Opticon OPH-1005 Laser Scanner - 1D96 MHz - 4 MB RAM - 64 MB Flash - 2" (50.80 mm) QVGA - TFT LCD - 23 Keys - Alphanumeric Keyboard - (OPH-1005-SK2)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- OPH-1005 Laser Scanner
- Standard Battery
- RS232/USB Charging Cradle
- Power Supply
- Wrist Strap
Connectivity Technology: Batch
Scanning Capability: 1D
Light Source: Laser
Power Supply Included: Yes
Features: Vibration Alert,Moisture Resistant,Lightweight
Processor Speed: 96 MHz
Standard Memory: 4 MB
Flash Memory: 64 MB
Memory Card Supported: microSD
Screen Size: 2" (50.80 mm)
Screen Mode: QVGA
Screen Resolution: 320 x 240
Display Screen Type: TFT LCD
Number of Keys: 23
Keyboard Type: Alphanumeric
USB: Yes
Operating System: Proprietary OS
Battery Capacity: 1100 mAh
Battery Chemistry: Lithium Ion (Li-Ion)
Battery Included: Yes
Maximum Battery Run Time: 40 Hour
Battery Voltage: 3.70 V
Operating Temperature: 14°F (-10°C) to 122°F (50°C)
Storage Temperature: -4°F (-20°C) to 140°F (60°C)
Humidity (Non-condensing): 20% to 85%
Product Color: Black
Form Factor: Phone-size
Rugged: Yes
Height: 5.35" (136 mm)
Width: 2.17" (55 mm)
Depth: 0.91" (23 mm)
Weight (With Battery): 4.94 oz (140 g)
Package Contents:
Application/Usage: Inventory Management,Asset Tracking,Industrial,Retail,Healthcare,Warehouse,Distribution
Ingress Protection (IP) Rating: IP54
Environmental Compliance: Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE)
Limited Warranty: 2 Year
- 2" (50.80 mm) QVGA display screen allows you to execute two applications at the same time
- Alphanumeric keypad allows prompt data input
- Improve work efficiency with laser scanning engine
- microSD card slot gives an extra storage option
- With batch connectivity, collect data immediately to your gadget and sync all the records to a computer afterward
- Phone-size form factor is comfortable to utilize in intensive or non-intensive scan environments
[custom-specifications]
| Specifications | |
| Manufacturer | Opticon Sensors Europe |
| Manufacturer Part Number | OPH-1005-SK2 |
| Manufacturer Website Address | http://www.opticon.com |
| Brand Name | Opticon |
| Product Model | OPH-1005 |
| Product Name | OPH-1005 Laser Scanner |
| Product Type | Handheld Terminal |
| Technical Information | |
| Connectivity Technology | Batch |
| Scanning Capability | 1D |
| Light Source | Laser |
| Power Supply Included | Yes |
| Features | Vibration Alert,Moisture Resistant,Lightweight |
| Processor & Chipset | |
| Processor Speed | 96 MHz |
| Memory | |
| Standard Memory | 4 MB |
| Flash Memory | 64 MB |
| Memory Card Supported | microSD |
| Display & Graphics | |
| Screen Size | 2" (50.80 mm) |
| Screen Mode | QVGA |
| Screen Resolution | 320 x 240 |
| Display Screen Type | TFT LCD |
| Keyboard/Keypad | |
| Number of Keys | 23 |
| Keyboard Type | Alphanumeric |
| Interfaces/Ports | |
| USB | Yes |
| Software | |
| Operating System | Proprietary OS |
| Battery Information | |
| Battery Capacity | 1100 mAh |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Included | Yes |
| Maximum Battery Run Time | 40 Hour |
| Battery Voltage | 3.70 V |
| Environmental Conditions | |
| Operating Temperature | 14°F (-10°C) to 122°F (50°C) |
| Storage Temperature | -4°F (-20°C) to 140°F (60°C) |
| Humidity (Non-condensing) | 20% to 85% |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Phone-size |
| Rugged | Yes |
| Height | 5.35" (136 mm) |
| Width | 2.17" (55 mm) |
| Depth | 0.91" (23 mm) |
| Weight (With Battery) | 4.94 oz (140 g) |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | Inventory Management,Asset Tracking,Industrial,Retail,Healthcare,Warehouse,Distribution |
| Ingress Protection (IP) Rating | IP54 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
[/custom-user-manual]
