TP-LINK RE505X AX1500 Wi-Fi 6 Range Extender - Dual-Band 1.5 Gbps - 2 External Antennas - Gigabit Ethernet Port - OneMesh Compatible
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Built on the 802.11ax (Wi-Fi 6) standard, the RE505X operates on dual frequency bands—2.4 GHz and 5 GHz—delivering combined wireless speeds up to 1.5 Gbps. This includes 1201 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band, optimizing performance for bandwidth-intensive activities. The extender features two external antennas that enhance signal propagation and coverage, effectively reducing interference and improving connection reliability in multi-device environments.
For network security, the RE505X supports robust encryption standards including 64-bit WEP, 128-bit WEP, WPA, and WPA-PSK2, ensuring your extended network remains protected against unauthorized access. The integrated Gigabit Ethernet port provides a high-speed wired backbone, capable of supporting data transfer rates up to 1000 Mbps, making it ideal for connecting devices that benefit from low-latency, stable connections.
Relevant factors for this section include Wireless LAN Standard, Network Band, Frequency Band, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The RE505X stands out with its combination of Wi-Fi 6 technology, extended coverage capabilities, and user-friendly features designed to enhance your network experience.
Seamless Whole-Home Coverage
OneMesh compatibility allows the RE505X to integrate with supported TP-Link routers, creating a single network name that devices can roam across without manual switching. This eliminates signal drops and provides a consistent WiFi experience throughout your space.
- Unified network with compatible routers
- No manual network switching required
- Intelligent roaming for connected devices
Enhanced Connectivity Options
Beyond wireless extension, the Gigabit Ethernet port offers a wired alternative for devices that demand maximum performance. This is particularly useful for stationary equipment like gaming consoles, desktop PCs, or media servers that benefit from reduced latency.
- Gigabit Ethernet for wired speeds
- Ideal for high-bandwidth applications
- Reduces wireless congestion
Simplified Setup and Management
The TP-Link Tether app (available for Android and iOS) guides you through installation in minutes, with an intelligent signal indicator helping to find the optimal placement for the extender. Ongoing management and settings adjustments can be handled directly from your smartphone.
- Quick setup via mobile app
- Signal strength indicator for placement
- Remote management capabilities
Deployment / Use Cases
The RE505X is ideal for residential and small office environments where existing WiFi coverage is insufficient. It effectively extends network reach to remote areas such as basements, garages, backyard patios, or upstairs bedrooms, ensuring that devices like smartphones, laptops, smart home gadgets, and streaming media players maintain strong connections.
In home office setups, the extender can bridge the gap between a router located in a central area and workspaces in separate rooms, supporting video conferencing, large file transfers, and cloud-based applications without interruption. For entertainment systems, placing the RE505X near a home theater or gaming station allows wired connections via the Gigabit Ethernet port, delivering stable, high-speed internet for 4K streaming, online gaming, and media server access.
Physical Profile
The RE505X features a compact, desktop-friendly design with dimensions of 4.90" (124.46 mm) in height, 2.90" (73.66 mm) in width, and 1.80" (45.72 mm) in depth. Its small footprint allows for discreet placement on shelves, desks, or countertops without occupying significant space. The two external antennas are adjustable, enabling you to orient them for optimal signal direction based on your environment. With a power consumption of just 10 W, the extender operates efficiently, making it suitable for continuous use without excessive energy draw.
- Width
- 2.90" (73.66 mm)
- Depth
- 1.80" (45.72 mm)
- Height
- 4.90" (124.46 mm)
What's in the Box
The package includes everything needed for immediate deployment and use.
Package contents include AX1500 Wi-Fi Range Extender Quick Installation Guide, AX1500 Wi-Fi Range Extender. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Wi-Fi 6 (802.11ax) technology for faster, more efficient wireless performance.
- Dual-band operation with speeds up to 1.5 Gbps (1201 Mbps on 5 GHz, 300 Mbps on 2.4 GHz).
- Two high-gain external antennas to boost signal strength and extend coverage.
- Gigabit Ethernet port for wired connections with speeds up to 1000 Mbps.
- OneMesh compatible for seamless roaming with supported TP-Link routers.
- Easy setup and management via the TP-Link Tether app (Android/iOS).
- Universal compatibility with all WiFi-enabled devices and routers.
- Compact design with dimensions of 4.90" x 2.90" x 1.80" for flexible placement.
- Robust encryption support (WEP, WPA, WPA2) for secure network extension.
- 2-year limited warranty for added peace of mind.
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | RE505X |
| Brand Name | TP-Link |
| Product Model | RE505X |
| Product Name | AX1500 Wi-Fi Range Extender |
| Packaged Quantity | 1 |
| Product Type | Wireless Range Extender |
| Technical Information | |
| Wireless LAN Standard | 802.11ax |
| Network Band | Dual Band |
| Frequency Band | 2.40 GHz,5 GHz |
| Total Number of Antennas | 2 |
| Number of External Antennas | 2 |
| Wireless Transmission Speed | 1.50 Gbit/s |
| Data Encryption | Yes |
| Encryption Standard | 64-bit WEP,128-bit WEP,WPA,WPA-PSK2 |
| Interfaces/Ports | |
| Ethernet Technology | Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| Power Description | |
| Power Consumption | 10 W |
| Physical Characteristics | |
| Antenna Form Factor | External |
| Height | 4.90" (124.46 mm) |
| Width | 2.90" (73.66 mm) |
| Depth | 1.80" (45.72 mm) |
| Miscellaneous | |
| Package Contents | AX1500 Wi-Fi Range Extender Quick Installation Guide |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the maximum wireless speed of the TP-Link RE505X?
The RE505X delivers combined dual-band speeds up to 1.5 Gbps, with 1201 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band. This Wi-Fi 6 performance supports smoother streaming, gaming, and downloading across multiple devices simultaneously.
Does this range extender support wired connections?
Yes, the RE505X includes one Gigabit Ethernet port, providing wired speeds up to 1000 Mbps. This port is ideal for connecting devices like gaming consoles, smart TVs, or desktop computers that benefit from stable, low-latency internet access.
How does OneMesh compatibility work with the RE505X?
OneMesh allows the RE505X to create a seamless WiFi network when used with compatible TP-Link routers, such as the Archer A7. Devices automatically roam between the router and extender using a single network name, eliminating the need to manually switch networks and reducing signal drops.
What is the setup process for the RE505X range extender?
Setup is quick and straightforward using the TP-Link Tether app, available for Android and iOS. The app guides you through installation steps and includes an intelligent signal indicator to help find the optimal placement for the extender, ensuring the best possible coverage extension.
Can the RE505X be used with any router or access point?
Yes, the RE505X is universally compatible with all standard WiFi-enabled devices and routers or access points. It supports the latest Wi-Fi 6 (802.11ax) devices as well as older Wi-Fi standards, making it a versatile addition to any existing network.
What security features does the RE505X offer for extended networks?
The RE505X supports multiple encryption standards including 64-bit WEP, 128-bit WEP, WPA, and WPA-PSK2 (WPA2). These protocols help secure your extended wireless network against unauthorized access, ensuring that your data remains protected as it travels between devices.
