Grandstream GWN7710R Outdoor Layer 2 Lite Managed PoE Switch - 6 Ports - 5 Gigabit RJ45 + 1 SFP - IP66 - 40°C to 60°C
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The GWN7710R delivers robust switching capabilities with enterprise-grade features in a compact outdoor form factor. The switch architecture includes five Gigabit Ethernet ports (four PoE output, one PoE input) and one SFP fiber port for long-distance uplink connections. PoE output reaches up to 60W on Port 1 and up to 30W on Ports 2-4, with PoE Watchdog functionality ensuring reliable power delivery to connected devices.
Network management features include DHCP Snooping for enhanced security, STP/RSTP protocols for network stability and redundancy, and built-in QoS for traffic prioritization. The switch supports multiple management interfaces including local web configuration, GWN Manager, and GDMS Networking for centralized administration.
Relevant factors for this section include IP66 dustproof and waterproof rating; Wide operating temperature range, SKU. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The GWN7710R stands out with its rugged outdoor design and comprehensive PoE capabilities, offering reliable performance in challenging environments where standard switches would fail.
Environmental Resilience
Built to operate in extreme conditions from -40°C to 60°C with full IP66 protection against dust and water ingress.
- Withstands rain, snow, and temperature extremes
- Suitable for outdoor installations without additional enclosures
Power Flexibility
Supports both standard IEEE 802.3at/af PoE and 24V/48V DC passive PoE, with dedicated PoE input port for simplified power deployment.
- 60W maximum on Port 1 for high-power devices
- 30W on Ports 2-4 for standard PoE devices
Deployment / Use Cases
The GWN7710R is specifically designed for outdoor networking scenarios where environmental durability and PoE capabilities are critical requirements.
Its rugged construction and wide temperature tolerance make it suitable for installations that experience seasonal temperature extremes or exposure to moisture.
Relevant factors for this section include IP66 dustproof and waterproof rating; Wide operating temperature range, SKU. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Outdoor Surveillance Systems
Power and connect multiple outdoor IP cameras, access control systems, or environmental sensors while withstanding harsh weather conditions.
- PoE ports eliminate separate power runs
- IP66 rating protects against rain and dust
Industrial Outdoor Networks
Deploy in manufacturing facilities, agricultural settings, or remote monitoring stations where temperature extremes and environmental exposure are concerns.
- Operates from -40°C to 60°C
- SFP uplink enables long-distance fiber connections
Highlights
- 6-port outdoor managed PoE switch with 5 Gigabit RJ45 and 1 SFP port
- IP66-rated waterproof and dustproof casing for harsh environments
- Wide operating temperature range from -40°C to 60°C
- 4 PoE output ports with up to 60W on Port 1 and 30W on Ports 2-4
- Supports IEEE 802.3at/af and 24V/48V DC passive PoE standards
- PoE Watchdog function for reliable power delivery monitoring
- SFP fiber port for long-distance uplink connections
- DHCP Snooping enhances enterprise network security
- STP/RSTP protocols ensure network stability and redundancy
- Multiple management options: local web, GWN Manager, and GDMS Networking
Specifications
| General | |
|---|---|
| IP66 dustproof and waterproof rating; Wide operating temperature range | 40°C and 60°C |
| Brand | Grandstream |
| SKU | GWN7710R |
| Manufacturer Part Number | GWN7710R |
User Manual
FAQ
What makes the GWN7710R suitable for outdoor installations?
The GWN7710R features an IP66-rated waterproof and dustproof casing that protects against rain, snow, and dust ingress. It operates across a wide temperature range from -40°C to 60°C, making it resilient in extreme environmental conditions where standard indoor switches would fail. This rugged design eliminates the need for additional protective enclosures in outdoor deployments.
How many PoE ports does this switch have and what power can they deliver?
The GWN7710R has four PoE output ports and one PoE input port. Port 1 can deliver up to 60W of power, while Ports 2-4 each support up to 30W. This configuration allows the switch to power high-demand devices like PTZ cameras on Port 1 while simultaneously supporting standard PoE devices on the remaining ports.
What PoE standards does the GWN7710R support?
This switch supports both IEEE 802.3at/af standards for compliant PoE devices and 24V/48V DC passive PoE for legacy or specialized equipment. This dual-standard approach provides flexibility for mixed-device environments and ensures compatibility with a wide range of powered devices in outdoor installations.
What management options are available for the GWN7710R?
The GWN7710R offers multiple management interfaces including local web configuration for direct access, GWN Manager for local network administration, and GDMS Networking for cloud-based centralized management. These options provide flexibility for different deployment scenarios, from standalone installations to centrally managed enterprise networks.
What networking features does this managed switch include?
The GWN7710R includes enterprise-grade networking features such as DHCP Snooping for enhanced security against rogue DHCP servers, STP/RSTP protocols for network stability and redundancy, and built-in QoS for traffic prioritization. These features ensure reliable network operation in demanding outdoor environments where connectivity is critical.
How does the PoE Watchdog function work?
The PoE Watchdog function monitors power delivery to connected PoE devices and can automatically reboot ports if connected devices become unresponsive. This feature helps maintain uptime in remote outdoor installations by automatically recovering from power-related issues without requiring manual intervention, which is particularly valuable in hard-to-access locations.
