Opticon L-46R Laser Scanner - Cable Connectivity - 100 scan/s - 35.24" (895.10 mm) Scan Distance - 1D - Laser - Bi-directional - USB - (L46RBU1-00)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- UPC-A
- UPC-E
- UPC-E1
- UPC-A Add-on
- UPC-E Add-on
- EAN-13
- EAN-8
- EAN-13 Add-on/EAN8 Add-on
- JAN-8
- JAN-13
- Code 39
- NW-7(Codabar)
- Industrial 2 of 5
- Interleaved 2 of 5
- Code 93
- Code 128
- GS1-128,
- MSI/Plessey
- Code 11
- OCR-B
- GS1 DataBar
- GS1 DataBar Limited
- GS1 DataBar Expanded
- Composite GS1 DataBar
- Composite GS1-128
- Composite EAN
- Composite UPC
- TELEPEN
- 1.8 m / 6 ft drop onto concrete surface
- L-46R Laser Scanner
- Stand
Connectivity Technology: Cable
Scanning Capability: 1D
Barcode Symbology Supported:
1D:
Light Source: Laser
Scan Rate: 100 scan/s
Scan Mode: Trigger
Scan Pattern: Bi-directional
Scanning Distance: 35.24" (895.10 mm)
Number of Keys: 1
Reading Angle (Skew): 50°
Reading Angle (Pitch): 35°
Maximum Ambient Light: 80000 lux
Drop Specification:
Minimum Element Resolution (Code 39): 5 mil (0.13 mm)
Maximum Element Resolution (Code 39): 39 mil (0.99 mm)
Features: Notification LED,Vibration,Ergonomic Design,Scan Button
Host Interface: USB
Operating Temperature: 23°F (-5°C) to 122°F (50°C)
Storage Temperature: -22°F (-30°C) to 140°F (60°C)
Humidity (Non-condensing): 5% to 90%
Form Factor: Handheld
Color Family: Black
Product Color: Black
Durability: Dust Resistant,Water Resistant
Height: 6.04" (153.42 mm)
Width: 4.15" (105.41 mm)
Depth: 2.36" (59.94 mm)
Weight (Approximate): 3.92 oz (111 g)
Package Contents:
Ingress Protection (IP) Rating: IP42
Application/Usage: Retail,Warehouse,Distribution,Healthcare,Transportation,Logistics,Pharmacy
Environmental Compliance: Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Limited Warranty: 2 Year
- Scan barcodes with a staggering speed of 100 scan/s
- With laser scanning technology you don't have to use any additional lighting as it works effectively in low ambient lighting conditions too
- Wired connectivity makes this scanner ideal for retail and desktop applications
[custom-specifications]
| Specifications | |
| Manufacturer | Opticon Sensors Europe |
| Manufacturer Part Number | L46RBU1-00 |
| Manufacturer Website Address | http://www.opticon.com |
| Brand Name | Opticon |
| Product Model | L-46R |
| Product Name | L-46R Laser Scanner |
| Packaged Quantity | 1 Each |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D |
| Barcode Symbology Supported | 1D:
|
| Light Source | Laser |
| Scan Rate | 100 scan/s |
| Scan Mode | Trigger |
| Scan Pattern | Bi-directional |
| Scanning Distance | 35.24" (895.10 mm) |
| Number of Keys | 1 |
| Reading Angle (Skew) | 50° |
| Reading Angle (Pitch) | 35° |
| Maximum Ambient Light | 80000 lux |
| Drop Specification |
|
| Minimum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Maximum Element Resolution (Code 39) | 39 mil (0.99 mm) |
| Features | Notification LED,Vibration,Ergonomic Design,Scan Button |
| Interfaces/Ports | |
| Host Interface | USB |
| Environmental Conditions | |
| Operating Temperature | 23°F (-5°C) to 122°F (50°C) |
| Storage Temperature | -22°F (-30°C) to 140°F (60°C) |
| Humidity (Non-condensing) | 5% to 90% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Color Family | Black |
| Product Color | Black |
| Durability | Dust Resistant,Water Resistant |
| Height | 6.04" (153.42 mm) |
| Width | 4.15" (105.41 mm) |
| Depth | 2.36" (59.94 mm) |
| Weight (Approximate) | 3.92 oz (111 g) |
| Miscellaneous | |
| Package Contents |
|
| Ingress Protection (IP) Rating | IP42 |
| Application/Usage | Retail,Warehouse,Distribution,Healthcare,Transportation,Logistics,Pharmacy |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
[/custom-user-manual]
