Lenovo 30HH0040US ThinkStation P8 Workstation - AMD Threadripper PRO 7975WX 32-Core 4. 0GHz - 32GB DDR5 - 1TB NVMe SSD - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the heart of the ThinkStation P8 is the AMD Ryzen Threadripper PRO 7975WX processor, operating at 4.0GHz with 128MB of L3 cache. This 32-core CPU leverages the Socket sTR5 platform and AMD WRX90 chipset to provide extensive PCIe lanes and memory bandwidth. The system supports up to 1TB of DDR5 ECC registered memory across eight slots, with the installed 32GB configuration running at 4800MHz.
Storage is handled by a 1TB NVMe PCIe 4.0 SSD, offering rapid data access and application loading. The storage subsystem supports hardware RAID 0, 1, 5, and 10 configurations via NVMe and SATA controllers. Graphics processing is managed by a dedicated controller with 16GB of dedicated memory, suitable for CAD, 3D modeling, and visualization workloads.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The ThinkStation P8 combines enterprise-grade reliability with workstation-class performance. Its Threadripper PRO processor includes AMD's PRO technologies for enhanced security and manageability, while the ECC memory ensures data integrity during critical computations.
Professional-Grade Connectivity
The workstation features comprehensive I/O including 10 USB ports (with USB-C 3.2 Gen 2 and 20Gbps options), dual Gigabit/10GbE Ethernet, Wi-Fi 6E, and Bluetooth for versatile peripheral and network connectivity.
- 2x USB-C 3.2 Gen 2 ports
- 1x USB-C 20Gbps port
- 5x USB 3.2 Gen 2 ports
- 2x USB 2.0 ports
Enterprise Management & Security
Built with business-ready features including hardware RAID support, ECC memory, and comprehensive environmental certifications for deployment in regulated environments.
- EPEAT Gold certified
- ENERGY STAR 8.0 compliant
- TCO Certified 9.0
- RoHS compliant
Deployment / Use Cases
The ThinkStation P8 is engineered for professional environments where computational power and system reliability are paramount. Its balanced configuration of high-core-count CPU, substantial memory, and fast storage makes it ideal for engineering simulations, financial modeling, scientific research, and media production workflows.
Architectural and engineering firms will appreciate the system's ability to handle complex CAD and BIM applications, while research institutions can leverage its parallel processing capabilities for data analysis and computational research. Creative studios can utilize the workstation for 3D rendering, video editing, and visual effects work that demands both CPU and GPU resources.
Engineering & Design
Optimized for CAD, CAE, and product design applications requiring precise calculations and complex model manipulation.
Scientific Computing
Suitable for research applications in computational biology, physics simulations, and data science workloads that benefit from high core counts and ECC memory.
Localization and Operating System
This workstation ships with Windows 11 Pro 64-bit in English, providing a familiar and secure operating environment for business and professional use. The US English keyboard localization ensures compatibility with standard input requirements in North American markets.
Windows 11 Pro includes advanced security features, remote management capabilities, and productivity enhancements that complement the workstation's hardware capabilities for enterprise deployment.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
The ThinkStation P8 features a substantial tower form factor measuring 17.1" high, 6.89" wide, and 20" deep (434.4 x 175 x 508mm), with a weight of approximately 50.04 pounds (22.7kg). Its black chassis provides a professional appearance suitable for office environments, while the design accommodates efficient cooling for sustained high-performance operation.
The workstation's dimensions allow for ample internal expansion space while maintaining a footprint appropriate for desk-side placement in professional settings.
- Width
- 6.89" (175 mm)
- Depth
- 20" (508 mm)
- Height
- 17.10" (434.40 mm)
- Weight
- 50.04 lb (22700 g)
What's in the Box
The workstation ships complete with all essential components for immediate deployment in professional environments.
