Socket Mobile SocketScan S720 - 1D/2D Linear Barcode Plus QR Code Reader - Wireless Connectivity - 14.96" (380 mm) Scan Distance - 1D, (CX4064-3127)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Codabar
- Code 39
- Code 93
- Code 128
- EAN-13
- EAN-8
- Interleaved 2 of 5
- ISBT 128
- UPC A
- UPC E1
- Chinese 2 of 5
- Codabar
- Code 11
- Code 16KCode 39
- Code 93
- Code 128
- Discrete 2 of 5
- EAN-13
- EAN-8
- GS1 Databar
- Industrial 2 of 5
- Interleaved 2 of 5
- Matrix 2 of 5
- MSI Plessey
- UPC A
- UPC E1
- Standard 2 of 5
- UK Plessey
- Data Matrix
- Micro QR Code
- PDF417
- QR Code
- Aztec
- Data Matrix
- Han Xin
- Micro PDF417
- Micro QR Code
- PDF417
- QR Code
Connectivity Technology: Wireless
Scanning Capability: 1D,2D
Barcode Symbology Supported: 1D:
Image Sensor Type: Imager
Scan Pattern: Linear
Scanning Distance: 14.96" (380 mm)
Field of View (Horizontal): 45°
Field of View (Vertical): 34°
Maximum Ambient Light: 100000 lux
Drop Specification: Multiple drops to vinyl covered concrete at about 3 ft or 1 m
Minimum Print Contrast: 25%
Maximum Element Resolution (Code 39): 5 mil (0.13 mm)
Maximum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Bluetooth: Yes
Ingress Protection (IP) Rating: IP40
Application/Usage: Retail,Hospitality,Logistics,Healthcare,Inventory,Transportation,Warehouse,Field Sales/Service
Platform Supported: iOS
- Wireless connectivity gives you the adaptability to transmit barcode data to your smart devices
- Bluetooth technology - Allows compatibility with most of your smart devices
[custom-specifications]
| Specifications | |
| Manufacturer | Socket Mobile, Inc |
| Manufacturer Part Number | CX4064-3127 |
| Manufacturer Website Address | http://www.socketmobile.com |
| Brand Name | Socket Mobile |
| Product Line | DuraSled |
| Product Model | DS820 |
| Product Name | SocketScan S720 - 1D/2D Linear Barcode Plus QR Code Reader |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D:
|
| Image Sensor Type | Imager |
| Scan Pattern | Linear |
| Scanning Distance | 14.96" (380 mm) |
| Field of View (Horizontal) | 45° |
| Field of View (Vertical) | 34° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | Multiple drops to vinyl covered concrete at about 3 ft or 1 m |
| Minimum Print Contrast | 25% |
| Maximum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Maximum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Network & Communication | |
| Bluetooth | Yes |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP40 |
| Application/Usage | Retail,Hospitality,Logistics,Healthcare,Inventory,Transportation,Warehouse,Field Sales/Service |
| Platform Supported | iOS |
