Sharp XP-V801U-B V801U Professional 3LCD Laser Projector - 8300 lm - WUXGA 1920 x 1200 - 3D - Standard Throw - Ceiling Mountable - Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The Sharp XP-V801U-B V801U Professional 3LCD Laser Projector is a high-performance installation-grade projector engineered for demanding visual environments. It combines a laser light source with advanced 3LCD, 3-chip technology to deliver consistent, vibrant color reproduction and reliable operation over extended periods. This model is built to serve education, corporate, simulator, and meeting room applications where image quality, brightness, and durability are critical.
With a native WUXGA resolution of 1920 x 1200 and a 16:10 aspect ratio, the projector provides crisp, detailed imagery suitable for presentations, training simulations, and multimedia content. Its 8300 lm brightness ensures clear visibility even in well-lit rooms, while the 3,000,000:1 contrast ratio adds depth and definition to visuals. The laser light source offers a 20,000-hour lifespan in normal mode, reducing maintenance needs and total cost of ownership compared to traditional lamp-based projectors.
Technical Overview
This projector utilizes a single laser light source, which provides instant on/off capability, consistent brightness over time, and eliminates the color decay associated with conventional lamps. The 3LCD optical engine ensures full-color projection in every frame, avoiding color breakup and delivering smooth motion for video and 3D content. The standard throw lens allows flexible placement in medium to large rooms, with a projection distance range from 27.56 inches to over 166 feet, accommodating image sizes from 40 inches to 41.67 feet diagonally.
Connectivity is comprehensive, featuring HDMI for high-definition video sources, USB for direct media playback or PC-free projection, and a network (RJ-45) port for remote management and control via wired LAN. The projector supports HDTV signals and outputs a scan format up to 2160p, ensuring compatibility with modern 4K content sources. Power consumption is rated at 467W during operation and drops to 500 mW in standby, aligning with energy-efficient operation standards.
Key Product Advantages
The Sharp V801U stands out with its laser illumination system, which provides long-term reliability and consistent performance without the frequent lamp replacements required by traditional projectors. This makes it an ideal choice for installations where accessibility is limited or where continuous operation is necessary, such as in simulation labs or auditoriums.
Superior Image Quality
The 3LCD technology ensures accurate color reproduction and high light output efficiency, resulting in bright, true-to-life images with excellent color uniformity across the entire screen.
- 8300 lm brightness for clear visibility in lit environments
- 3,000,000:1 contrast ratio for deep blacks and vivid highlights
- WUXGA 1920x1200 resolution for detailed graphics and text
Flexible Installation
Designed for ceiling mounting, the projector offers a standard throw ratio that accommodates a wide range of room sizes and screen dimensions. Its compact black chassis blends discreetly into professional settings.
- Projection distance from 27.56" to 166.99 ft
- Image size from 40" to 41.67 ft diagonal
- Front or ceiling projection modes
Deployment / Use Cases
This projector is tailored for environments that demand high brightness, reliable operation, and minimal maintenance. Its laser light source and robust construction make it suitable for extended use in educational institutions, corporate boardrooms, simulation facilities, and large meeting spaces where image clarity and color accuracy are paramount.
In education, it can serve lecture halls and classrooms, displaying detailed diagrams, videos, and interactive content with consistent brightness throughout the day. For corporate applications, it enhances presentations and video conferences with sharp, vibrant visuals. Simulation and training centers benefit from its 3D capability and high contrast ratio, which provide immersive experiences for technical or medical training. The network port enables IT departments to monitor and manage multiple projectors remotely, simplifying maintenance and troubleshooting across a facility.
Physical Profile
The projector features a sleek black housing designed for ceiling mounting, with dimensions of 19.65" (499 mm) wide, 16.02" (407 mm) deep, and 6.46" (164 mm) high. Weighing approximately 24.69 lb (11200 g), it is sturdy yet manageable for installation. The form factor is optimized for discreet placement in professional environments, and the black finish helps it blend into ceiling mounts or AV cabinets without drawing attention.
