for different departments, and establishing backbone connectivity between workstations and servers. The uplink port enables cascading to additional switches for network expansion as business needs grow.
Small Office Networking
Connect multiple workstations, printers, and network devices in office environments with consistent Gigabit speeds and reliable connectivity.
Educational & Training Facilities
Deploy in computer labs and classroom settings where simple, dependable networking supports multiple simultaneous connections without configuration overhead.
Physical Profile
Measuring 1.73" (44 mm) in height, 9.92" (252 mm) in width, and 7.09" (180 mm) in depth, the GS324 maintains a compact footprint suitable for various installation scenarios. The 2.89 lb (1310 g) weight and durable metal-plastic construction ensure stability while the included rubber footpads provide secure desktop placement.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.73" (44 mm), 9.92" (252 mm), 7.09" (180 mm), 2.89 lb (1310 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 9.92" (252 mm)
- Depth
- 7.09" (180 mm)
- Height
- 1.73" (44 mm)
- Weight
- 2.89 lb (1310 g)
What's in the Box
The package includes all necessary components for immediate deployment and flexible installation options.
Highlights
- 24 Gigabit Ethernet ports for extensive wired network connectivity
- Layer 2 switching with IGMP snooping, port mirroring, and spanning tree support
- Fanless design for silent operation in office environments
- Energy-efficient operation with just 11.10 W power consumption
- Multiple mounting options: desktop, wall, enclosure, and rack
- Auto Denial of Service prevention for basic network security
- Plug-and-play installation with no configuration required
- Uplink port for network expansion and cascading
- Supports twisted pair cabling up to 100 meters
- 3-year limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Netgear, Inc |
| Manufacturer Part Number | GS324-200NAS |
| Brand Name | Netgear |
| Product Line | Business |
| Product Series | 300 |
| Product Model | GS324 |
| Product Name | Business GS324 Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Fanless,Energy Efficient,Auto Denial of Service (DoS) Prevention,LED Indicator,Plug and Play |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Maximum Data Transfer Rate | 128 MB/s |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3ab,IEEE 802.3u,IEEE 802.3i,IEEE 802.3x,IEEE 802.1p,IEEE 802.3,IEEE 802.3az |
| Management & Protocols | |
| Manageable | No |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | AC |
| Power Consumption | 11.10 W |
| Physical Characteristics | |
| Product Material | Metal,Plastic |
| Form Factor | Desktop,Wall Mountable,Enclosure,Rack-mountable |
| Height | 1.73" (44 mm) |
| Width | 9.92" (252 mm) |
| Depth | 7.09" (180 mm) |
| Weight (Approximate) | 2.89 lb (1310 g) |
| Miscellaneous | |
| Package Contents | Business GS324 Ethernet Switch Power Cord Rack Mount Kit Rubber Footpads Installation Guide |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
How many devices can I connect to the Netgear GS324 switch?
The Netgear GS324 provides 24 Gigabit Ethernet ports, allowing you to connect up to 24 wired devices simultaneously. This includes computers, printers, network storage devices, and other Ethernet-enabled equipment. The dedicated uplink port enables further network expansion by connecting to additional switches or network infrastructure.
Is this switch managed or unmanaged?
The GS324 is an unmanaged switch, meaning it operates with plug-and-play simplicity without requiring configuration or ongoing management. This makes it ideal for environments where technical expertise is limited or where basic networking functionality without complex features is sufficient. The switch automatically handles network traffic and includes basic Layer 2 features like IGMP snooping and spanning tree protocol.
What mounting options are available for this switch?
The GS324 supports multiple mounting configurations including desktop placement, wall mounting, enclosure installation, and rack mounting. The package includes a rack mount kit and rubber footpads for flexible deployment. This versatility allows installation in various environments from open office areas to organized network closets, adapting to different space constraints and organizational preferences.
Does this switch support Power over Ethernet (PoE)?
No, the Netgear GS324 does not support Power over Ethernet. It provides standard Gigabit Ethernet connectivity without PoE capability. If you require PoE to power devices like IP cameras, wireless access points, or VoIP phones, you would need to consider a different switch model specifically designed with PoE functionality and appropriate power budgeting.
What type of cables does this switch support?
The GS324 supports twisted pair Ethernet cables, specifically Cat5e, Cat6, or higher categories. These cost-effective cables support data transfer up to 100 meters at Gigabit speeds. The switch is compatible with 10/100/1000Base-T networking standards, ensuring interoperability with standard Ethernet infrastructure commonly deployed in business environments.
What is the power consumption of this switch?
The Netgear GS324 consumes approximately 11.10 watts during operation, making it an energy-efficient choice for continuous use. This low power draw, combined with the fanless design, reduces both electricity costs and heat generation. The switch accepts input voltages of 120V AC or 230V AC, providing compatibility with standard North American and international power systems.
