Supermicro SSG-6019P-ACR12L+ SuperStorage Server Barebone - 1U Rackmount - Dual Socket P LGA-3647 - 12x DDR4 Slots - 16x Drive Bays - 10GbE
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Built on the Intel C622 chipset, the SSG-6019P-ACR12L+ supports dual Socket P LGA-3647 processors, compatible with Intel Xeon Platinum, Gold, Silver, and Bronze series. This ensures scalable performance for compute-intensive tasks. The memory subsystem features 12 DDR4-2933/PC4-23466 slots, enabling up to 3 TB of RAM and support for Intel Optane memory to accelerate storage performance.
Storage flexibility is a key focus, with 16 total expansion bays including 12 dedicated 3.5" bays. The integrated Serial ATA/600 controller with RAID support manages data integrity and throughput. Expansion capabilities include four PCIe slots (x4, x8, and two x16) for adding network cards, GPUs, or storage adapters. Networking is handled by 10 Gigabit Ethernet for high-speed data transfer, while six USB ports (four USB 3.0) provide peripheral connectivity.
Relevant factors for this section include Number of Processors Supported, Processor Socket, Processor Supported, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SSG-6019P-ACR12L+ combines scalability with reliability, offering a future-proof platform for evolving IT needs. Its modular design simplifies upgrades and maintenance, while the comprehensive package contents reduce deployment time.
High-Density Storage Design
With 16 drive bays and integrated SAS/SATA controllers, this system maximizes storage capacity in a 1U footprint, ideal for data-heavy applications.
- 12 dedicated 3.5" bays for high-capacity drives
- Includes SAS 16-port mezzanine controller
- Hybrid backplane supports mixed drive types
Enterprise-Grade Reliability
Dual 800W redundant power supplies and a robust cooling system ensure continuous operation in demanding environments.
- Redundant power for uptime
- Passive CPU heat sinks for efficient cooling
- RoHS compliance for environmental safety
Deployment / Use Cases
This server barebone is suited for environments requiring dense compute and storage resources. In data centers, it can serve as a hyper-converged infrastructure node, handling both compute and storage workloads efficiently. For media production or scientific research, the expansion slots allow for GPU acceleration or high-speed networking cards.
Small to medium businesses can deploy it as a foundational server for file sharing, database management, or application hosting, benefiting from its scalability and redundancy features. The included components, such as riser cards and backplanes, streamline integration into existing rack setups.
Virtualization Host
Leverage dual processor support and high memory capacity to run multiple virtual machines for server consolidation and cloud infrastructure.
Storage Server
Utilize the 16 drive bays and RAID capabilities to build a high-performance NAS or SAN solution for data backup and archival.
Physical Profile
The SSG-6019P-ACR12L+ features a standard 1U rack-mountable design with a black finish, measuring 1.70 inches in height, 17.60 inches in width, and 37.40 inches in depth. Weighing approximately 65.04 pounds, it is built for stability in rack environments. The compact form factor optimizes space in data centers while providing ample internal layout for components and cooling.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1U, 17.60" (447.04 mm), 37.40" (949.96 mm), 65.04 lb (29500 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.60" (447.04 mm)
- Depth
- 37.40" (949.96 mm)
- Height
- 1U
- Weight
- 65.04 lb (29500 g)
What's in the Box
This barebone system includes all necessary components for assembly and deployment:
Highlights
- Supports dual Intel Xeon Platinum, Gold, Silver, and Bronze processors for scalable performance
- 12 DDR4-2933 memory slots enable up to 3 TB of RAM with Intel Optane readiness
- 16 total drive bays with 12 dedicated 3.5" bays for high-capacity storage
- 10 Gigabit Ethernet ensures fast network connectivity for enterprise applications
- Dual 800W redundant power supplies provide reliable operation and uptime
- Includes comprehensive storage controllers and backplanes for flexible configuration
- 1U rack-mountable design optimizes space in data center environments
- RoHS compliant for environmentally responsible manufacturing
Specifications
