TP-LINK AP7650 Omada Pro AX3000 Wall Plate WiFi 6 Access Point - Dual Band 2.91 Gbps - 4x Gigabit Ports - PoE PD - Indoor
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The AP7650 operates on the IEEE 802.11 a/b/g/n/ac/ax wireless standard, commonly known as Wi-Fi 6, which improves network efficiency, reduces latency, and increases capacity in congested environments. It utilizes dual-band radio technology, transmitting on both the 2.40 GHz and 5 GHz frequency bands simultaneously, with a maximum aggregate wireless throughput of 2.91 Gbit/s. Advanced features like beamforming technology focus wireless signals toward connected clients for stronger, more reliable connections.
On the wired side, the access point is equipped with four Gigabit Ethernet ports that support 10/100/1000 Mbps speeds. One of these ports functions as a PoE PD (Powered Device) port, allowing the unit to receive both data and power over a single Ethernet cable from a compatible PoE switch or injector. This eliminates the need for a separate power outlet near the installation point. The internal dual-antenna design is optimized for wall plate mounting, providing omnidirectional coverage suitable for rooms, hallways, or open office areas.
Key Product Advantages
The Omada Pro AP7650 combines high-performance Wi-Fi 6 technology with a discreet, installation-friendly form factor. Its wall plate design allows for seamless integration into existing infrastructure, reducing visual clutter and maximizing space utilization. The inclusion of four Gigabit Ethernet ports offers exceptional flexibility for connecting additional wired devices, such as IP phones, printers, or desktop computers, directly at the access point location.
Wi-Fi 6 Efficiency
Supports OFDMA and MU-MIMO technologies to handle multiple client devices simultaneously, reducing latency and improving overall network performance in high-density environments.
- Better performance in congested areas
- Improved battery life for connected devices
- Higher data rates for compatible clients
Simplified Installation
The PoE PD capability allows for single-cable deployment, while the wall plate/junction box mounting options provide versatile placement choices without requiring additional brackets or hardware.
- Power over Ethernet support
- Clean, low-profile installation
- No separate power outlet needed
Enterprise-Grade Security
Features comprehensive encryption standards including WPA3, WPA2, and WPA-ENT for robust wireless security, along with support for RADIUS authentication and multiple management protocols.
- WPA3 encryption support
- RADIUS authentication compatible
- SSH, HTTPS, SNMP management
Deployment / Use Cases
The AP7650 is ideally suited for environments where discreet, high-performance wireless access is required without the bulk of traditional ceiling-mounted access points. Its wall plate form factor makes it perfect for office spaces, hotel rooms, classrooms, healthcare facilities, and retail locations where aesthetics and space constraints are important considerations. The four Ethernet ports enable the creation of local network hubs in rooms where multiple wired connections are needed alongside wireless access.
This access point excels in retrofit installations where running new cabling is challenging. It can replace existing wall plates or be installed in junction boxes, leveraging existing infrastructure while upgrading to Wi-Fi 6 capabilities. The PoE support simplifies deployment in locations without convenient power outlets, such as above drop ceilings or in wall cavities. For larger deployments, multiple AP7650 units can be managed centrally through the Omada SDN platform, providing consistent configuration and monitoring across the network.
Office & Commercial Spaces
Provides discreet wireless coverage in individual offices, conference rooms, and common areas while maintaining a professional appearance. The four Ethernet ports allow for direct connection of office peripherals.
Hospitality & Education
Ideal for hotel rooms, dormitories, and classrooms where wall-mounted installation is preferred. The low-profile design minimizes visual impact while delivering reliable connectivity for guests, students, and staff.
Physical Profile
The AP7650 features a compact design measuring 5.63 inches in height, 3.39 inches in width, and 1.68 inches in depth (143 x 86 x 42.6 mm), with an approximate weight of 1.98 pounds (900 g). Its wall plate form factor allows for direct mounting in standard electrical boxes or wall plates, creating a flush installation that blends with room decor. The internal antenna design eliminates external protrusions, maintaining a clean appearance while providing effective wireless coverage. The unit is designed for indoor use only and meets RoHS environmental compliance standards.
- Width
- 3.39" (86 mm)
- Depth
- 1.68" (42.60 mm)
- Height
- 5.63" (143 mm)
- Weight
- 1.98 lb (900 g)
What's in the Box
The package includes all necessary components for installation and operation of the access point.
