TP-LINK ES208GP Omada 8-Port Gigabit Easy Managed Switch with 8-Port PoE+ 64W Budget Layer 2 Desktop/Wall Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Layer 2 switch supports 10/100/1000Base-T network technology over twisted pair cabling, ensuring compatibility with modern Gigabit devices. It incorporates key networking standards including IEEE 802.3af/at for PoE, IEEE 802.1Q for VLAN support, and IEEE 802.3x for flow control, providing a robust foundation for managed network environments.
The switch offers comprehensive management capabilities through its easy managed interface, accessible via web browser or the Omada app for centralized cloud management. This allows network administrators to configure quality of service (QoS) policies, set up virtual LANs (VLANs), enable port mirroring for monitoring, and implement link aggregation for increased bandwidth between switches.
Relevant factors for this section include Features, Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ES208GP provides significant advantages for network deployments requiring both data connectivity and device power in a single compact unit. Its combination of full PoE+ support across all eight ports with a substantial 64W power budget eliminates the need for separate power injectors or electrical outlets at device locations.
Enhanced Network Reliability
Built-in features including loop protection, broadcast storm control, and surge protection help maintain network stability and prevent downtime in critical applications.
- Automatic loop prevention
- IGMP snooping for multicast optimization
- Link aggregation support
Simplified Management
The easy managed interface balances advanced configuration options with user-friendly operation, making it accessible to both IT professionals and small business owners.
- Centralized cloud management via Omada app
- Remote camera reboot capability
- Port isolation for security
Deployment / Use Cases
This switch is ideally suited for surveillance system deployments where it can power multiple IP cameras while providing the network backbone for video transmission. The extended PoE range of up to 820 feet allows for flexible camera placement, while features like remote camera reboot ensure continuous surveillance operation.
Small office environments benefit from the ES208GP's combination of desktop/wall mounting options and silent fanless operation. The switch can power wireless access points throughout the office while providing VLAN segmentation for separating guest traffic from corporate networks. Retail locations appreciate the compact form factor that fits discreetly behind counters or on wall mounts while powering point-of-sale systems, digital signage, and inventory management devices.
Surveillance Systems
Power up to eight IP cameras with PoE+ while implementing port isolation and QoS to prioritize video traffic for reliable monitoring.
Small Business Networks
Create segmented networks with VLAN support while powering wireless access points and VoIP phones from a single centralized switch.
Physical Profile
The ES208GP features a compact desktop design measuring 6.20" wide × 4" deep × 1" high, with a weight of just 1.76 pounds for easy placement in space-constrained environments. The durable metal and steel construction provides both physical protection and effective heat dissipation for the fanless design. Four rubber feet included in the package ensure stable desktop placement, while integrated mounting points allow for secure wall installation in wiring closets, retail spaces, or surveillance control rooms.
- Width
- 6.20" (157.48 mm)
- Depth
- 4" (101.60 mm)
- Height
- 1" (25.40 mm)
- Weight
- 1.76 lb (800 g)
What's in the Box
The package includes all necessary components for immediate deployment of the switch in your network environment.
Highlights
- 8× 10/100/1000Mbps RJ45 ports with full PoE+ support
- 64W total PoE budget with up to 30W per port
- Easy managed interface with centralized cloud management via Omada app
- Fanless design for completely silent operation
- Durable metal casing with desktop and wall mounting options
- Layer 2 switching with VLAN, QoS, and link aggregation support
- Extended PoE range up to 820 feet for flexible device placement
- Automatic loop prevention and broadcast storm control
- Compact dimensions: 6.20" × 4" × 1" (W×D×H)
- RoHS compliant for environmental responsibility
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | ES208GP |
| Brand Name | Omada |
| Product Model | ES208GP |
| Product Name | 8-Port Gigabit Easy Managed Switch with 8-Port PoE+ |
| Packaged Quantity | 1 |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Plug and Play,Fanless,Reset Button,Surge Protection,Broadcast Storm Control,Virtual LAN (VLAN),IGMP Snooping,Flow Control,Loopback Detection,Link Aggregation,Loop Protection,Port Mirroring,Quality of Service (QoS),Easy to Use |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8× Gigabit Ethernet PoE+ |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Maximum Data Transfer Rate | 128 MB/s |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3af,IEEE 802.3at,IEEE 802.1p,IEEE 802.3x,IEEE 802.1ab,IEEE 802.1Q |
| Management & Protocols | |
| Manageable | Yes |
| Switch Management Type | Easy Managed |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 64 W |
| Power Source | Power Adapter,DC |
| Physical Characteristics | |
| Product Material | Metal,Steel |
| Form Factor | Desktop,Wall Mountable,Compact |
| Height | 1" (25.40 mm) |
| Width | 6.20" (157.48 mm) |
| Depth | 4" (101.60 mm) |
| Weight (Approximate) | 1.76 lb (800 g) |
| Miscellaneous | |
| Package Contents | 8-Port Gigabit Easy Managed Switch with 8-Port PoE+ Power Adapter Power Cord Installation Guide Rubber Feet |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
How many devices can this switch power simultaneously with PoE?
The ES208GP features eight PoE+ ports with a total power budget of 64W. This allows you to power up to eight compatible devices simultaneously, with each port capable of delivering up to 30W of power. The switch automatically negotiates power requirements with connected devices and distributes available power across all ports based on actual device needs.
What management capabilities does this easy managed switch provide?
This easy managed switch offers comprehensive management through both web interface and the Omada app for centralized cloud management. You can configure virtual LANs (VLANs) for network segmentation, set up quality of service (QoS) policies to prioritize traffic, enable port mirroring for network monitoring, implement link aggregation between switches, and configure port isolation for security. The interface balances advanced features with user-friendly operation suitable for both IT professionals and small business owners.
Can this switch be mounted on a wall?
Yes, the ES208GP is designed for both desktop placement and wall mounting. The durable metal casing includes integrated mounting points that allow for secure wall installation in wiring closets, retail spaces, or surveillance control rooms. The compact dimensions of 6.20" wide × 4" deep × 1" high make it suitable for space-constrained environments, and four rubber feet are included for stable desktop placement when wall mounting isn't required.
What networking standards does this switch support?
This switch supports IEEE 802.3af and IEEE 802.3at for Power over Ethernet, IEEE 802.1Q for VLAN implementation, IEEE 802.1p for traffic prioritization, IEEE 802.3x for flow control, IEEE 802.1ab for LLDP discovery, and IEEE 802.1D for bridging. These standards ensure compatibility with modern network equipment and provide the foundation for features like quality of service, virtual LAN segmentation, and efficient power management for connected devices.
Is this switch suitable for powering IP cameras in surveillance systems?
Yes, the ES208GP is particularly well-suited for surveillance deployments. It can power up to eight IP cameras simultaneously with its PoE+ ports, eliminating the need for separate power supplies at each camera location. The extended PoE range of up to 820 feet allows for flexible camera placement, while features like remote camera reboot capability help maintain continuous surveillance operation. Port isolation can be configured to enhance security between cameras, and QoS settings ensure video traffic receives priority on the network.
What are the physical dimensions and weight of this switch?
The ES208GP measures 6.20 inches in width, 4 inches in depth, and 1 inch in height (157.48 mm × 101.60 mm × 25.40 mm). It weighs approximately 1.76 pounds (800 grams), making it lightweight and easy to install in various locations. The compact form factor allows for placement in space-constrained environments, while the durable metal and steel construction provides physical protection and effective heat dissipation for the fanless design that ensures silent operation.
