StarTech.com ST1000SPEXI 1-Port Gigabit Ethernet Network Card - PCIe x4 - Intel I210-AT Chipset - 10/100/1000Base-T
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This network adapter leverages PCI Express x4 host interface bandwidth to eliminate bottlenecks for Gigabit Ethernet traffic. The Intel I210-AT chipset provides hardware-accelerated TCP/IP checksum offloading, interrupt moderation, and advanced power management through IEEE 802.3az Energy Efficient Ethernet support.
Full compliance with IEEE 802.3, 802.3u, and 802.3ab standards guarantees interoperability with existing network infrastructure. The card supports auto-negotiation for speed and duplex detection, auto-MDIX for straight-through or crossover cable use, and Wake-on-LAN for remote power management.
Relevant factors for this section include Chipset Manufacturer, Chipset Model, Host Interface, Total Number of Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The ST1000SPEXI combines enterprise-grade Intel silicon with StarTech.com's hardware reliability for demanding networking tasks. Its feature set addresses both performance and management needs in professional deployments.
Intel Reliability
The I210-AT controller is widely deployed in servers and workstations, offering proven stability, low CPU utilization, and driver support across Windows, Linux, and virtualization platforms.
Advanced Networking Features
Support for 9K jumbo frames reduces protocol overhead for large data transfers, while IEEE 802.1Q VLAN tagging enables segmentation in managed network environments.
Deployment Flexibility
Included low-profile bracket allows installation in space-constrained chassis, and the card's small footprint ensures compatibility with most desktop and server PCIe slot configurations.
Deployment / Use Cases
This Gigabit Ethernet card is ideal for adding wired network connectivity to systems where the motherboard lacks an Ethernet port or where additional ports are required for network segmentation, failover, or dedicated management interfaces.
Common deployment scenarios include upgrading older desktops to Gigabit speeds, adding a dedicated management port to servers, providing network connectivity to custom-built workstations, or replacing failed onboard NICs in business computers.
Relevant factors for this section include Chipset Manufacturer, Chipset Model, Host Interface, Total Number of Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Server Management Port
Install in a server to create a dedicated out-of-band management interface separate from production network traffic, improving security and reliability for remote administration.
Desktop Network Upgrade
Add Gigabit Ethernet to desktop computers with failed or outdated onboard networking, restoring full network performance for file transfers, backups, and networked applications.
Physical Profile
The black plug-in card measures 2.60" wide by 2.70" deep with a low 0.70" profile that fits most chassis configurations. At just 1.30 ounces, it adds minimal weight to systems. The standard-height bracket is pre-installed with a low-profile bracket included for small form factor cases.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.70" (17.78 mm), 2.60" (66.04 mm), 2.70" (68.58 mm), 1.30 oz (36.85 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 2.60" (66.04 mm)
- Depth
- 2.70" (68.58 mm)
- Height
- 0.70" (17.78 mm)
- Weight
- 1.30 oz (36.85 g)
What's in the Box
The package includes everything needed for installation and operation.
Highlights
- Adds a 10/100/1000 RJ-45 Ethernet port via PCI Express x4 slot
- Intel I210-AT Gigabit Ethernet controller for reliable performance
- Supports PXE network boot for diskless workstation deployment
- Fully compliant with IEEE 802.3, 802.3u, and 802.3ab standards
- Auto-MDIX support eliminates need for crossover cables
- Wake-on-LAN enabled for remote power management
- Supports up to 9K jumbo frames for reduced protocol overhead
- IEEE 802.3az Energy Efficient Ethernet reduces power consumption
- IEEE 802.1Q VLAN tagging support for network segmentation
- Includes both standard and low-profile mounting brackets
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | ST1000SPEXI |
| Brand Name | StarTech.com |
| Product Name | 1-Port Gigabit Ethernet Network Card - PCI Express, Intel I210 NIC |
| Packaged Quantity | 1 Each |
| Product Type | Gigabit Ethernet Card |
| Technical Information | |
| Chipset Manufacturer | Intel |
| Chipset Model | I210-AT |
| Interfaces/Ports | |
| Host Interface | PCI Express x4 |
| Total Number of Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Maximum Data Transfer Rate | 1.95 Gbit/s |
| Network & Communication | |
| Network Technology | 10/100/1000Base-T |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Plug-in Card |
| Height | 0.70" (17.78 mm) |
| Width | 2.60" (66.04 mm) |
| Depth | 2.70" (68.58 mm) |
| Weight (Approximate) | 1.30 oz (36.85 g) |
| Miscellaneous | |
| Package Contents | 1-Port Gigabit Ethernet Network Card - PCI Express, Intel I210 NIC 1 x Low Profile Bracket 1 x Instruction Manual |
| Device Supported | Computer |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What type of PCI Express slot does this network card require?
The ST1000SPEXI uses a PCI Express x4 host interface. It is physically compatible with any PCIe x4, x8, or x16 slot and will operate at x4 lane width. The card requires a single available PCIe slot in your desktop or server chassis.
Does this card support Wake-on-LAN functionality?
Yes, the Intel I210-AT chipset includes hardware support for Wake-on-LAN (WOL). This allows the network card to receive a magic packet over the network to power on a sleeping or powered-off computer, enabling remote management and after-hours maintenance without physical access.
What operating systems are compatible with this network adapter?
The card is compatible with a wide range of operating systems through Intel's driver support. This includes Windows 10/11, Windows Server editions, various Linux distributions, and virtualization platforms like VMware ESXi and Microsoft Hyper-V. Always check StarTech.com's support site for the latest driver versions.
What is the maximum data transfer rate of this Gigabit Ethernet card?
The ST1000SPEXI supports a maximum data transfer rate of 1.95 Gbit/s (gigabits per second) when operating at full Gigabit Ethernet speed. This theoretical maximum accounts for protocol overhead, with actual throughput depending on network conditions, system resources, and connected equipment.
Does the package include both standard and low-profile brackets?
Yes, the package includes one low-profile bracket in addition to the pre-installed standard-height bracket. This allows installation in both traditional desktop cases and compact small form factor chassis that require low-profile expansion cards for proper fit.
What network features does the Intel I210-AT chipset provide?
The Intel I210-AT controller offers advanced networking features including TCP/IP checksum offloading to reduce CPU utilization, interrupt moderation for better performance under load, Energy Efficient Ethernet (EEE) for power savings during low traffic, and support for jumbo frames up to 9KB for improved large data transfer efficiency.