Highlights
- Wi-Fi 6 (802.11ax) technology for improved network efficiency and capacity
- Dual-band operation on 2.4 GHz and 5 GHz frequencies
- Maximum wireless speed of 2.91 Gbit/s for high-performance connectivity
- Four Gigabit Ethernet ports for flexible wired connections
- Power over Ethernet (PoE) PD support for simplified installation
- Wall plate and junction box mounting options for discreet placement
- Internal dual-antenna design optimized for wall-mounted applications
- Advanced security with WPA3, WPA2, and enterprise encryption standards
- Centralized management capability through Omada SDN platform
- RoHS compliant and environmentally friendly construction
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | AP7650 |
| Brand Name | Omada Pro |
| Product Series | Pro |
| Product Model | AP7650 |
| Product Name | Omada Pro AX3000 Wall Plate WiFi 6 Access Point |
| Packaged Quantity | 1 |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Network Band | Dual Band |
| Frequency Band | 2.40 GHz,5 GHz |
| Total Number of Antennas | 2 |
| Number of Internal Antennas | 2 |
| Indoor/Outdoor | Indoor |
| Wireless Transmission Speed | 2.91 Gbit/s |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WPA3,WPA-ENT,WPA-PSK,WPA2-ENT,WPA2-PSK,WPA3-ENT,WPA3-Personal |
| Interfaces/Ports | |
| Ethernet Technology | Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 4 |
| PoE PD Port | Yes |
| Network & Communication | |
| Wi-Fi Generation | Wi-Fi 6 |
| Communication Protocols | SSH,HTTP,HTTPS,SNMPv1/v2c/v3,RADIUS |
| Physical Characteristics | |
| Form Factor | Wall Plate,Junction Box Mount |
| Antenna Form Factor | Internal |
| Height | 5.63" (143 mm) |
| Width | 3.39" (86 mm) |
| Depth | 1.68" (42.60 mm) |
| Weight (Approximate) | 1.98 lb (900 g) |
| Miscellaneous | |
| Package Contents | Omada Pro AX3000 Wall Plate WiFi 6 Access Point Installation Guide Wall Plate Mounting Kits |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
What Wi-Fi standard does the AP7650 support?
The AP7650 supports the IEEE 802.11 a/b/g/n/ac/ax wireless standard, which is commonly referred to as Wi-Fi 6. This latest generation of Wi-Fi technology offers improved network efficiency, higher data rates, better performance in congested environments, and reduced latency compared to previous Wi-Fi standards like Wi-Fi 5 (802.11ac).
Does this access point support Power over Ethernet?
Yes, the AP7650 includes a PoE PD (Powered Device) port that allows it to receive both data and electrical power over a single Ethernet cable. This enables installation in locations without convenient power outlets, as the access point can be powered by a compatible PoE switch or injector. The PoE support simplifies deployment and reduces installation costs.
How many Ethernet ports does the AP7650 have?
The AP7650 is equipped with four Gigabit Ethernet ports (10/100/1000 Mbps). These RJ-45 ports provide flexible wired connectivity options for connecting devices such as computers, printers, IP phones, or other network equipment directly to the access point. One of these ports serves as the PoE PD port for receiving power.
What mounting options are available for this access point?
The AP7650 is designed for wall plate or junction box mounting, making it ideal for discreet installations in office walls, electrical boxes, or similar locations. This form factor allows for a clean, low-profile appearance that blends with room decor. The package includes wall plate mounting kits to facilitate installation in standard electrical boxes.
Is this access point suitable for outdoor use?
No, the AP7650 is designed for indoor use only. It does not have the weatherproofing or temperature ratings required for outdoor deployment. The access point should be installed in controlled indoor environments such as offices, classrooms, hotels, or commercial buildings where temperature and humidity remain within normal operating ranges.
What management capabilities does the AP7650 offer?
The AP7650 supports multiple management protocols including SSH, HTTP, HTTPS, SNMPv1/v2c/v3, and RADIUS authentication. When integrated with an Omada Software-Defined Networking (SDN) controller, it enables centralized management of multiple access points, providing streamlined configuration, monitoring, and maintenance across the wireless network. This is particularly valuable for larger deployments requiring consistent policy enforcement.