- Width
- 19.65" (499 mm)
- Depth
- 16.02" (407 mm)
- Height
- 6.46" (164 mm)
- Weight
- 24.69 lb (11200 g)
Highlights
- Laser light source with 20,000-hour lifespan for reduced maintenance
- 8300 lm brightness ensures clear visibility in well-lit rooms
- WUXGA 1920x1200 native resolution with 16:10 aspect ratio
- 3LCD, 3-chip technology for accurate, vibrant color reproduction
- 3D capable for immersive content from compatible sources
- Standard throw lens with flexible projection distance and image size
- HDMI, USB, and network (RJ-45) ports for versatile connectivity
- Ceiling mountable design with compact black chassis
- Supports HDTV and 2160p output scan format
- TÜV Rheinland Green Product and RoHS environmental certifications
Specifications
| Specifications | |
|---|---|
| Manufacturer | Sharp Electronics |
| Manufacturer Part Number | XP-V801U-B |
| Brand Name | Sharp |
| Product Line | Professional |
| Product Series | V |
| Product Model | V801U |
| Product Name | V801U Professional Value LCD Laser Installation Projector |
| Product Type | 3LCD Projector |
| Technical Information | |
| Projection Method | Ceiling,Front |
| 3D Type | 3D |
| Display & Graphics | |
| Native Resolution | 1920 x 1200 |
| Graphic Mode | WUXGA |
| Native Aspect Ratio | 16:10 |
| Projection Lens | |
| Throw Type | Standard Throw |
| Minimum Diagonal Image Size | 40" (1016 mm) |
| Maximum Diagonal Image Size | 41.67 ft (12700 mm) |
| Minimum Projection Distance | 27.56" (700 mm) |
| Maximum Projection Distance | 166.99 ft (50900 mm) |
| Lamp | |
| Number of Lamps | 1 |
| Lamp Type | Laser |
| Normal Mode Lamp Life | 20000 Hour |
| Image | |
| Standard Mode Brightness | 8300 lm |
| Contrast Ratio | 3,000,000:1 |
| Video | |
| Video Signal Standard | HDTV |
| Output Scan Format | 2160p |
| Interfaces/Ports | |
| HDMI | Yes |
| USB | Yes |
| Network (RJ-45) | Yes |
| Power Description | |
| Operating Power Consumption | 467 W |
| Standby Power Consumption | 500 mW |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Ceiling Mountable |
| Height | 6.46" (164 mm) |
| Width | 19.65" (499 mm) |
| Depth | 16.02" (407 mm) |
| Weight (Approximate) | 24.69 lb (11200 g) |
| Miscellaneous | |
| Application/Usage | Education,Corporate,Simulator,Meeting |
| Environmental Certification | TÜV Rheinland Green Product |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
What is the brightness of this projector and is it suitable for lit rooms?
The Sharp XP-V801U-B delivers 8300 lumens in standard mode, making it highly suitable for use in well-lit environments such as classrooms, conference rooms, or simulation labs. This brightness level ensures that projected images remain clear and vivid even with ambient light, reducing the need for complete darkness during presentations or training sessions.
How does the laser light source compare to traditional lamp projectors?
The laser light source offers a significantly longer lifespan of 20,000 hours in normal mode, compared to typical lamp-based projectors that may require replacement every 1,000 to 5,000 hours. Lasers provide consistent brightness and color output over time, instant on/off operation, and eliminate the risk of lamp failure during critical use, reducing maintenance costs and downtime.
What resolution and aspect ratio does this projector support?
This projector features a native WUXGA resolution of 1920 x 1200 with a 16:10 aspect ratio. This resolution provides detailed imagery for presentations, graphics, and video, and the 16:10 aspect ratio is ideal for displaying modern computer content or widescreen materials without black bars, offering more vertical screen space compared to standard 16:9 formats.
Can this projector display 3D content and what is required?
Yes, the Sharp V801U is 3D capable and can project 3D content from compatible 3D display screens or sources. To view 3D content, users typically need 3D glasses compatible with the projector's 3D system and a 3D source such as a Blu-ray player, gaming console, or computer with 3D output. The projector's high brightness and contrast ratio enhance the 3D viewing experience.
What are the throw distance and image size capabilities?
This standard throw projector offers a projection distance range from 27.56 inches (700 mm) to 166.99 feet (50900 mm), allowing flexible placement in various room sizes. It can produce image sizes from 40 inches (1016 mm) to 41.67 feet (12700 mm) diagonally, making it adaptable for small meeting rooms up to large auditoriums or simulation environments.
What connectivity options are available on this projector?
The projector includes HDMI for high-definition video input from devices like laptops, Blu-ray players, or media players; USB for direct media playback or projecting images from USB drives; and a network (RJ-45) port for wired LAN connectivity. The network port enables remote management, monitoring, and control via network protocols, useful for IT administration in multi-projector installations.
