SIIG HDMI 2.0 Over IP Extender And Matrix Kit With IR Remote Support Device Output Input Range Ft Mm X CE-H25A11-S1
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- 1 x Transmitter
- 1 x Receiver
- 2 x Power Adapter
- IR Blaster Cable & IR Receiver Cable
- Mounting Ear (4pcs) and Screw (8pcs)
- Remote Control
- Insert Card
- User Manual
Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 393.70 ft (120000 mm)
Graphics Modes: 4K
Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
Number of Network (RJ-45) Ports: 2
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1
Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 7
Product Color: Black
Transmitter Height: 1.18" (29.97 mm)
Transmitter Width: 4.33" (109.98 mm)
Transmitter Depth: 5.28" (134.11 mm)
Receiver Height: 1.18" (29.97 mm)
Receiver Width: 4.33" (109.98 mm)
Receiver Depth: 5.28" (134.11 mm)
Transmitter Weight (Approximate): 326.6 g
Receiver Weight (Approximate): 326.6 g
Package Contents:
Country of Origin: China
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 2 Year
[custom-specifications]
| Specifications | |
| Manufacturer | SIIG, Inc |
| Manufacturer Part Number | CE-H25A11-S1 |
| Manufacturer Website Address | http://www.siig.com |
| Brand Name | SIIG |
| Product Name | HDMI 2.0 4K60Hz Over IP Extender / Matrix with IR - Kit |
| Product Type | Video Extender Transmitter/Receiver |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Input Devices Supported | 1 |
| Number of Output Devices Supported | 1 |
| Maximum Operating Distance | 393.70 ft (120000 mm) |
| Video | |
| Graphics Modes | 4K |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| HDMI In | Yes |
| HDMI Out | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Twisted Pair Cable Standard | Category 7 |
| Physical Characteristics | |
| Product Color | Black |
| Transmitter Height | 1.18" (29.97 mm) |
| Transmitter Width | 4.33" (109.98 mm) |
| Transmitter Depth | 5.28" (134.11 mm) |
| Receiver Height | 1.18" (29.97 mm) |
| Receiver Width | 4.33" (109.98 mm) |
| Receiver Depth | 5.28" (134.11 mm) |
| Transmitter Weight (Approximate) | 326.6 g |
| Receiver Weight (Approximate) | 326.6 g |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
[/custom-user-manual]
