Securitron PDB-4C1 Power Distribution Module - 4 Output 1 Amp Each AC/DC - Compact 3. 75" x 2. 22" x 1"
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The PDB-4C1 features four independent PTC Polyswitch outputs, each capable of handling 1 Amp of current. This design provides overcurrent protection, automatically resetting after a fault condition is cleared, which enhances system reliability and safety. The module accepts both AC and DC input, allowing it to adapt to different power supplies commonly used in security applications.
With dimensions of 3.75" x 2.22" x 1", the module is engineered for space-efficient installations. Its compact size does not compromise durability, as it is built to withstand the rigors of continuous operation in commercial and industrial environments.
This section brings together practical product details such as Height, Width, Depth, Additional Information, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The PDB-4C1 simplifies power distribution by consolidating multiple outputs into a single, manageable unit. Its use of PTC Polyswitch technology ensures each output is protected against overcurrent events, reducing the risk of damage to connected devices and minimizing maintenance needs.
Flexible Power Compatibility
Supports both AC and DC power sources, making it versatile for integration with various security system components without requiring separate modules for different power types.
Space-Optimized Design
With a minimal footprint, this module fits easily into tight spaces within control panels or enclosures, maximizing available room for other equipment.
Reliable Protection
PTC Polyswitch outputs provide automatic reset functionality after faults, ensuring continuous operation and reducing the need for manual intervention.
Deployment / Use Cases
The Securitron PDB-4C1 is primarily deployed in access control systems, where it distributes power to devices such as electric locks, card readers, and keypads. Its ability to handle both AC and DC power makes it suitable for a wide range of security installations, from small office setups to large-scale industrial facilities.
Common applications include powering multiple door controllers in a networked access system, providing dedicated outputs for alarm sensors, or managing power for surveillance camera peripherals. The module's compact size allows it to be mounted inside control cabinets or alongside other networking equipment, streamlining overall system design.
Access Control Panels
Ideal for distributing power to multiple access control devices within a single panel, ensuring consistent and protected power supply.
Security System Enclosures
Fits seamlessly into enclosures housing security hardware, providing organized power management for sensors, interfaces, and communication modules.
Physical Profile
Measuring 3.75" in height, 2.22" in width, and 1" in depth, the PDB-4C1 is designed for minimal spatial impact. Its compact dimensions facilitate installation in confined areas, such as within standard electrical boxes or mounted on DIN rails in control panels. The module's sturdy construction ensures it can endure vibrations and environmental stresses typical in security deployments.
- Width
- 2.22" (56.39 mm)
- Depth
- 1" (25.40 mm)
- Height
- 3.75" (95.25 mm)
Highlights
- 4 PTC Polyswitch outputs for reliable power distribution
- 1 Amp rating per output, suitable for low-power security devices
- Compatible with both AC and DC power sources
- Compact size: 3.75" x 2.22" x 1" for space-efficient installations
- Made in the United States, ensuring quality manufacturing standards
- Ideal for access control systems and security panel integrations
- Overcurrent protection with automatic reset functionality
- Easy to mount in control cabinets or enclosures
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASSA ABLOY |
| Manufacturer Part Number | PDB-4C1 |
| Brand Name | Securitron |
| Product Name | Power Distribution Module |
| Product Type | Power Distribution Module |
| Physical Characteristics | |
| Height | 3.75" (95.25 mm) |
| Width | 2.22" (56.39 mm) |
| Depth | 1" (25.40 mm) |
| Miscellaneous | |
| Additional Information | 4 PTC Polyswitch Output 1 Amp Each AC or DC Output |
| Country of Origin | United States |
User Manual
FAQ
What is the output configuration of the Securitron PDB-4C1?
The PDB-4C1 features four independent PTC Polyswitch outputs, each capable of delivering 1 Amp of current. This configuration allows it to power multiple devices simultaneously while providing overcurrent protection for each output.
Can this module handle both AC and DC power?
Yes, the PDB-4C1 is designed to accept both AC and DC input power, making it versatile for various security system applications. This compatibility allows it to integrate seamlessly with different power supplies without requiring additional converters.
What are the physical dimensions of the PDB-4C1?
The module measures 3.75 inches in height, 2.22 inches in width, and 1 inch in depth. Its compact size makes it suitable for installation in tight spaces within control panels or enclosures.
How does the PTC Polyswitch technology benefit this power distribution module?
PTC Polyswitch technology provides overcurrent protection by automatically limiting current during fault conditions and resetting once the fault is cleared. This enhances reliability and reduces maintenance needs by preventing damage to connected devices.
Where is the Securitron PDB-4C1 manufactured?
This power distribution module is manufactured in the United States, ensuring adherence to quality standards and supporting domestic production for reliability in security applications.
What are typical use cases for the PDB-4C1 in security systems?
Common deployments include powering electric locks, card readers, keypads, and alarm sensors in access control systems. Its compact design and multiple outputs make it ideal for organizing power distribution within security panels or enclosures.
| Qty | Price | Available |
|---|
