StarTech. com HDMI-SPLITTER-4K60UP 2-Port HDMI Splitter - 4K 60Hz HDMI 2. 0 - HDR/HDCP - 1 x 2 Display Duplication
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This HDMI 2.0 splitter delivers 18Gbps total bandwidth to support 4K video at 60Hz with 4:4:4 chroma subsampling for accurate color reproduction. The integrated downscaler automatically detects connected display capabilities, enabling mixed-resolution setups where one output can be 4K while the other operates at 1080p without manual configuration.
Advanced signal integrity features include 8kV air and 6kV contact ESD protection to safeguard connected equipment from electrostatic discharge. The splitter operates driver-free across all major operating systems and includes a dedicated reset button for quick EDID re-detection without disconnecting cables.
This section brings together practical product details such as Splitter Type, Maximum Video Resolution, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
This splitter simplifies multi-display setups with intelligent automation and robust construction. The automatic downscaling capability eliminates compatibility issues when connecting displays with different native resolutions, while the extended built-in HDMI cable provides immediate connectivity without additional purchases.
Flexible Power Options
Includes both a USB wall charger and Micro-B cable for direct power connection. The splitter can also draw power from any available 5V 1A USB port on computers, monitors, or power banks for installation flexibility.
- 31-inch USB power cable included
- 5V 1A USB port compatible
- Wall charger provided
Professional-Grade Protection
Built with industrial-grade ESD protection and RoHS/WEEE compliant materials for reliable operation in demanding environments. The ABS plastic housing provides durability while maintaining a compact footprint.
- 8kV air/6kV contact ESD protection
- RoHS/WEEE compliant
- ABS construction
Deployment / Use Cases
Ideal for digital signage applications where identical content must be displayed across multiple screens in retail stores, restaurants, or corporate lobbies. The splitter maintains signal integrity over extended cable runs while supporting 4K HDR content for high-impact visual presentations.
Perfect for conference rooms and training facilities requiring simultaneous display duplication on projectors and monitors. The driverless operation ensures compatibility with various source devices including laptops, media players, gaming consoles, and set-top boxes without software installation.
Retail & Hospitality Displays
Duplicate promotional content, menus, or informational displays across multiple screens while maintaining 4K quality and HDR color accuracy. The compact design allows discreet installation behind displays or within media cabinets.
Education & Corporate Training
Share instructional content simultaneously on primary displays and secondary monitors for optimal viewing in classrooms and meeting spaces. The automatic resolution management accommodates different display types within the same setup.
Physical Profile
Measuring just 2.56 x 2.17 x 0.75 inches (65 x 55 x 19 mm) and weighing approximately 3.25 ounces (92 grams), this splitter offers a compact footprint that fits easily behind displays or within cable management systems. The durable ABS construction provides reliable performance in various environmental conditions while the included accessories support immediate deployment.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.75" (19 mm), 2.17" (55 mm), 3.25 oz (92 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 2.17" (55 mm)
- Height
- 0.75" (19 mm)
- Weight
- 3.25 oz (92 g)
- Length
- 2.56" (65 mm)
What's in the Box
This package includes all necessary components for immediate setup and operation.
Highlights
- Duplicates 4K 60Hz video from one source to two displays simultaneously
- Supports HDR content and HDCP 2.2 copy protection for secure media playback
- Automatic downscaling enables mixed 4K/1080p output without manual configuration
- Includes 20-inch built-in HDMI cable to reduce strain on source device ports
- Flexible USB power options with included wall charger and cable
- Driverless operation compatible with all major operating systems
- 8kV air/6kV contact ESD protection safeguards connected equipment
- Compact design measures just 2.56 x 2.17 x 0.75 inches for easy installation
- RoHS/WEEE compliant construction with 2-year limited warranty
- Supports extended cable runs up to 16 feet with passive HDMI cables
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | HDMI-SPLITTER-4K60UP |
| Brand Name | StarTech.com |
| Product Name | 2-Port HDMI Splitter |
| Packaged Quantity | 1 |
| Product Type | Signal Splitter |
| Technical Information | |
| Splitter Type | 2-way |
| Video | |
| Maximum Video Resolution | 3480 x 2160 |
| Interfaces/Ports | |
| HDMI In | Yes |
| HDMI Out | Yes |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 2 |
| Media & Performance | |
| Maximum Operating Distance | 16.40 ft (5000 mm) |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Physical Characteristics | |
| Product Material | Acrylonitrile Butadiene Styrene (ABS) |
| Height | 0.75" (19 mm) |
| Width | 2.17" (55 mm) |
| Length | 2.56" (65 mm) |
| Weight (Approximate) | 3.25 oz (92 g) |
| Miscellaneous | |
| Package Contents | 2-Port HDMI Splitter 1 x USB Micro-B Cable 1 x USB Wall Charger 1 x Quick-Start Guide |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What maximum resolution does this HDMI splitter support?
The StarTech.com HDMI-SPLITTER-4K60UP supports resolutions up to 3480 x 2160 (4K UHD) at 60Hz refresh rates. This includes full 4:4:4 chroma subsampling for accurate color reproduction and HDR content compatibility when connected to compatible source devices and displays.
Can I connect displays with different resolutions to this splitter?
Yes, the splitter features automatic downscaling technology that detects the capabilities of connected displays. It can output different resolutions simultaneously, such as 4K to one display and 1080p to another, without requiring manual configuration or sacrificing signal quality on either output.
What power options are available for this HDMI splitter?
The splitter includes multiple power options: a USB wall charger with Micro-B cable, or connection to any available 5V 1A USB port on computers, monitors, or power banks. The 31-inch USB power cable provides installation flexibility with maximum power consumption of 5W during operation.
Does this splitter support HDCP 2.2 for protected content?
Yes, the splitter fully supports HDCP 2.2 and HDCP 1.4 copy protection standards. This ensures compatibility with streaming devices, Blu-ray players, gaming consoles, and other sources that require HDCP authentication for protected 4K HDR content playback on both connected displays.
What is the maximum cable distance supported by this splitter?
The splitter supports passive HDMI cables up to 16.4 feet (5 meters) in length. For longer distances, active HDMI cables or extenders can be used (sold separately). The built-in 20-inch HDMI cable connects directly to the source device, reducing strain on ports while supporting additional cable extensions as needed.
Is this splitter compatible with gaming consoles and media players?
Yes, the splitter is fully compatible with gaming consoles, media players, set-top boxes, computers, and other HDMI source devices. The driverless operation ensures plug-and-play functionality across all major operating systems, while the 60Hz refresh rate and low latency maintain smooth video performance for gaming and multimedia applications.
What resolution or display format is specified?
It features a display specification of 3480 x 2160, giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
