Opticon OPC-3301i CCD Barcode Scanner - Wireless Connectivity - 300 scan/s - 19.69" (500.13 mm) Scan Distance - 1D - LED - CCD, Linear (OPC3301I-00)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- JAN/UPC/EAN incl. add on
- Codabar/NW-7
- Code 11
- Code 39
- Code 93
- Code 128
- GS1-128 (EAN-128)
- GS1 DataBar (RSS)
- IATA
- Industrial 2of5
- Interleaved 2of5
- ISBN-ISSN -ISMN
- Matrix 2of5
- MSI/Plessey
- S-Code
- Telepen
- Tri-Optic
- UK/Plessey
- Chinese Post
- Korean Postal Authority code
Connectivity Technology: Wireless
Scanning Capability: 1D
Barcode Symbology Supported:
Barcode (1D):
Postal Code:
Light Source: LED
Image Sensor Type: CCD,Linear
Scan Rate: 300 scan/s
Scan Mode: Trigger
Scanning Distance: 19.69" (500.13 mm)
Number of Keys: 1
Reading Angle (Skew): 65°
Reading Angle (Pitch): 50°
Reading Angle (Roll): 25°
Maximum Ambient Light: 100000 lux
Drop Specification:
5 ft (1.5 m) drop onto concrete surface
Minimum Element Resolution (Code 39): 5 mil (0.13 mm)
Maximum Element Resolution (Code 39): 40 mil (1.02 mm)
Features: Vibration,Ergonomic Design
Standard Memory: 1 MB
Flash Memory: 1 MB
Bluetooth: Yes
Standby Current: 15 mA
Battery Chemistry: Lithium Ion (Li-Ion)
Battery Capacity: 1100 mAh
Maximum Battery Recharge Time: 3 Hour
Operating Temperature: 32°F (0°C) to 122°F (50°C)
Storage Temperature: -4°F (-20°C) to 140°F (60°C)
Humidity (Non-condensing): 20% to 85%
Form Factor: Handheld
Color Family: Black
Product Color: Black
Product Material: Acrylonitrile Butadiene Styrene (ABS)
Durability: Dust Resistant
Height: 5.20" (132 mm)
Width: 4.45" (113 mm)
Depth: 2.20" (56 mm)
Weight (Approximate): 4.48 oz (127 g)
Ingress Protection (IP) Rating: IP42
Application/Usage: Industrial,Retail,Healthcare,Warehouse,Distribution,Transportation,Logistics
Country of Origin: Japan
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 2 Year
- Scan barcodes with a staggering speed of 300 scan/s
- LED aimer is a perfect choice for patient-facing applications
- Wireless connectivity gives you the adaptability to transmit barcode data to your smart devices
- Bluetooth technology - Allows compatibility with most of your smart devices
[custom-specifications]
| Specifications | |
| Manufacturer | Opticon Sensors Europe |
| Manufacturer Part Number | OPC3301I-00 |
| Manufacturer Website Address | http://www.opticon.com |
| Brand Name | Opticon |
| Product Model | OPC-3301i |
| Product Name | OPC-3301i CCD Barcode Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 1D |
| Barcode Symbology Supported | Barcode (1D):
Postal Code:
|
| Light Source | LED |
| Image Sensor Type | CCD,Linear |
| Scan Rate | 300 scan/s |
| Scan Mode | Trigger |
| Scanning Distance | 19.69" (500.13 mm) |
| Number of Keys | 1 |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 50° |
| Reading Angle (Roll) | 25° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | 5 ft (1.5 m) drop onto concrete surface |
| Minimum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Maximum Element Resolution (Code 39) | 40 mil (1.02 mm) |
| Features | Vibration,Ergonomic Design |
| Memory | |
| Standard Memory | 1 MB |
| Flash Memory | 1 MB |
| Network & Communication | |
| Bluetooth | Yes |
| Power Description | |
| Standby Current | 15 mA |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 1100 mAh |
| Maximum Battery Recharge Time | 3 Hour |
| Environmental Conditions | |
| Operating Temperature | 32°F (0°C) to 122°F (50°C) |
| Storage Temperature | -4°F (-20°C) to 140°F (60°C) |
| Humidity (Non-condensing) | 20% to 85% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Color Family | Black |
| Product Color | Black |
| Product Material | Acrylonitrile Butadiene Styrene (ABS) |
| Durability | Dust Resistant |
| Height | 5.20" (132 mm) |
| Width | 4.45" (113 mm) |
| Depth | 2.20" (56 mm) |
| Weight (Approximate) | 4.48 oz (127 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP42 |
| Application/Usage | Industrial,Retail,Healthcare,Warehouse,Distribution,Transportation,Logistics |
| Country of Origin | Japan |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
