Supermicro SuperServer 4029GP-TRT3 Server Barebone System - 4U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C622 (SYS-4029GP-TRT3)
SKU:
SYS-4029GP-TRT3
UPC:
672042354283
(No reviews)
Write a Review
Write a Review
Supermicro
Supermicro SuperServer 4029GP-TRT3 Server Barebone System - 4U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C622 (SYS-4029GP-TRT3)
MSRP:
$10,315.95
$10,315.95
$9,013.99
Save:
$1,301.96 (12.62%)
Warranty Information:
1 Year
Condition:
New
Width:
43.69
(cm)
Height:
17.78
(cm)
Depth:
73.66
(cm)
B2B Pricing
Business volume discounts
IT Experts
Technical guidance
IT Configuration
Preparation & staging
Canada Stock
QC · ON · AB · BC
Product Features
Description
[custom-highlights][/custom-highlights]
- SuperServer 4029GP-TRT3 (Black)
- 1 x Super X11DPG-OT-CPU Motherboard
- 1 x Super X11DPG-O-PCIE Motherboard
- 1 x CSE-418GTS-R4000BP2 Chassis
- 1 x 24-port 2U SAS3 12Gbps hybrid backplane, support up to 20x 2.5-inch SAS3/SATA3 HDD/SSD and 4x SAS3/SATA3/NVMe Storage Devices
- 2 x HDD power extension for X8OBN, special 8 pin to 4 HDD. 45cm. 18AWG
- 8 x GPU,2x4F/CPU to 2x4F/CPU,P4.2, 30CM,16AWG, 10A/pin, -40~105C
- 2 x MINI SAS HD-MINI SAS,6G,INT,80CM,SB,28AWG
- 2 x OcuLink V. 1.0 source to MiniSAS HD,INT,PCIe, 70CM,34AWG,RoH
- 1 x Black plastic palm cover for X10DRG-O-PCIE
- 4 x RSC-X9DRG-O
- 2 x 2U Active CPU Heat Sink Supporting Narrow Bolster Plate Mounting Mechanism for X11 Purley Platform
- 4 x 1U 2000W Redundant Titanium Power Supply W/PMbus 73.5x40x265mm,RoHS/REACH
- 1 x CBL,FRONT CNTL,16 TO 16 PIN,RA,RND TUBE,75CM,28AWG
- 4 x PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,14AWG,15A,125V,RoHS/REACH
- 8 x 92x92x38 mm, 11.5K RPM, SC418G Middle Fan w/ Housing,RoHS/REACH,PBF
- 24 x Black gen 3rd hot-swap 2.5inch HDD tray
- 1 x 21 slot rear window for SC418X
- 1 x IO shield for X9DRG-O in SC418G
- 1 x Front control board adapter (TB826) for SC216,826,936,846
- 1 set Rail set, quick/quick, default for 4U 17.2"; W
- 1 x Threaded rail adapter default for round hole rack
- 3 x Black 2.5 HDD dummy cover for SC213,216 (Cover 8 HDD)
- 1 x Inner rail, quick-release type
- 1 x Outer rail, quick-release type
- 1 x 92x92x38 mm, 11.5K RPM, 4-pin PWM Bare Fan
Number of Processors Supported: 2
Processor Socket: Socket P LGA-3647
Processor Supported: Xeon Gold,Xeon Platinum,Xeon Silver,Xeon Bronze
64-bit Processing: Yes
Chipset Manufacturer: Intel
Chipset Model: C622
Maximum Memory Supported: 6 TB
Memory Technology: DDR4 SDRAM
Memory Standard: DDR4-2933/PC4-23466
Total Number of Memory Slots: 24
Intel Optane Memory Ready: Yes
Controller Type: Serial ATA/600
RAID Supported: Yes
Ethernet Technology: 10 Gigabit Ethernet
Number of Total Expansion Bays: 34
Total Number of Expansion Slots: 12
Number of PCI Express x16 Slots: 12
Total Number of USB Ports: 4
Number of USB 3.0 Ports: 4
Number of SATA Interfaces: 10
Input Voltage: 230 V AC
Number of Power Supplies Installed: 4
Maximum Power Supply Wattage: 2 kW
Color Family: Black
Product Color: Black
Form Factor: Rack-mountable
Rack Height: 4U
Height: 7" (177.80 mm)
Width: 17.20" (436.88 mm)
Depth: 29" (736.60 mm)
Weight (Approximate): 65.48 lb (29700 g)
Package Contents:
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 1 Year
- Perform computational tasks efficiently with Xeon Gold processor for smooth and reliable performance
- Serial ATA/600 interface delivers fast data transfer and higher throughput, ensuring smooth performance for demanding workloads
- Rack-mountable server barebone system maximizes space utilization while providing easy access to essential components
- Connect USB-enabled devices via 4 USB ports for seamless data sharing and reliable performance
- 10 Gigabit Ethernet optimizes network performance, ensuring rapid data transfer for enterprise and high-speed environments
- DDR4 SDRAM slot reduces processor idle time, improving multitasking and overall computing speed
[custom-specifications]
| Specifications | |
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | SYS-4029GP-TRT3 |
| Manufacturer Website Address | http://www.supermicro.com |
| Brand Name | Supermicro |
| Product Line | SuperServer |
| Product Model | 4029GP-TRT3 |
| Product Name | SuperServer 4029GP-TRT3 (Black) |
| Product Type | Server Barebone System |
| Processor | |
| Number of Processors Supported | 2 |
| Processor Socket | Socket P LGA-3647 |
| Processor Supported | Xeon Gold,Xeon Platinum,Xeon Silver,Xeon Bronze |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C622 |
| Memory | |
| Maximum Memory Supported | 6 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2933/PC4-23466 |
| Total Number of Memory Slots | 24 |
| Intel Optane Memory Ready | Yes |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 34 |
| Total Number of Expansion Slots | 12 |
| Number of PCI Express x16 Slots | 12 |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 4 |
| Number of SATA Interfaces | 10 |
| Power Description | |
| Input Voltage | 230 V AC |
| Number of Power Supplies Installed | 4 |
| Maximum Power Supply Wattage | 2 kW |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Rack Height | 4U |
| Height | 7" (177.80 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 29" (736.60 mm) |
| Weight (Approximate) | 65.48 lb (29700 g) |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
[/custom-specifications]