| Specifications | |
|---|---|
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | SSG-6019P-ACR12L+ |
| Brand Name | Supermicro |
| Product Line | SuperStorage |
| Product Model | 6019P-ACR12L+ |
| Product Name | SuperStorage 6019P-ACR12L+ (Black) |
| Product Type | Server Barebone System |
| Processor | |
| Number of Processors Supported | 2 |
| Processor Socket | Socket P LGA-3647 |
| Processor Supported | Xeon Platinum,Xeon Gold,Xeon Silver,Xeon Bronze |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C622 |
| Memory | |
| Maximum Memory Supported | 3 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2933/PC4-23466 |
| Total Number of Memory Slots | 12 |
| Intel Optane Memory Ready | Yes |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 16 |
| Number of 3.5" Bays | 12 |
| Total Number of Expansion Slots | 4 |
| Number of PCI Express x4 Slots | 1 |
| Number of PCI Express x8 Slots | 1 |
| Number of PCI Express x16 Slots | 2 |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 3.0 Ports | 4 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 800 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.70" (43.18 mm) |
| Width | 17.60" (447.04 mm) |
| Depth | 37.40" (949.96 mm) |
| Weight (Approximate) | 65.04 lb (29500 g) |
| Miscellaneous | |
| Package Contents | SuperStorage 6019P-ACR12L+ (Black) 1 x Super X11DDW-NT Motherboard 1 x 1U Chassis 1 x SAS 16-port mezzanine controller based on Broadcom 3216 IOC. 1 x 4-Port Hybrid Backplane Supports 4 x 2.5 3 x 4-Port Backplane Supports 4 x 3.5" SAS/SATA HDD,HF,RoHS 2 x PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,14AWG,15A,125V,RoHS/REACH 1 x CBL,7PIN TO 7PIN,P1.5/1.0mm,17.2CM,26/28AWG,RoHS 2 x PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,14AWG,RoHS/REACH 1 x BPN PWR,2P/P3.0 to 3P/P3.0, 12V, 60CM,18AWG, 6A/pin, -20~80C, RoHS 4 x OcuLink v 1.0,INT,PCIe NVMe SSD,Passive Latch, 80 1 x OcuLink v 1.0,INT,PCIe NVMe SSD, Passive Latch, to MiniSAS 95CM,32AWG 1 x SLIMLINE SAS, INT,Passive Latch,91.9CM, power x4, 17/19.8CM 1 x SC802 front HDD LED board,RoHS 2 x Rubber pad, 3.0mm H, 10x10mm 1 x 1U LHS WIO Riser card with two PCI-E x16 slots 1 x 1U RHS WIO Riser card with one PCI-E 4.0 x16 slot,HF,RoHS 2 x 1U Passive CPU Heat Sink for X11 Purley Platform Equipped with a Narrow Retention Mechanism 2 x 1U 800W 100-240VAC/50-60Hz, and DC240V input 1 x 1U Power Distributor Board for SC802 support up to 800W.,RoH |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
FAQ
What processors are compatible with this server barebone?
The SSG-6019P-ACR12L+ supports dual Socket P LGA-3647 processors, compatible with Intel Xeon Scalable family including Xeon Platinum, Gold, Silver, and Bronze series. This allows for a range of performance options from entry-level to high-end compute tasks, ensuring flexibility for different workload requirements.
How much memory can this system support?
This system features 12 DDR4-2933/PC4-23466 memory slots, supporting up to 3 TB of RAM. It is also Intel Optane Memory Ready, enabling accelerated storage performance for demanding applications such as databases and virtualization.
What storage options are available with this barebone?
The SSG-6019P-ACR12L+ includes 16 total expansion bays, with 12 dedicated to 3.5" drives. It comes with a SAS 16-port mezzanine controller and hybrid backplanes that support both SAS and SATA drives, along with RAID capabilities via the Serial ATA/600 controller for data redundancy and performance.
What expansion slots does this server have?
This system provides four PCIe expansion slots: one PCIe x4, one PCIe x8, and two PCIe x16 slots. These slots allow for the addition of network adapters, graphics cards, or storage controllers, enhancing connectivity and functionality for specialized workloads.
What power supply configuration is included?
The barebone includes dual 800W power supplies that support input voltages of 120V AC and 230V AC. This redundant configuration ensures continuous operation by providing backup power in case of a failure, which is critical for mission-critical applications in data centers.
Is this system environmentally compliant?
Yes, the SSG-6019P-ACR12L+ is RoHS (Restriction of Hazardous Substances) compliant, meaning it meets environmental standards by limiting the use of certain hazardous materials. This makes it suitable for organizations with green IT initiatives or regulatory requirements.
