Thermaltake TOUGHPOWER GT 1200W - Black - Internal - 120 V AC, 230 V AC Input - 3.3 V DC, 5 V DC, 12 V DC, -12 V DC, 5 V SB Output - - (PS-TPT-1200FNFAGU-3)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Specification Compliance: ATX 3.1
Efficiency: 90%
Power Factor Correction (PFC): Active
Number of Fans: 1
Fan Bearing Type: Hydraulic Bearing
Fan Diameter: 120 mm (4.72")
Protection Type: Over Current,Over Voltage,Under Voltage,Over Power,Short Circuit,Over Temperature
Modular: Yes
Modular Type: Fully Modular
Features: On/Off Switch,Low Noise
Input Voltage: 120 V AC,230 V AC
Number of +12V Rails: 1
Output Voltage: 3.3 V DC,5 V DC,12 V DC,-12 V DC,5 V SB
Output Voltage Detail: 3.3 V DC @ 20 A,5 V DC @ 20 A,12 V @ 100 A,-12 V @ 0.3 A,5 V SB @ 3 A
Output Current: 20 A,100 A,300 mA,3 A
Output Power: 1.20 kW
Number of SATA Power Connectors: 6
PCI Express Connector: Yes
PCI Express Version: 5.1
Number of (6+2 pin) PCI Express Power Connectors: 5
Number of (4+4 pin) CPU Power Connectors: 2
Color Family: Black
Product Color: Black
Form Factor: Internal
Height: 3.39" (86 mm)
Width: 5.91" (150 mm)
Depth: 5.51" (140 mm)
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Energy Efficiency Certification: 80 Plus Gold
Limited Warranty: 5 Year
[custom-specifications]
| Specifications | |
| Manufacturer | Thermaltake Technology Co., Ltd |
| Manufacturer Part Number | PS-TPT-1200FNFAGU-3 |
| Manufacturer Website Address | http://www.thermaltake.com |
| Brand Name | Thermaltake |
| Product Line | Toughpower |
| Product Series | GT |
| Product Model | TPD-1200AH2FXG-3 |
| Product Name | TOUGHPOWER GT 1200W |
| Product Type | Power Supply |
| Technical Information | |
| Specification Compliance | ATX 3.1 |
| Efficiency | 90% |
| Power Factor Correction (PFC) | Active |
| Number of Fans | 1 |
| Fan Bearing Type | Hydraulic Bearing |
| Fan Diameter | 120 mm (4.72") |
| Protection Type | Over Current,Over Voltage,Under Voltage,Over Power,Short Circuit,Over Temperature |
| Modular | Yes |
| Modular Type | Fully Modular |
| Features | On/Off Switch,Low Noise |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of +12V Rails | 1 |
| Output Voltage | 3.3 V DC,5 V DC,12 V DC,-12 V DC,5 V SB |
| Output Voltage Detail | 3.3 V DC @ 20 A,5 V DC @ 20 A,12 V @ 100 A,-12 V @ 0.3 A,5 V SB @ 3 A |
| Output Current | 20 A,100 A,300 mA,3 A |
| Output Power | 1.20 kW |
| Interfaces/Ports | |
| Number of SATA Power Connectors | 6 |
| PCI Express Connector | Yes |
| PCI Express Version | 5.1 |
| Number of (6+2 pin) PCI Express Power Connectors | 5 |
| Number of (4+4 pin) CPU Power Connectors | 2 |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Internal |
| Height | 3.39" (86 mm) |
| Width | 5.91" (150 mm) |
| Depth | 5.51" (140 mm) |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Miscellaneous | |
| Energy Efficiency Certification | 80 Plus Gold |
| Warranty | |
| Limited Warranty | 5 Year |