Highlights
- AMD Ryzen Threadripper PRO 7975WX processor with 32 cores and 4.0GHz clock speed
- 32GB DDR5 ECC registered memory running at 4800MHz with 1TB maximum support
- 1TB NVMe PCIe 4.0 SSD for fast storage and application loading
- Dedicated graphics controller with 16GB dedicated memory
- Windows 11 Pro 64-bit English operating system
- Comprehensive connectivity with 10 USB ports, dual Ethernet, Wi-Fi 6E, and Bluetooth
- Hardware RAID 0/1/5/10 support for data protection and performance
- Professional-grade certifications including EPEAT Gold, ENERGY STAR 8.0, and TCO Certified 9.0
- 3-year limited warranty with 3-year on-site service
- Substantial tower form factor with robust cooling for sustained performance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 30HH0040US |
| Brand Name | Lenovo |
| Product Line | ThinkStation |
| Product Series | P8 |
| Product Model | 30HH0040US |
| Product Name | ThinkStation P8 30HH0040US Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Ryzen Threadripper PRO |
| Processor Model | 7975WX |
| Processor Core | Dotriaconta-core (32 Core) |
| Processor Threads | 64 |
| Processor Speed | 4 GHz |
| Processor Socket | Socket sTR5 |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | WRX90 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 16 GB |
| Error Checking | ECC |
| Signal Processing | Registered |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express 4.0 |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Display & Graphics | |
| Number of Graphic Controllers | 1 |
| Graphics Memory Capacity | 16 GB |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Wi-Fi Generation | Wi-Fi 6E |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English (US) |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| USB Type-C | Yes |
| USB Type-C Detail | 2x USB-C 3.2 Gen 2; 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Operating System Architecture | 64-bit |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 1.40 kW |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Height | 17.10" (434.40 mm) |
| Width | 6.89" (175 mm) |
| Depth | 20" (508 mm) |
| Weight (Approximate) | 50.04 lb (22700 g) |
| Miscellaneous | |
| Package Contents | ThinkStation P8 30HH0040US Keyboard Mouse |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),GREENGUARD,TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3YR Premier NBD 3 Year On-site |
User Manual
FAQ
What processor does the ThinkStation P8 30HH0040US workstation use?
This workstation features the AMD Ryzen Threadripper PRO 7975WX processor, which has 32 physical cores, 64 threads, and operates at a base frequency of 4.0GHz. The processor includes 128MB of L3 cache and supports AMD's PRO technologies for enhanced security and manageability in professional environments.
How much memory is installed and what type does it use?
The system comes with 32GB of DDR5 ECC registered memory installed as two 16GB modules running at 4800MHz. The workstation has eight memory slots total and supports up to 1TB of DDR5 memory, with ECC functionality ensuring data integrity for critical computational workloads.
What storage configuration does this workstation include?
Storage is provided by a 1TB NVMe PCIe 4.0 solid-state drive, which offers high-speed data access for applications and project files. The storage subsystem supports hardware RAID configurations including RAID 0, 1, 5, and 10 through both NVMe and SATA controllers.
What operating system is pre-installed on this workstation?
The ThinkStation P8 ships with Windows 11 Pro 64-bit in English pre-installed. This professional edition includes advanced security features, remote management capabilities, and productivity tools suitable for business and technical environments.
What connectivity options are available on this workstation?
Connectivity includes 10 total USB ports (with USB-C 3.2 Gen 2 and 20Gbps options), dual Gigabit/10GbE Ethernet ports, Wi-Fi 6E wireless networking, and Bluetooth. The system also features dedicated graphics output and comprehensive expansion capabilities through its PCIe slots.
What warranty and support come with this workstation?
Lenovo provides a 3-year limited warranty with 3-year premier next-business-day on-site service. This support package includes hardware repair or replacement by a technician at your location, ensuring minimal downtime for professional users who depend on this workstation for critical tasks.
What processor is listed for this desktop or workstation?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 4 GHz processor for everyday performance and multitasking.
