SonicWall TZ80 Network Security/Firewall Appliance - Intrusion Prevention - 4 Port - Gigabit Ethernet - 750 Mbit/s Firewall Throughput (03-SSC-2749)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Functionality: Intrusion Prevention
Firewall Protection Supported: Intrusion Prevention,Malware Protection,Application Control,Content Filtering,Anti-spyware,URL Filtering,Threat Protection,Secure IPsec VPN Connectivity,Deep Inspection Firewall,Gateway Antivirus,SSL Inspection,TLS Inspection,Dead Peer Detection,Deep Packet Inspection (DPI)
Firewall Throughput: 750 Mbit/s
Encryption Standard: DES,3DES,MD5,SHA-1,AES (128-bit),AES (192-bit),AES (256-bit)
Number of VPN Supported: 5
Data Link Protocols: TCP/IP,HTTP,HTTPS,L2TP,PPTP
Connectivity Technology: Wired
New Connections Per Second: 7500
Total Number of Ports: 4
USB: Yes
Number of Network (RJ-45) Ports: 4
VPN Throughput: 93.75 MB/s
IPS Throughput: 93.75 MB/s
Ethernet Technology: Gigabit Ethernet
Total Number of Expansion Slots: 1
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 1
Manageable: Yes
Frequency: 50 Hz,60 Hz
Power Consumption: 11.60 W
Form Factor: Desktop,Compact
Height: 1.19" (30.20 mm)
Width: 7.89" (200.30 mm)
Depth: 4.47" (113.60 mm)
Weight (Approximate): 15.45 oz (438 g)
Environmental Compliance: Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
- Subscription-based with flexible licensing models
- Traffic inspection across all ports, without compromising performance
- SD-WAN & Advanced routing
- Intrusion detection and prevention, content & reputation based filtering, Capture ATP Sandboxing and DNS filtering1
- Native SSL VPN secure access
- Cloud and centralized management
- Zero-touch and bulk provisioning
- Automated and remote configuration
- SonicProtect ready
- Private connector with SonicWall Cloud Secure Edge
- Industry first firewall warranty included with APSS and MPSS subscriptions
[custom-specifications]
| Specifications | |
| Manufacturer | SonicWall Inc. |
| Manufacturer Part Number | 03-SSC-2749 |
| Manufacturer Website Address | http://www.sonicwall.com |
| Brand Name | SonicWall |
| Product Series | TZ |
| Product Model | TZ80 |
| Product Name | TZ80 Network Security/Firewall Appliance |
| Product Type | Network Security/Firewall Appliance |
| Technical Information | |
| Functionality | Intrusion Prevention |
| Firewall Protection Supported | Intrusion Prevention,Malware Protection,Application Control,Content Filtering,Anti-spyware,URL Filtering,Threat Protection,Secure IPsec VPN Connectivity,Deep Inspection Firewall,Gateway Antivirus,SSL Inspection,TLS Inspection,Dead Peer Detection,Deep Packet Inspection (DPI) |
| Firewall Throughput | 750 Mbit/s |
| Encryption Standard | DES,3DES,MD5,SHA-1,AES (128-bit),AES (192-bit),AES (256-bit) |
| Number of VPN Supported | 5 |
| Data Link Protocols | TCP/IP,HTTP,HTTPS,L2TP,PPTP |
| Connectivity Technology | Wired |
| New Connections Per Second | 7500 |
| Interfaces/Ports | |
| Total Number of Ports | 4 |
| USB | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Media & Performance | |
| VPN Throughput | 93.75 MB/s |
| IPS Throughput | 93.75 MB/s |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| I/O Expansions | |
| Total Number of Expansion Slots | 1 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 1 |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Frequency | 50 Hz,60 Hz |
| Power Consumption | 11.60 W |
| Physical Characteristics | |
| Form Factor | Desktop,Compact |
| Height | 1.19" (30.20 mm) |
| Width | 7.89" (200.30 mm) |
| Depth | 4.47" (113.60 mm) |
| Weight (Approximate) | 15.45 oz (438 g) |
| Miscellaneous | |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
Additional-pdf2
[/custom-user-manual]
